Model Electrolux FPUS2686LF3 REFRIGERATOR – Common Parts &amp; Diagrams

1

241786014 Frigidaire Refrigerator Door Gasket In Stock WCI 241786014 $57.30

2

241716101 Frigidaire Refrigerator Ice Auger Backorder WCI 241716101 $74.17

2

241786013 Frigidaire Refrigerator Door Gasket Backorder WCI 241786013 $57.76

2

WCI 242166910 WCI 242166910 Contact Us For Availability

3

218679614 Frigidaire Refrigerator Evaporator Backorder WCI 218679614 $12.67

3

241685201 Frigidaire Refrigerator Drive Cam Backorder WCI 241685201 $26.72

4

240323002 Frigidaire Bottom Clear Door Bin In Stock WCI 240323002 $36.85

4

241734001 Frigidaire Refrigerator Ice Bucket In Stock WCI 241734001 $76.32

4

WCI 242034203 WCI 242034203 Contact Us For Availability

4A

240334201 Frigidaire Refrigerator Upper Freez In Stock WCI 240334201 $27.02

4B

240351601 Frigidaire Refrigerator Door Bin In Stock WCI 240351601 $20.49

5

241545005 Frigidaire Refrigerator Tilt-Out Bi Backorder WCI 241545005 $80.37

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $31.93

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $23.09

6

241685101 Frigidaire Refrigerator Ice Dispens In Stock WCI 241685101 $33.06

7

WCI 240326203 WCI 240326203 Contact Us For Availability

7

WCI 241735302 WCI 241735302 Contact Us For Availability

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $11.78

9

241563601 Frigidaire Refrigerator Motor Mount Backorder WCI 241563601 $11.32

9A

241845301 Frigidaire Refrigerator Motor Mount Backorder WCI 241845301 $14.48

10

240435912 Frigidaire Refrigerator Air Duct Co Backorder WCI 240435912 $77.92

10

241726501 Frigidaire Refrigerator Drive Bar In Stock WCI 241726501 $37.18

10A

241719711 Frigidaire Refrigerator Evaporator Backorder WCI 241719711 $65.55

11

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $27.18

11

WCI 241657602 WCI 241657602 Contact Us For Availability

11

WCI 242026456 WCI 242026456 Contact Us For Availability

11A

241657504 Frigidaire Refrigerator Shelf In Stock WCI 241657504 $52.54

11C

240324101 Frigidaire Refrigerator Pizza Shelf Backorder WCI 240324101 $35.78

12

5304456664 Frigidaire Refrigerator Wiring Har Backorder WCI 5304456664 $79.31

12

WCI 242015101 WCI 242015101 Contact Us For Availability

13

241990201 Frigidaire Refrigerator Door Stop Backorder WCI 241990201 $13.59

13

5304456665 Frigidaire Refrigerator Thermostat Backorder WCI 5304456665 $79.31

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $95.44

13A

241990202 Frigidaire Refrigerator Door Stop A Backorder WCI 241990202 $13.59

14

242044113 Frigidaire Refrigerator Defrost Hea In Stock WCI 242044113 $65.42

14

242135301 Frigidaire Refrigerator Evaporator In Stock WCI 242135301 $4.97

14A

241547902 Frigidaire Refrigerator Light Switc In Stock WCI 241547902 $10.86

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

5303918284 Frigidaire Refrigerator Evaporator In Stock WCI 5303918284 $330.62

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $54.68

WCI 242038850 WCI 242038850 Contact Us For Availability

16

241559801 Frigidaire Light Socket Refrigerato Backorder WCI 241559801 $45.94

16

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $37.63

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

17

241684503 Frigidaire Ice Crusher Blade In Stock WCI 241684503 $10.39

18

WCI 241972501 WCI 241972501 Contact Us For Availability

20

241734902 Frigidaire Refrigerator Cover Backorder WCI 241734902 $93.20

21

5303918214 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918214 $14.53

21A

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $4.97

21D

241548003 Frigidaire Refrigerator Screw In Stock WCI 241548003 $1.79

22

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.05

22

241917801 Frigidaire Refrigerator Closer Plat In Stock WCI 241917801 $4.51

22

241990301 Frigidaire Hinge Bearing Backorder WCI 241990301 $4.51

22A

241990302 Frigidaire Refrigerator Hinge Beari Backorder WCI 241990302 $4.51

22B

241760404 Frigidaire Refrigerator Bearing Backorder WCI 241760404 $8.15

22C

241760402 Frigidaire Refrigerator Bearing In Stock WCI 241760402 $12.20

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $27.16

241684001 Frigidaire Refrigerator Front Plate Backorder WCI 241684001 $92.01

241845401 Frigidaire Refrigerator Sensor Hous Backorder WCI 241845401 $8.60

WCI 242092405 WCI 242092405 Contact Us For Availability

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $42.12

25

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

25

240599301 Frigidaire Refrigerator Crisper Dra In Stock WCI 240599301 $39.88

25

WCI 240491503 WCI 240491503 Contact Us For Availability

25A

240350903 Frigidaire Refrigerator Crisper Pan In Stock WCI 240350903 $37.62

25B

241969501 Frigidaire Refrigerator Meat Pan Co In Stock WCI 241969501 $57.89

26

240351061 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351061 $45.88

26

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $6.79

26

241697603 Frigidaire Defrost Pan Backorder WCI 241697603 $47.70

26A

240362201 Frigidaire Refrigerator Humidity Co Backorder WCI 240362201 $43.91

27

240351240 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351240 $113.90

27A

WCI 241812702 WCI 241812702 Contact Us For Availability

30

241941003 Frigidaire Refrigerator Starter Rel In Stock WCI 241941003 $38.85

33

241684802 Frigidaire Refrigerator Spacer Backorder WCI 241684802 $5.40

34

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

34

241689802 Frigidaire Refrigerator Spacer Backorder WCI 241689802 $4.97

35A

241684303 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684303 $10.39

35B

241684203 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684203 $10.85

37A

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $13.13

37B

241684108 Frigidaire Refrigerator Ice Crusher In Stock WCI 241684108 $13.13

37C

241684109 Frigidaire Ice Crusher Blade In Stock WCI 241684109 $13.13

38

241761301 Frigidaire Upper Bracket Hinge Backorder WCI 241761301 $41.88

38A

241761302 Frigidaire Refrigerator Upper Hinge In Stock WCI 241761302 $40.78

39

WCI 240430706 WCI 240430706 Contact Us For Availability

39A

WCI 240430702 No Longer Available

40

241946709 Frigidaire Refrigerator Upper Hinge Backorder WCI 241946709 $41.71

40A

241891901 Frigidaire Refrigerator Wiring Harn Backorder WCI 241891901 $1.31

40A

241946710 Frigidaire Refrigerator Upper Hinge Backorder WCI 241946710 $40.85

41

241550801 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550801 $37.63

42

240578902 Frigidaire Screw Mounting Hinge In Stock WCI 240578902 $9.04

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $19.99

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.72

45A

241675902 Frigidaire Refrigerator Solenoid Sp Backorder WCI 241675902 $4.07

45B

241676001 Frigidaire Refrigerator E-Ring Sole Backorder WCI 241676001 $44.35

45C

241676101 Frigidaire Refrigerator Solenoid-Ac In Stock WCI 241676101 $40.78

46

241716002 Frigidaire Refrigerator Control Rod Backorder WCI 241716002 $28.07

47

240350649 Frigidaire Refrigerator Glass Inser In Stock WCI 240350649 $64.95

47

241513001 Frigidaire Refrigerator Shelf Mount In Stock WCI 241513001 $66.34

47

241731801 Frigidaire Refrigerator Control Rod Backorder WCI 241731801 $9.06

47A

240350603 Frigidaire Glass Shelf Backorder WCI 240350603 $73.07

47B

240443384 Frigidaire Refrigerator Crisper Cov In Stock WCI 240443384 $87.18

48

241684602 Frigidaire Refrigerator Control Rod Backorder WCI 241684602 $67.69

49

240356402 Frigidaire Refrigerator Gallon Door In Stock WCI 240356402 $42.72

49

240564401 Frigidaire Refrigerator Sliding Bas In Stock WCI 240564401 $89.90

49

241734501 Frigidaire Refrigerator Rail Backorder WCI 241734501 $113.81

49B

WCI 240530504 WCI 240530504 Contact Us For Availability

50

241675601 Frigidaire Refrigerator Solenoid Gu Backorder WCI 241675601 $50.64

50

5304499076 Frigidaire Refrigerator Main Power In Stock WCI 5304499076 $186.58

51

240343002 Frigidaire Hanger Basket Backorder WCI 240343002 $38.55

51

WCI 241676301 WCI 241676301 Contact Us For Availability

52

240343102 Frigidaire Basket Hanger In Stock WCI 240343102 $41.24

52

241684901 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684901 $18.12

53

241690402 Frigidaire Refrigerator Spiral Pin Backorder WCI 241690402 $12.20

54

WCI 241532401 No Longer Available

54

241685001 Frigidaire Auger Nut Backorder WCI 241685001 $12.67

55

241690306 Frigidaire Refrigerator Washer Backorder WCI 241690306 $31.71

55

297286803 Frigidaire Refrigerator Run Capacit In Stock WCI 297286803 $16.17

56

241690201 Frigidaire Refrigerator E-Ring Backorder WCI 241690201 $12.22

58

218781101 Frigidaire Handle Screw In Stock WCI 218781101 $9.97

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $28.97

60

242018301 Frigidaire Refrigerator Condenser F In Stock WCI 242018301 $80.30

60

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $8.14

60

WCI 242010601 WCI 242010601 Contact Us For Availability

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.41

62

241969607 Frigidaire Refrigerator Meat Pan In Stock WCI 241969607 $82.40

66

241756801 Frigidaire Refrigerator Meat Keeper Backorder WCI 241756801 $16.75

66A

241756901 Frigidaire Refrigerator Damper Hous Backorder WCI 241756901 $19.47

72

241969405 Frigidaire Kickplate Grille Backorder WCI 241969405 $49.29

74

218755402 Frigidaire Refrigerator Set Screw In Stock WCI 218755402 $4.07

79

218755401 Frigidaire Refrigerator Screw Set In Stock WCI 218755401 $14.94

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.60

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $30.80

82

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.50

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.04

85

241856909 Frigidaire Refrigerator Connector T In Stock WCI 241856909 $94.62

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $39.88

91

240380101 Frigidaire Refrigerator Ice Maker D Backorder WCI 240380101 $44.37

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.60

93

241911705 Frigidaire Refrigerator Light Switc In Stock WCI 241911705 $33.97

94

WCI 242034101 WCI 242034101 Contact Us For Availability

100

240326304 Frigidaire Refrigerator Cover Backorder WCI 240326304 $44.31

100

241993001 Frigidaire Refrigerator Left Crispe In Stock WCI 241993001 $5.55

100

241993101 Frigidaire Refrigerator Right Crisp In Stock WCI 241993101 $3.46

101

218493101 Frigidaire Refrigerator Screw In Stock WCI 218493101 $8.58

107

WCI 241753601 WCI 241753601 Contact Us For Availability

108

WCI 241753701 WCI 241753701 Contact Us For Availability

115

241853801 Frigidaire Refrigerator Damper Cont In Stock WCI 241853801 $67.82

120

240342901 Frigidaire Refrigerator Ice Cream S Backorder WCI 240342901 $33.32

126

241674401 Frigidaire Refrigerator Channel Backorder WCI 241674401 $30.36

126

241674402 Frigidaire Refrigerator Channel Backorder WCI 241674402 $27.62

139

BASE-WATER FILTER Backorder WCI 242009604 $20.15

208

241754301 Frigidaire Refrigerator Sleeve Backorder WCI 241754301 $24.46

210

241998303 Frigidaire Refrigerator Water Filte In Stock WCI 241998303 $6.51

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.04

218515403 Frigidaire Refrigerator Grille Clip Backorder WCI 218515403 $18.56

218976419 Frigidaire Refrigerator Tube Backorder WCI 218976419 $14.50

218976429 Frigidaire Refrigerator Tube Backorder WCI 218976429 $25.83

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.01

240349801 Frigidaire Refrigerator Clip In Stock WCI 240349801 $12.24

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.26

240362101 Frigidaire Refrigerator Crisper Cov In Stock WCI 240362101 $28.07

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $8.14

240451503 Frigidaire Refrigerator Screw Backorder WCI 240451503 $2.26

240542901 Frigidaire Water Valve Cap Backorder WCI 240542901 $11.33

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $13.13

241512807 Frigidaire Refrigerator Seal Backorder WCI 241512807 $1.79

241519401 Frigidaire Refrigerator Clip Backorder WCI 241519401 $5.40

241550701 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550701 $10.85

241587402 Frigidaire Refrigerator Ice Deflect Backorder WCI 241587402 $13.13

241595202 Frigidaire Refrigerator Clip Backorder WCI 241595202 $10.85

241781601 Frigidaire Refrigerator Air Return Backorder WCI 241781601 $5.40

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $49.65

241834703 Frigidaire Refrigerator Wiring Harn Backorder WCI 241834703 $64.98

241850615 Frigidaire Ice Maker Fill Tube Asse In Stock WCI 241850615 $22.19

241852501 Frigidaire Refrigerator Clip Backorder WCI 241852501 $9.93

241860813 Frigidaire Refrigerator Ice Contain Backorder WCI 241860813 $166.58

241945101 Frigidaire Refrigerator Air Duct In Backorder WCI 241945101 $12.68

241987601 Frigidaire Refrigerator Wiring Harn Backorder WCI 241987601 $67.22

242141102 Frigidaire Refrigerator Wiring Harn In Stock WCI 242141102 $113.14

5303918327 Frigidaire Refrigerator Heat Excha In Stock WCI 5303918327 $176.48

WCI 5303918222 WCI 5303918222 Contact Us For Availability

WCI 241519902 WCI 241519902 Contact Us For Availability

WCI 241522901 WCI 241522901 Contact Us For Availability

WCI 241780403 WCI 241780403 Contact Us For Availability
