Model Electrolux FPEF3077QFA RANGE/OVEN, ELECTRIC, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

2

5304527989 Frigidaire Liner Backorder WCI 5304527989 $17.20

4

5304511907 Frigidaire Range Panel Backorder WCI 5304511907 $41.86

4

GLASS, OVEN DOOR, BLACK, OUTER WCI 316452744 Contact Us For Availability

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $3.61

6

316406328 Frigidaire Shield Backorder WCI 316406328 $51.52

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $57.70

6A

316496205 Frigidaire Oven Rack In Stock WCI 316496205 $82.86

7

316405600 Frigidaire Insulation Backorder WCI 316405600 $48.41

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.88

8

5304490938 Frigidaire Glide Assembly In Stock WCI 5304490938 $8.60

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

8

BOTTOM, OVEN WCI 316549601 Contact Us For Availability

9

LINER, OVEN DOOR WCI 316423707 No Longer Available

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

10

5304494433 Frigidaire Potentiometer Backorder WCI 5304494433 $42.55

10

SCREW, HANDLE MTG., 10-24 X 1.75", (2) WCI 316439500 Contact Us For Availability

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

11

5304493649 Frigidaire Oven Range Wall Potenti In Stock WCI 5304493649 $45.26

12

316405000 Frigidaire Oven Seal In Stock WCI 316405000 $89.27

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $38.11

13

DOOR ASSEMBLY, OUTER, STAINLESS, W/BADGE WCI 5304494422 Contact Us For Availability

14

316022500 Frigidaire Oven Warmer Drawer Zone In Stock WCI 316022500 $36.24

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $64.96

15

5304493644 Frigidaire Range Cap Backorder WCI 5304493644 $39.44

15A

316280701 Frigidaire Range Double 6" Surface In Stock WCI 316280701 $169.09

15A

5304493646 Frigidaire Range Cap In Stock WCI 5304493646 $39.44

15B

316282101 Frigidaire Oven Element In Stock WCI 316282101 $139.64

15C

140273621015 Frigidaire Warmer Element, Radia Backorder WCI 140273621015 $22.85

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

16

807038642 Frigidaire Range Maintop Backorder WCI 807038642 $212.10

16

GLASS, DOOR, AIRWASH WCI 316552800 Contact Us For Availability

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $36.24

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.94

18

316405800 Frigidaire Assembly Latch In Stock WCI 316405800 $29.00

18

316580800 Frigidaire Hinge Bracket Backorder WCI 316580800 $5.88

19

5304496879 Frigidaire Range Panel Backorder WCI 5304496879 $178.79

20

316284100 Frigidaire Range Spacer Assembly In Stock WCI 316284100 $9.50

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.85

21

316533801 Frigidaire Oven Plate Backorder WCI 316533801 $3.59

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.32

23

HINGE, OVEN DOOR, BROWN WCI 316575911 Contact Us For Availability

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $31.23

28

316528700 Frigidaire Insulation Assembly Backorder WCI 316528700 $56.46

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.34

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $39.37

39

5304494423 Frigidaire Range Handle Backorder WCI 5304494423 $227.49

40

316552401 Frigidaire Range Bracket Backorder WCI 316552401 $17.21

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

46

316557300 Frigidaire Range Indicator Light Le In Stock WCI 316557300 $6.67

47

LIGHT/LAMP, INDICATOR, BLUE WCI 316022505 Contact Us For Availability

52

316461700 Frigidaire Oven Clip Assembly In Stock WCI 316461700 $7.65

53

5304504202 Frigidaire Red Meat Temperature Pr Backorder WCI 5304504202 $71.26

53

5304532042 Frigidaire Door Filler Shield Backorder WCI 5304532042 $15.38

54

316436000 Frigidaire Range Surface Element Sw In Stock WCI 316436000 $46.51

54

RECEPTACLE, PROBE WCI 316536900 Contact Us For Availability

54A

316436001 Frigidaire Oven Range Infinite Burn In Stock WCI 316436001 $21.80

54B

316238201 Frigidaire Range Switch In Stock WCI 316238201 $57.14

54C

SWITCH INFT Backorder WCI 5304537897 $21.74

55

316247700 Frigidaire Oven Nut Backorder WCI 316247700 $10.85

55

316408300 Frigidaire Range Bracket Backorder WCI 316408300 $12.67

56

316234045 Frigidaire Oven Shield Backorder WCI 316234045 $39.43

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $7.25

58A

316406604 Frigidaire Insulation Backorder WCI 316406604 $41.22

59

316208401 Frigidaire Range VentTube Backorder WCI 316208401 $111.62

59A

316208304 Frigidaire Oven Tube Backorder WCI 316208304 $50.64

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $37.82

63

5304536404 Frigidaire Strap Backorder WCI 5304536404 $1.29

66

316430900 Frigidaire Range Broil Element In Stock WCI 316430900 $145.79

67

316563600 Frigidaire Oven Element Backorder WCI 316563600 $161.89

68

316429100 Frigidaire Range Support Bracket Backorder WCI 316429100 $39.52

71

316283204 Frigidaire Range Shield Backorder WCI 316283204 $33.50

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $14.03

87

316081200 Frigidaire Oven Bracket Backorder WCI 316081200 $47.97

88

316203500 Frigidaire Oven Rod Backorder WCI 316203500 $45.72

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $32.80

97

316472807 Frigidaire Range Circuit Board Asse In Stock WCI 316472807 $168.06

100

808751525 Frigidaire Control Assembly In Stock WCI 808751525 $237.00

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $37.65

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $215.44

108

316256100 Frigidaire Range Fan Motor In Stock WCI 316256100 $138.12

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.38

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.20

161

316211603 Frigidaire Oven Element Backorder WCI 316211603 $153.00

170

316112005 Frigidaire Oven Anti-Tip Range Brac In Stock WCI 316112005 $10.00

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.23

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.60

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.60

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $3.61

5304493655 Frigidaire Range Harness Backorder WCI 5304493655 $118.68

5304516183 Frigidaire Harness Backorder WCI 5304516183 $26.22

5304516198 Frigidaire Harness Backorder WCI 5304516198 $87.18

HARNESS, BACKGUARD WCI 5304498836 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06

5304494446 Frigidaire Oven Switch Backorder WCI 5304494446 $27.62

5308014215 Frigidaire Oven Screw In Stock WCI 5308014215 $1.35

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $7.25

NIC

316542203 Frigidaire Insulator Backorder WCI 316542203 $4.97
