Model Electrolux FGGF3045RFA RANGE/OVEN, GAS, FREESTANDING – Common Parts &amp; Diagrams

1

316408706 Frigidaire Oven Drawer Assembly In Stock WCI 316408706 $63.43

1

5304513540 Frigidaire Range Manifold Backorder WCI 5304513540 $58.69

1

SHIELD, REAR WALL WCI 316557600 Contact Us For Availability

2

316560900 Frigidaire Range Valve Backorder WCI 316560900 $52.43

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $15.85

2A

5303935308 Frigidaire Range Valve Backorder WCI 5303935308 $44.82

2B

5303935306 Frigidaire Range Valve In Stock WCI 5303935306 $51.10

2C

5303935305 Frigidaire Range Valve Backorder WCI 5303935305 $48.87

2D

5303935309 Frigidaire Top Burner Valve Backorder WCI 5303935309 $52.01

3

316580615 Frigidaire Range Spark Ignition Swi In Stock WCI 316580615 $49.53

4

316452722 Frigidaire Range Glass In Stock WCI 316452722 $159.83

4

5304494412 Frigidaire Range Panel Backorder WCI 5304494412 $58.21

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $3.61

6

316402316 Frigidaire Shield Backorder WCI 316402316 $52.43

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $57.70

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $45.72

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.88

8

316400603 Frigidaire Range Stove Bottom Panel In Stock WCI 316400603 $107.26

8

5304490938 Frigidaire Glide Assembly In Stock WCI 5304490938 $8.60

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

8

5304508269 Frigidaire Oven Range Spark Module In Stock WCI 5304508269 $62.29

9

316423807 Frigidaire Range Door Liner In Stock WCI 316423807 $98.56

9

PAN, BROILER WCI 316081900 Contact Us For Availability

10

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $49.31

10

5304507924 Frigidaire Oven Screw In Stock WCI 5304507924 $4.53

10

INSERT, BROILER PAN WCI 316082000 Contact Us For Availability

10A

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $36.24

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $50.46

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $33.50

10D

316559300 Frigidaire Range Burner Backorder WCI 316559300 $109.03

11

316536622 Frigidaire Igniter Orifice Assembly In Stock WCI 316536622 $109.52

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $58.42

11B

316536616 Frigidaire Igniter/Orifice Assembly Backorder WCI 316536616 $96.08

11C

316536602 Frigidaire Range Igniter/Orifice As In Stock WCI 316536602 $60.14

11D

316536623 Frigidaire Igniter/Orifice Assembly In Stock WCI 316536623 $90.89

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $38.11

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $9.04

12

5304498835 Frigidaire Range Seal In Stock WCI 5304498835 $63.63

13

316489101 Frigidaire Suppl Tube-Manifold Backorder WCI 316489101 $64.54

13

316604011 Frigidaire Panel Backorder WCI 316604011 $90.60

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $61.84

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

14

316572700 Frigidaire Range Nameplate In Stock WCI 316572700 $51.54

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $43.49

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

15

END CAP, BACKGUARD, BLACK, RH WCI 807437103 Contact Us For Availability

15A

END CAP, BACKGUARD, BLACK, LH WCI 807437104 Contact Us For Availability

16

316610014 Frigidaire Range Maintop Backorder WCI 316610014 $151.31

16

5304507348 Frigidaire Range Tube Backorder WCI 5304507348 $28.09

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

17

316031501 Frigidaire Range Valve In Stock WCI 316031501 $172.02

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $36.24

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.94

18

316404400 Frigidaire Range Burner Backorder WCI 316404400 $69.45

18

316405800 Frigidaire Assembly Latch In Stock WCI 316405800 $29.00

19

316572406 Frigidaire Control Panel Backorder WCI 316572406 $154.45

19

5304506545 Frigidaire Gas Oven Range Igniter In Stock WCI 5304506545 $72.30

316284102 Frigidaire Range Spacer Backorder WCI 316284102 $10.41

5304509231 Frigidaire Range Clock In Stock WCI 5304509231 $128.82

5304519024 Frigidaire Range Baffle In Stock WCI 5304519024 $47.49

807327101 Frigidaire Range Grate Assembly Backorder WCI 807327101 $145.79

20A

316419353 Frigidaire Oven Overlay In Stock WCI 316419353 $22.19

20A

807412601 Frigidaire Range Grate Backorder WCI 807412601 $143.66

21

Backorder WCI 154079601 $0.28

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.85

21

CAP, BACKGUARD, BLACK, TOP WCI 316546601 Contact Us For Availability

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.32

22

5304507768 Frigidaire Range Tube Backorder WCI 5304507768 $29.90

22

5304508468 Frigidaire Oven Cap Assembly In Stock WCI 5304508468 $29.53

22A

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.91

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $27.48

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $19.06

22D

316559604 Frigidaire Range Cap In Stock WCI 316559604 $45.70

23

316404302 Frigidaire Range Burner Backorder WCI 316404302 $65.86

23

316575906 Frigidaire Range Hinge Backorder WCI 316575906 $55.12

24

5304516894 Frigidaire Range Elbow Assembly Backorder WCI 5304516894 $51.54

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.99

25

5304497666 Frigidaire Range Baffle Backorder WCI 5304497666 $55.56

26

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $67.63

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $31.23

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.34

33

316402500 Frigidaire Range Shield Backorder WCI 316402500 $76.18

34

316499902 Frigidaire Range Griddle Backorder WCI 316499902 $143.26

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.23

36

5304502763 Frigidaire Range Knob In Stock WCI 5304502763 $51.99

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.23

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $39.37

39

316554010 Frigidaire Stainless Steel Handle In Stock WCI 316554010 $88.78

39

5304534377 Frigidaire Cord In Stock WCI 5304534377 $16.03

42

316416204 Frigidaire Range Trim Backorder WCI 316416204 $26.27

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

44

316527509 Frigidaire Oven 18.2K Burner Orific Backorder WCI 316527509 $12.65

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.48

44B

316527511 Frigidaire Oven Orifice Backorder WCI 316527511 $12.65

44C

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.65

47

GRLP4 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP4 $43.89

55

316408301 Frigidaire Range Bracket Backorder WCI 316408301 $3.62

56

316230708 Frigidaire Range Shield Backorder WCI 316230708 $38.99

58A

316403700 Frigidaire Insulation Backorder WCI 316403700 $176.57

58B

INSULATION, OVEN BACK WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $33.06

82

316400801 Frigidaire Range Shield Backorder WCI 316400801 $94.62

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $14.03

88

316232702 Frigidaire Rod Backorder WCI 316232702 $7.67

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $32.80

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $37.65

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $215.44

108

316256900 Frigidaire Range Fan Motor In Stock WCI 316256900 $114.35

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.38

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.20

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $6.32

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.23

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.60

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $9.04

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.60

5304494425 Frigidaire Range Harness Backorder WCI 5304494425 $51.08

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

NIA

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $4.97

NIA

316401500 Frigidaire Range Cover Backorder WCI 316401500 $7.67

NIA

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06
