Model Electrolux FEF385CCTA RANGE – Common Parts &amp; Diagrams

*67846

WCI 316001175 WCI 316001175 Contact Us For Availability

*67847

WCI 5303281379 WCI 5303281379 Contact Us For Availability

*67848

WCI 5303281584 WCI 5303281584 Contact Us For Availability

*67850

WCI 316065301 WCI 316065301 Contact Us For Availability

*67851

SCREW, CR PAN HD SEMS, 8-32BP X 1.00 WCI 5303212671 Contact Us For Availability

*67852

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $8.89

*67853

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $8.44

*67854

WCI 5303280311 WCI 5303280311 Contact Us For Availability

*67855

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.46

*67856

131243700 Frigidaire Screw In Stock WCI 131243700 $2.02

1

WCI 316029410 WCI 316029410 Contact Us For Availability

1

DRAWER-UTILITY WCI 316011501 Contact Us For Availability

2

WCI 3131975 WCI 3131975 Contact Us For Availability

3

LAMP-FLUORESCENT, BACKGUARD WCI 3131275 Contact Us For Availability

3

WCI 316081006 WCI 316081006 Contact Us For Availability

3

WCI 316081007 WCI 316081007 Contact Us For Availability

3

WCI 316067803 WCI 316067803 Contact Us For Availability

3A

SHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED) WCI 3200834 Contact Us For Availability

3B

FASTENER-EDGE MTG (NOT ILLUSTRATED) WCI 3200846 Contact Us For Availability

4

SCREW, HEX WASHER HEAD, 8-18(AB) X 1/2 (NOT I WCI 08067785 Contact Us For Availability

4

WCI 5303271756 WCI 5303271756 Contact Us For Availability

4

WCI 316056206 WCI 316056206 Contact Us For Availability

4

WCI 316019712 WCI 316019712 Contact Us For Availability

5

GLASS-OVEN DOOR, INNER WCI 5303209513 Contact Us For Availability

5A

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

5B

WCI 3934058 WCI 3934058 Contact Us For Availability

5C

316116000 Frigidaire Screw Backorder WCI 316116000 $7.55

5D

NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED) WCI 5303288460 Contact Us For Availability

6

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $63.90

6

STARTER-LAMP WCI 3206218 Contact Us For Availability

6

WCI 316085400 WCI 316085400 Contact Us For Availability

6

SHIELD-INSULATION, ALMOND WCI 5303291032 Contact Us For Availability

7

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $2.33

7

WCI 316007002 No Longer Available

7

WCI 316076400 WCI 316076400 Contact Us For Availability

8

PANEL-OVEN BOTTOM WCI 3203540 Contact Us For Availability

9

WCI 316073800 WCI 316073800 Contact Us For Availability

9

WCI 316066603 WCI 316066603 Contact Us For Availability

10

SCREW-OVEN DOOR, WASHER HEAD, 10-24 X 1.81 WCI 316001002 Contact Us For Availability

10

WCI 316073900 WCI 316073900 Contact Us For Availability

12

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $199.68

12

SWITCH-OVEN LIGHT, DOOR FRAME WCI 316027701 Contact Us For Availability

13

WCI 316026800 WCI 316026800 Contact Us For Availability

316022503 Frigidaire Light Lamp P-1 Backorder WCI 316022503 $43.64

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $36.58

5303208655 Frigidaire Reflector Assembly Backorder WCI 5303208655 $36.13

REFLECTOR, ALUMINUM FOIL WCI 3131361 Contact Us For Availability

316442301 Frigidaire Oven 8 Coil Element 2600 In Stock WCI 316442301 $15.95

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

318372211 Frigidaire Oven 6" Electric Range B In Stock WCI 318372211 $12.96

BRACKET-GLASS MTG WCI 5303209510 Contact Us For Availability

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $8.02

16

GLASS-OVEN DOOR, HEAT BARRIER, (2) WCI 5303209512 Contact Us For Availability

16

WCI 316020908 WCI 316020908 Contact Us For Availability

17

316057601 Frigidaire Oven Rod Backorder WCI 316057601 $40.13

17

RETAINER-GLASS WCI 3204585 Contact Us For Availability

17

WCI 5303209517 WCI 5303209517 Contact Us For Availability

WCI 316036300 WCI 316036300 Contact Us For Availability

HINGE-MAIN TOP (RH) WCI 5303273062 Contact Us For Availability

HINGE-MAIN TOP (LH) WCI 5303273063 Contact Us For Availability

SEAL-ROPE, 0.25 DIA WCI 5303211085 Contact Us For Availability

19

WCI 316048409 WCI 316048409 Contact Us For Availability

19

WCI 316048412 WCI 316048412 Contact Us For Availability

19

WCI 316067600 WCI 316067600 Contact Us For Availability

21

SPACER-BODYSIDE, (8) WCI 3014099 Contact Us For Availability

25

WCI 3200848 WCI 3200848 Contact Us For Availability

27

5303935058 Frigidaire Oven Burner Receptacle In Stock WCI 5303935058 $4.05

28

5303017715 Frigidaire Medallion Backorder WCI 5303017715 $37.47

28

WCI 5303296595 WCI 5303296595 Contact Us For Availability

29

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $1.73

30

BRACKET-HINGE, MAIN TOP RH WCI 5303283574 Contact Us For Availability

30

BRACKET-HINGE, MAIN TOP, LH WCI 5303283575 Contact Us For Availability

36

WCI 316025107 WCI 316025107 Contact Us For Availability

37

5304497424 Frigidaire Oven Temperature Sensor In Stock WCI 5304497424 $21.37

39

WCI 316026104 WCI 316026104 Contact Us For Availability

39

WCI 316060204 WCI 316060204 Contact Us For Availability

40

316058601 Frigidaire Oven Clip Backorder WCI 316058601 $7.11

41

WCI 3131570 WCI 3131570 Contact Us For Availability

44

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $32.52

55

WCI 3051368 WCI 3051368 Contact Us For Availability

57

COVER-ACCESS WCI 3203405 Contact Us For Availability

316403803 Frigidaire Insulation Backorder WCI 316403803 $27.63

INSULATION, OVEN TOP WCI 3131304 Contact Us For Availability

WCI 316054201 WCI 316054201 Contact Us For Availability

INSULATION, OVEN WRAPPER WCI 3200833 Contact Us For Availability

59

WCI 316073600 WCI 316073600 Contact Us For Availability

60

WCI 5303288574 WCI 5303288574 Contact Us For Availability

62

5304409888 Frigidaire Oven Terminal Block Ass In Stock WCI 5304409888 $16.01

63

PLATE-GROUND STRAP WCI 5303212739 Contact Us For Availability

66

5303051140 Frigidaire Broil Element Backorder WCI 5303051140 $119.12

67

316075103 Frigidaire Oven Bake Element In Stock WCI 316075103 $14.21

68

316203400 Frigidaire Oven Support Backorder WCI 316203400 $39.21

71

SHIELD, REAR WALL, REAR WALL WCI 316015803 Contact Us For Availability

72

COVER-LIGHT/SWITCH ROD WCI 5303285692 Contact Us For Availability

82

SHIELD, OVEN BOTTOM WCI 3200825 Contact Us For Availability

87

WCI 5303206618 WCI 5303206618 Contact Us For Availability

88

WCI 316026400 WCI 316026400 Contact Us For Availability

89

WCI 316028101 WCI 316028101 Contact Us For Availability

105

WCI 316071900 WCI 316071900 Contact Us For Availability

106

WCI 316026601 WCI 316026601 Contact Us For Availability

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $222.73

108A

WCI 316049401 WCI 316049401 Contact Us For Availability

108B

WCI 316021106 WCI 316021106 Contact Us For Availability

109

WCI 316054500 WCI 316054500 Contact Us For Availability

110

WCI 316054600 WCI 316054600 Contact Us For Availability

111

WCI 316054700 WCI 316054700 Contact Us For Availability

112

WCI 316082700 WCI 316082700 Contact Us For Availability
