Model Electrolux FGHS2631PE0 REFRIGERATOR – Common Parts &amp; Diagrams

1

241786014 Frigidaire Freezer Door Gasket In Stock WCI 241786014 $55.53

1

242106605 Frigidaire Refrigerator Condenser Backorder WCI 242106605 $115.36

2

241716101 Frigidaire Refrigerator Ice Auger In Stock WCI 241716101 $67.00

2

241786013 Frigidaire Refrigerator Door Gasket In Stock WCI 241786013 $56.81

2

WCI 5304436616 WCI 5304436616 Contact Us For Availability

3

218679614 Frigidaire Refrigerator Evaporator Backorder WCI 218679614 $12.46

3

241685201 Frigidaire Refrigerator Drive Cam In Stock WCI 241685201 $26.28

4

240323002 Frigidaire Bottom Clear Door Bin In Stock WCI 240323002 $38.08

4

241561302 Frigidaire Refrigerator Container Backorder WCI 241561302 $63.05

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $8.69

4A

240351601 Frigidaire Freezer Door Bin In Stock WCI 240351601 $32.09

4A

242176402 Frigidaire Refrigerator Trim Backorder WCI 242176402 $33.87

4B

240334201 Frigidaire Refrigerator Upper Freez In Stock WCI 240334201 $41.89

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $31.41

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $22.72

6

241685101 Frigidaire Refrigerator Ice Dispens In Stock WCI 241685101 $32.52

7

241561402 Frigidaire Refrigerator Front Ice C Backorder WCI 241561402 $49.81

7

WCI 240326203 WCI 240326203 Contact Us For Availability

7

WCI 5304458382 WCI 5304458382 Contact Us For Availability

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $11.59

9

241563601 Frigidaire Refrigerator Motor Mount Backorder WCI 241563601 $11.13

9A

241845301 Frigidaire Refrigerator Motor Mount Backorder WCI 241845301 $14.24

10

241726501 Frigidaire Refrigerator Drive Bar In Stock WCI 241726501 $36.57

10A

241719711 Frigidaire Refrigerator Evaporator Backorder WCI 241719711 $67.88

11

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $26.74

11

5304458400 Frigidaire Refrigerator Thermal Cu Backorder WCI 5304458400 $38.37

11

WCI 242178018 WCI 242178018 Contact Us For Availability

11A

WCI 241657602 WCI 241657602 Contact Us For Availability

11B

241657504 Frigidaire Refrigerator Shelf In Stock WCI 241657504 $51.59

11C

240324101 Frigidaire Refrigerator Pizza Shelf Backorder WCI 240324101 $35.20

12

242015201 Frigidaire Nameplate Backorder WCI 242015201 $2.66

13

241990201 Frigidaire Refrigerator Door Stop Backorder WCI 241990201 $13.37

13

5304456665 Frigidaire Refrigerator Thermostat In Stock WCI 5304456665 $78.01

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $79.70

13A

241990202 Frigidaire Refrigerator Door Stop A Backorder WCI 241990202 $13.37

14

242044113 Frigidaire Refrigerator Defrost Hea In Stock WCI 242044113 $64.35

14

242135301 Frigidaire Refrigerator Evaporator Backorder WCI 242135301 $4.89

14A

241547902 Frigidaire Refrigerator Light Switc In Stock WCI 241547902 $15.66

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

5303918284 Frigidaire Refrigerator Evaporator In Stock WCI 5303918284 $318.19

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $53.79

5304517886 Frigidaire Refrigerator Light In Stock WCI 5304517886 $44.95

WCI 242178116 WCI 242178116 Contact Us For Availability

16

241559801 Frigidaire Light Socket Refrigerato In Stock WCI 241559801 $44.52

16

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $37.02

16

5308000110 Frigidaire Refrigerator Evaporator Backorder WCI 5308000110 $38.80

17

241684503 Frigidaire Ice Crusher Blade In Stock WCI 241684503 $10.22

18

241930103 Frigidaire Door Handle Backorder WCI 241930103 $123.27

19

WCI 5304458378 WCI 5304458378 Contact Us For Availability

20

241675502 Frigidaire Refrigerator Motor Cover Backorder WCI 241675502 $82.76

21

5303918214 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918214 $14.53

21

5304458390 Frigidaire Refrigerator Ice Stripp Backorder WCI 5304458390 $33.76

21A

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $4.89

21D

218781101 Frigidaire Handle Screw In Stock WCI 218781101 $9.80

240597220 Frigidaire Sensor In Stock WCI 240597220 $2.95

241917801 Frigidaire Refrigerator Closer Plat In Stock WCI 241917801 $4.44

241990301 Frigidaire Hinge Bearing In Stock WCI 241990301 $4.44

WCI 5304458375 WCI 5304458375 Contact Us For Availability

22A

241990302 Frigidaire Freezer Hinge Bearing Backorder WCI 241990302 $4.44

22B

241760404 Frigidaire Refrigerator Bearing Backorder WCI 241760404 $8.02

22C

241760402 Frigidaire Refrigerator Bearing In Stock WCI 241760402 $12.01

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $26.72

241684001 Frigidaire Refrigerator Front Plate Backorder WCI 241684001 $90.46

241845401 Frigidaire Refrigerator Sensor Hous Backorder WCI 241845401 $8.46

242176502 Frigidaire Main Board Backorder WCI 242176502 $16.04

24

240350150 Frigidaire Shelf Backorder WCI 240350150 $99.89

24A

240355270 Frigidaire Spill Safe Glass Shelf F In Stock WCI 240355270 $96.46

25

240555002 Frigidaire Refrigerator Screw #8-32 Backorder WCI 240555002 $8.44

25

240599301 Frigidaire Refrigerator Crisper Dra In Stock WCI 240599301 $60.84

25

WCI 240491503 WCI 240491503 Contact Us For Availability

25A

240350903 Frigidaire Refrigerator Crisper Pan In Stock WCI 240350903 $57.31

25B

241969501 Frigidaire Refrigerator Meat Pan Co In Stock WCI 241969501 $59.94

26

240351061 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351061 $66.76

26

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $6.68

26

241697603 Frigidaire Defrost Pan Backorder WCI 241697603 $49.38

27

240351240 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351240 $114.51

28

240362201 Frigidaire Refrigerator Humidity Co Backorder WCI 240362201 $43.19

30

241941003 Frigidaire Refrigerator Starter Rel In Stock WCI 241941003 $55.10

33

241684802 Frigidaire Refrigerator Spacer Backorder WCI 241684802 $5.31

34

240405201 Frigidaire Refrigerator Grommet In Stock WCI 240405201 $12.46

34

241689802 Frigidaire Refrigerator Spacer Backorder WCI 241689802 $4.89

35A

241684303 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684303 $10.22

35B

241684203 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684203 $10.68

37

242161202 Frigidaire Refrigerator Trim-Cabine In Stock WCI 242161202 $4.89

37A

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $12.91

37B

241684108 Frigidaire Washer Poly V-Belt Backorder WCI 241684108 $12.91

37C

241684109 Frigidaire Ice Crusher Blade Backorder WCI 241684109 $12.91

38

241761301 Frigidaire Upper Bracket Hinge Backorder WCI 241761301 $40.99

38A

241761302 Frigidaire Refrigerator Upper Hinge Backorder WCI 241761302 $40.11

38C

5304527935 Frigidaire Refrigerator Grey User In Stock WCI 5304527935 $202.82

39A

WCI 240430706 WCI 240430706 Contact Us For Availability

39B

WCI 240430702 WCI 240430702 Contact Us For Availability

40

241946705 Frigidaire Refrigerator Upper Hinge Backorder WCI 241946705 $27.18

40

WCI 5304458401 WCI 5304458401 Contact Us For Availability

40A

241891901 Frigidaire Refrigerator Wiring Harn Backorder WCI 241891901 $16.48

40A

241946706 Frigidaire Refrigerator Upper Hinge Backorder WCI 241946706 $27.18

41

241550801 Frigidaire Refrigerator Shelf Mount Backorder WCI 241550801 $37.02

42

218515403 Frigidaire Refrigerator Grille Clip Backorder WCI 218515403 $18.26

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $8.89

43

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $9.35

43

241720601 Frigidaire Refrigerator Extension In Stock WCI 241720601 $12.90

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $14.68

45A

241675902 Frigidaire Refrigerator Solenoid Sp Backorder WCI 241675902 $4.00

45B

241676001 Frigidaire Refrigerator E-Ring Sole Backorder WCI 241676001 $43.62

45C

241676101 Frigidaire Refrigerator Solenoid-Ac Backorder WCI 241676101 $40.11

46

241716002 Frigidaire Refrigerator Control Rod Backorder WCI 241716002 $27.61

47

240350649 Frigidaire Refrigerator Glass Inser In Stock WCI 240350649 $64.95

47

241513001 Frigidaire Refrigerator Shelf Mount In Stock WCI 241513001 $65.25

47

241731801 Frigidaire Refrigerator Control Rod Backorder WCI 241731801 $8.91

47A

240350603 Frigidaire Glass Shelf Backorder WCI 240350603 $71.87

47B

240443384 Frigidaire Refrigerator Crisper Cov In Stock WCI 240443384 $85.72

48

241684602 Frigidaire Refrigerator Control Rod Backorder WCI 241684602 $66.58

49

240356402 Frigidaire Refrigerator Gallon Door In Stock WCI 240356402 $66.56

49

240564401 Frigidaire Refrigerator Sliding Bas Backorder WCI 240564401 $89.90

49

241734501 Frigidaire Refrigerator Rail Backorder WCI 241734501 $111.90

49B

WCI 240530504 WCI 240530504 Contact Us For Availability

50

241675601 Frigidaire Refrigerator Solenoid Gu Backorder WCI 241675601 $49.81

51

240343002 Frigidaire Hanger Basket Backorder WCI 240343002 $37.92

51

WCI 241676301 WCI 241676301 Contact Us For Availability

52

240343102 Frigidaire Basket Hanger Backorder WCI 240343102 $40.56

52

241684901 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684901 $17.83

53

241690402 Frigidaire Refrigerator Spiral Pin Backorder WCI 241690402 $12.01

54

241532401 Frigidaire Refrigerator Channel In Stock WCI 241532401 $19.14

54

241685001 Frigidaire Auger Nut Backorder WCI 241685001 $12.46

55

241690306 Frigidaire Refrigerator Washer Backorder WCI 241690306 $31.20

55

242252702 Frigidaire Refrigerator Water Inlet In Stock WCI 242252702 $44.28

55

297286803 Frigidaire Refrigerator Run Capacit In Stock WCI 297286803 $24.50

56

241690201 Frigidaire Refrigerator E-Ring Backorder WCI 241690201 $12.02

58

241548003 Frigidaire Refrigerator Screw In Stock WCI 241548003 $1.76

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $28.50

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.59

60

242018301 Frigidaire Refrigerator Condenser F In Stock WCI 242018301 $78.35

60

WCI 242010601 WCI 242010601 Contact Us For Availability

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.22

62

241969607 Frigidaire Refrigerator Meat Pan In Stock WCI 241969607 $120.36

66

241756801 Frigidaire Refrigerator Meat Keeper Backorder WCI 241756801 $16.48

66A

241756901 Frigidaire Refrigerator Damper Hous Backorder WCI 241756901 $19.15

72

241969403 Frigidaire Refrigerator Kickplate/G In Stock WCI 241969403 $48.50

74

218755402 Frigidaire Refrigerator Set Screw In Stock WCI 218755402 $4.00

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.44

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $8.91

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $30.30

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $22.66

85

241856909 Frigidaire Refrigerator Connector T Backorder WCI 241856909 $93.03

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $39.23

89

5304520905 Frigidaire Assembly Cover Refriger Backorder WCI 5304520905 $43.21

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.46

93

241911704 Frigidaire Refrigerator Switch Backorder WCI 241911704 $19.15

100

240326304 Frigidaire Refrigerator Cover Backorder WCI 240326304 $45.87

100

241993001 Frigidaire Refrigerator Left Crispe In Stock WCI 241993001 $5.44

100

241993101 Frigidaire Refrigerator Right Crisp In Stock WCI 241993101 $3.38

101

218493101 Frigidaire Refrigerator Screw In Stock WCI 218493101 $8.44

101

241953902 Frigidaire Refrigerator Screw In Stock WCI 241953902 $10.70

107

WCI 241753601 WCI 241753601 Contact Us For Availability

108

WCI 241753701 WCI 241753701 Contact Us For Availability

115

241853801 Frigidaire Refrigerator Damper Cont In Stock WCI 241853801 $95.17

120

241691901 Frigidaire Refrigerator Ice Cream S Backorder WCI 241691901 $46.28

121

241561001 Frigidaire Refrigerator Ice Cream S Backorder WCI 241561001 $59.08

122

241692001 Frigidaire Refrigerator Ice Cream S Backorder WCI 241692001 $49.79

126

241674401 Frigidaire Refrigerator Channel Backorder WCI 241674401 $29.87

126

241674402 Frigidaire Refrigerator Channel Backorder WCI 241674402 $27.18

139

242009602 Frigidaire Refrigerator Water Filte In Stock WCI 242009602 $37.08

208

241754301 Frigidaire Refrigerator Sleeve Backorder WCI 241754301 $24.07

210

241983812 Frigidaire Refrigerator Water Filte Backorder WCI 241983812 $46.25

210

241998303 Frigidaire Refrigerator Water Filte In Stock WCI 241998303 $6.51

210

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.35

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $8.89

218976419 Frigidaire Refrigerator Tube Backorder WCI 218976419 $14.26

218976429 Frigidaire Refrigerator Tube Backorder WCI 218976429 $25.41

240346701 Frigidaire Refrigerator Foam Seal T In Stock WCI 240346701 $18.70

240349801 Frigidaire Refrigerator Clip Backorder WCI 240349801 $12.04

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.22

240362101 Frigidaire Refrigerator Crisper Cov In Stock WCI 240362101 $27.61

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $8.00

240451503 Frigidaire Refrigerator Screw Backorder WCI 240451503 $2.22

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $12.91

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.67

241512807 Frigidaire Refrigerator Seal Backorder WCI 241512807 $1.76

241519401 Frigidaire Refrigerator Clip Backorder WCI 241519401 $5.31

241522901 Frigidaire Refrigerator Electrical Backorder WCI 241522901 $68.35

241550701 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550701 $10.68

241583301 Frigidaire Refrigerator Air Deflect Backorder WCI 241583301 $29.40

241587402 Frigidaire Refrigerator Ice Deflect Backorder WCI 241587402 $12.91

241595202 Frigidaire Refrigerator Clip Backorder WCI 241595202 $10.68

241781601 Frigidaire Refrigerator Air Return Backorder WCI 241781601 $5.31

241850615 Frigidaire Ice Maker Fill Tube Asse In Stock WCI 241850615 $21.83

241860810 Frigidaire Refrigerator Ice Contain In Stock WCI 241860810 $138.34

241945101 Frigidaire Refrigerator Air Duct In Backorder WCI 241945101 $12.48

241987601 Frigidaire Refrigerator Wiring Harn Backorder WCI 241987601 $66.11

242036801 Frigidaire Refrigerator Plastic Cli In Stock WCI 242036801 $59.94

242141102 Frigidaire Refrigerator Wiring Harn Backorder WCI 242141102 $111.18

242288101 Frigidaire Refrigerator Harness Backorder WCI 242288101 $196.65

5303918327 Frigidaire Refrigerator Heat Excha In Stock WCI 5303918327 $162.44

WCI 5303918222 WCI 5303918222 Contact Us For Availability

WCI 241519902 WCI 241519902 Contact Us For Availability
