Model Electrolux FGEF3036TDB RANGE/OVEN, ELECTRIC, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

2

5304527989 Frigidaire Liner Backorder WCI 5304527989 $17.20

3

5303935377 Frigidaire Door Trim Kit In Stock WCI 5303935377 $36.74

4

316355602 Frigidaire Glass In Stock WCI 316355602 $139.94

4

5304516891 Frigidaire Range Panel Backorder WCI 5304516891 $90.73

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $3.61

6

316406328 Frigidaire Shield Backorder WCI 316406328 $51.52

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $57.70

7

316405600 Frigidaire Insulation Backorder WCI 316405600 $48.41

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.88

8

PANEL, OVEN BOTTOM WCI 316400601 No Longer Available

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

8

807047202 Frigidaire Range Glide Assembly Backorder WCI 807047202 $7.69

8A

BASE, BAKE ELEMENT WCI 316411106 Contact Us For Availability

9

LINER, OVEN DOOR WCI 316423707 No Longer Available

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

10

5304507924 Frigidaire Oven Screw In Stock WCI 5304507924 $4.53

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

12

316405000 Frigidaire Oven Seal In Stock WCI 316405000 $89.27

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $38.11

13A

5304508926 Frigidaire Oven Temperature Contro In Stock WCI 5304508926 $49.76

14

316022500 Frigidaire Oven Warmer Drawer Zone In Stock WCI 316022500 $36.24

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $64.96

15

5304493644 Frigidaire Range Cap Backorder WCI 5304493644 $39.44

15A

316530001 Frigidaire Oven Element In Stock WCI 316530001 $132.12

15A

5304493646 Frigidaire Range Cap In Stock WCI 5304493646 $39.44

15B

316282103 Frigidaire Range Element In Stock WCI 316282103 $169.09

15C

140273621015 Frigidaire Warmer Element, Radia Backorder WCI 140273621015 $22.85

16

5304509324 Frigidaire Range Main Top Backorder WCI 5304509324 $405.30

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

16

GLASS, DOOR, AIRWASH WCI 316552800 Contact Us For Availability

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $36.24

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.94

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $29.00

18

316580800 Frigidaire Hinge Bracket Backorder WCI 316580800 $5.88

19

PANEL, BACKGUARD, BLACK STAINLESS WCI 5304509317 Contact Us For Availability

20

5304511270 Frigidaire Range Clock In Stock WCI 5304511270 $222.20

20

SPACER, DOOR, RH WCI 316353002 Contact Us For Availability

20A

316419378 Frigidaire Range Overlay Backorder WCI 316419378 $14.48

20A

SPACER, DOOR, LH WCI 316353003 Contact Us For Availability

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.85

21

316533801 Frigidaire Oven Plate Backorder WCI 316533801 $3.59

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.32

23

316575908 Frigidaire Range Hinge Assembly Backorder WCI 316575908 $91.30

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.99

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $31.23

28

316528700 Frigidaire Insulation Assembly Backorder WCI 316528700 $56.46

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.34

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $42.27

39

316554009 Frigidaire Oven Handle Backorder WCI 316554009 $114.26

40

316552401 Frigidaire Range Bracket Backorder WCI 316552401 $17.21

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

46

316557300 Frigidaire Range Indicator Light Le In Stock WCI 316557300 $6.67

51

316355300 Frigidaire Insulation Backorder WCI 316355300 $4.53

52

316461700 Frigidaire Oven Clip Assembly In Stock WCI 316461700 $7.65

52

5304520272 Frigidaire Top Cap Backorder WCI 5304520272 $105.52

54

316436000 Frigidaire Range Surface Element Sw In Stock WCI 316436000 $46.51

54A

316530101 Frigidaire Range Switch Assembly Backorder WCI 316530101 $87.26

54B

316238201 Frigidaire Range Switch In Stock WCI 316238201 $57.14

56

316234045 Frigidaire Oven Shield Backorder WCI 316234045 $39.43

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $7.25

58

316403802 Frigidaire Insulation Backorder WCI 316403802 $69.91

58A

316406602 Frigidaire Insulation Backorder WCI 316406602 $76.66

58B

316406500 Frigidaire Insulation Backorder WCI 316406500 $56.04

59

316208401 Frigidaire Range VentTube Backorder WCI 316208401 $111.62

59A

316208304 Frigidaire Oven Tube Backorder WCI 316208304 $50.64

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $48.94

63

5304536404 Frigidaire Strap Backorder WCI 5304536404 $1.29

66

316203301 Frigidaire Oven Broil Element In Stock WCI 316203301 $99.47

67

316413800 Frigidaire Oven Range Bake Element In Stock WCI 316413800 $137.91

68

316404002 Frigidaire Support Assembly Backorder WCI 316404002 $5.21

71

316283204 Frigidaire Range Shield Backorder WCI 316283204 $33.50

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $14.03

87

316081200 Frigidaire Oven Bracket Backorder WCI 316081200 $47.97

88

316203500 Frigidaire Oven Rod Backorder WCI 316203500 $45.72

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $32.80

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $37.65

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $215.44

108

316256100 Frigidaire Range Fan Motor In Stock WCI 316256100 $138.12

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.38

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.20

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.23

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.60

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.60

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $3.61

WCI 316580267 WCI 316580267 Contact Us For Availability

HARNESS, SURFACE UNITS WCI 5304511285 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

316247300 Frigidaire Oven Catalyst Backorder WCI 316247300 $62.72

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06

5308014215 Frigidaire Oven Screw In Stock WCI 5308014215 $1.35

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $7.25

NIC

316542203 Frigidaire Insulator Backorder WCI 316542203 $4.97
