Model Electrolux FGC6X7XETA COOK-TOP – Common Parts & Diagrams

*48364
WCI 318054000
WCI 318054000 WCI 318054000 Contact Us For Availability
View on Model
*48366
WCI 318065000
WCI 318065000 WCI 318065000 Contact Us For Availability
View on Model
*48368
WCI 5303320671
WCI 5303320671 WCI 5303320671 Contact Us For Availability
View on Model
1
WCI 318077910
WCI 318077910 WCI 318077910 Contact Us For Availability
View on Model
2A
VALVE-TOP BURNER, 2-POSITION, (3)
VALVE-TOP BURNER, 2-POSITION, (3) WCI 5303935042 Contact Us For Availability
View on Model
2C
VALVE-TOP BURNER, LARGE, W/SCREW
VALVE-TOP BURNER, LARGE, W/SCREW WCI 316036801 Contact Us For Availability
View on Model
3
SWITCH-IGNITER, (4)
SWITCH-IGNITER, (4) WCI 316032002 Contact Us For Availability
View on Model
4
WCI 318054604
WCI 318054604 WCI 318054604 Contact Us For Availability
View on Model
5
WCI 318054605
WCI 318054605 WCI 318054605 Contact Us For Availability
View on Model
10
BURNER ASSY-TOP, SEALED, 9000 BTU (1) (INCLUD
BURNER ASSY-TOP, SEALED, 9000 BTU (1) (INCLUD WCI 318055001 Contact Us For Availability
View on Model
10
WCI 318055100
WCI 318055100 WCI 318055100 Contact Us For Availability
View on Model
13
WCI 318054504
WCI 318054504 WCI 318054504 Contact Us For Availability
View on Model
20
WCI 318120002
WCI 318120002 WCI 318120002 Contact Us For Availability
View on Model
21
TRIM RING, ALMOND, (3)
TRIM RING, ALMOND, (3) WCI 318050501 Contact Us For Availability
View on Model
21
TRIM RING, ALMOND, LARGE
TRIM RING, ALMOND, LARGE WCI 318050601 Contact Us For Availability
View on Model
22
WCI 318142000
WCI 318142000 WCI 318142000 Contact Us For Availability
View on Model
22
WCI 318142010
WCI 318142010 WCI 318142010 Contact Us For Availability
View on Model
33
WCI 318090400
WCI 318090400 WCI 318090400 Contact Us For Availability
View on Model
33A
BRACKET-BURNER MTG, (4)
BRACKET-BURNER MTG, (4) WCI 318072000 Contact Us For Availability
View on Model
35
WCI 5303307978
WCI 5303307978 WCI 5303307978 Contact Us For Availability
View on Model
43
WCI 318016508
WCI 318016508 WCI 318016508 Contact Us For Availability
View on Model
44A
ORIFICE-TOP BURNER, 9000 BTU, SMALL
ORIFICE-TOP BURNER, 9000 BTU, SMALL WCI 318088700 Contact Us For Availability
View on Model
44B
WCI 3138088702
WCI 3138088702 WCI 3138088702 Contact Us For Availability
View on Model
45
WCI 316011100
WCI 316011100 WCI 316011100 Contact Us For Availability
View on Model
45B
BUSHING, TOP BURNER KNOB (NOT ILLUSTRATED)
BUSHING, TOP BURNER KNOB (NOT ILLUSTRATED) WCI 5303307933 Contact Us For Availability
View on Model
46
WCI 318077100
WCI 318077100 WCI 318077100 Contact Us For Availability
View on Model
47
WCI 5303303991
WCI 5303303991 WCI 5303303991 Contact Us For Availability
View on Model
47
LP CONVERSION KIT, 5 BURNER
LP CONVERSION KIT, 5 BURNER WCI 5303319611 Contact Us For Availability
View on Model
50B
BURNER-TOP, SMALL, (3), INCLUDES 37
BURNER-TOP, SMALL, (3), INCLUDES 37 WCI 5303935026 Contact Us For Availability
View on Model
61
TRIM RING, CHROME, (3), SMALL
TRIM RING, CHROME, (3), SMALL WCI 318083900 Contact Us For Availability
View on Model
61
TRIM RING, CHROME, LARGE
TRIM RING, CHROME, LARGE WCI 318083901 Contact Us For Availability
View on Model
