Model Frigidaire FGF379WESP RANGE – Common Parts & Diagrams

*
Screw,cup pt ,#8-18 x 3/8 ,hinge ,ind lght br
Screw,cup pt ,#8-18 x 3/8 ,hinge ,ind lght br WCI 316021108 Contact Us For Availability
View on Model
1
Back-main
Back-main WCI 316029412 Contact Us For Availability
View on Model
2
Shield-oven top
Shield-oven top WCI 3131314 Contact Us For Availability
View on Model
2#
Valve-top burner
Valve-top burner WCI 5303935130 No Longer Available
View on Model
2A#
Valve-top burner,large ,(2)
Valve-top burner,large ,(2) WCI 5303935132 Contact Us For Availability
View on Model
3
Panel-bodyside,white ,RH
Panel-bodyside,white ,RH WCI 316081028 Contact Us For Availability
View on Model
3#
Switch-ignitor,(4)
Switch-ignitor,(4) WCI 316103600 Contact Us For Availability
View on Model
3*
Shield-insulation
Shield-insulation WCI 08067992 Contact Us For Availability
View on Model
3*
Panel-bodyside,white ,LH
Panel-bodyside,white ,LH WCI 316081029 Contact Us For Availability
View on Model
3*
Shield-heat,body side
Shield-heat,body side WCI 316088100 Contact Us For Availability
View on Model
4
Burner Box
Burner Box WCI 316011914 Contact Us For Availability
View on Model
4#
Tube-burner,red ,RF
Tube-burner,red ,RF WCI 316059612 Contact Us For Availability
View on Model
5
Leg-leveling,plastic w/stop
Leg-leveling,plastic w/stop WCI 316129200 Contact Us For Availability
View on Model
6#
Tube-burner,nat. ,RR
Tube-burner,nat. ,RR WCI 316059614 Contact Us For Availability
View on Model
7
Hinge-oven door,(2)
Hinge-oven door,(2) WCI 316007005 Contact Us For Availability
View on Model
8
Panel-oven bottom
Panel-oven bottom WCI 5303212540 Contact Us For Availability
View on Model
8*
Harness-wiring,module/igniter
Harness-wiring,module/igniter WCI 5303289034 Contact Us For Availability
View on Model
9
Pan-broiler
Pan-broiler WCI 316073800 Contact Us For Availability
View on Model
10
Insert-broiler pan
Insert-broiler pan WCI 3205234 Contact Us For Availability
View on Model
10#
Burner Assy-top,sealed ,small ,9000 BTU
Burner Assy-top,sealed ,small ,9000 BTU WCI 5303935025 Contact Us For Availability
View on Model
10A#
Burner Assy-top,sealed ,large ,
Burner Assy-top,sealed ,large , WCI 5303935075 Contact Us For Availability
View on Model
12#
Switch-oven light
Switch-oven light WCI 316027701 Contact Us For Availability
View on Model
13
Rod-light switch /door
Rod-light switch /door WCI 316026800 Contact Us For Availability
View on Model
13#
Tube,aluminum ,rgltr to manf , with fittings
Tube,aluminum ,rgltr to manf , with fittings WCI 316065005 Contact Us For Availability
View on Model
16#
Tube-valve to rgltr,3/8
Tube-valve to rgltr,3/8 WCI 316065003 Contact Us For Availability
View on Model
18#
Burner-oven
Burner-oven WCI 3131290 Contact Us For Availability
View on Model
18#
Latch-door
Latch-door WCI 316036300 Contact Us For Availability
View on Model
20
Baffle-oven burner
Baffle-oven burner WCI 3131284 Contact Us For Availability
View on Model
21
Spacer-bodyside,(8)
Spacer-bodyside,(8) WCI 3014099 Contact Us For Availability
View on Model
22#
Tube-valve to mixer
Tube-valve to mixer WCI 316065002 Contact Us For Availability
View on Model
23#
Burner-broiler
Burner-broiler WCI 316087900 Contact Us For Availability
View on Model
24#
Mixer Elbow
Mixer Elbow WCI 316070400 Contact Us For Availability
View on Model
25
Baffle-broiler
Baffle-broiler WCI 5303210379 Contact Us For Availability
View on Model
25A
Shield-warmer,upper
Shield-warmer,upper WCI 316092300 Contact Us For Availability
View on Model
28
Push Button,clock/timer/EOC ,gray
Push Button,clock/timer/EOC ,gray WCI 316015103 Contact Us For Availability
View on Model
28A
Shaft-push button,clock/timer/EOC , black
Shaft-push button,clock/timer/EOC , black WCI 316080600 No Longer Available
View on Model
30
Bracket-main top,RH
Bracket-main top,RH WCI 316059200 Contact Us For Availability
View on Model
30A
Bracket-main top,LH
Bracket-main top,LH WCI 316059201 Contact Us For Availability
View on Model
33
Shield,rear wall
Shield,rear wall WCI 316014401 Contact Us For Availability
View on Model
36
Flue
Flue WCI 5303272844 Contact Us For Availability
View on Model
38
Shield-heat
Shield-heat WCI 316051700 Contact Us For Availability
View on Model
38A
Insulator,shield
Insulator,shield WCI 316097100 Contact Us For Availability
View on Model
39*
Fastener-power cord
Fastener-power cord WCI 08067961 Contact Us For Availability
View on Model
40
Shield-heat baffle
Shield-heat baffle WCI 3200836 Contact Us For Availability
View on Model
40*
Screw-heat shield,hd shldr sqdr ,
Screw-heat shield,hd shldr sqdr , WCI 5303288570 Contact Us For Availability
View on Model
41
Cover-hinge cutout
Cover-hinge cutout WCI 3131570 Contact Us For Availability
View on Model
42
Shield-bake burner
Shield-bake burner WCI 5303288578 No Longer Available
View on Model
44
Orifice-top burner,small
Orifice-top burner,small WCI 5303210090 No Longer Available
View on Model
45
Screw-ignitor mtg,self-tapping ,M3x5.8
Screw-ignitor mtg,self-tapping ,M3x5.8 WCI 316011100 Contact Us For Availability
View on Model
46
Plate-burner tube
Plate-burner tube WCI 316074700 Contact Us For Availability
View on Model
47
LP Conversion Kit
LP Conversion Kit WCI 5303307190 Contact Us For Availability
View on Model
53
Shield-main front
Shield-main front WCI 5303288579 Contact Us For Availability
View on Model
58A
Insulation,oven wrapper
Insulation,oven wrapper WCI 316047705 Contact Us For Availability
View on Model
58B
Insulation, 2" ,oven back
Insulation, 2" ,oven back WCI 316054200 Contact Us For Availability
View on Model
58C
Insulation,oven top
Insulation,oven top WCI 3131304 Contact Us For Availability
View on Model
72
Cover-light/switch rod
Cover-light/switch rod WCI 5303285692 Contact Us For Availability
View on Model
