Model Electrolux FDPC4221AW1A DISHWASHER, BUILT-IN, 24 INCH – Common Parts &amp; Diagrams

1

SPRING, DOOR, (2) WCI 154430501 Contact Us For Availability

1A

154325201 Frigidaire Linkage Spring In Stock WCI 154325201 $16.47

2

154093301 Frigidaire Dishwasher ARM Assembly In Stock WCI 154093301 $1.35

2

154465101 Frigidaire Dishwasher Heating Eleme Backorder WCI 154465101 $7.25

2

154662601 Frigidaire Door Strike Latch In Stock WCI 154662601 $25.37

2

BASKET, SILVERWARE WCI 5304509753 Contact Us For Availability

3

COUNTERBALANCE ARM, KIT, LH & RH, W/SCREWS-NU WCI 5304513274 Contact Us For Availability

3

VALVE, WATER INLET WCI 5304525044 Contact Us For Availability

3

PC BOARD, CONTROL, GEM K4 WCI 5304525200 Contact Us For Availability

4

808326801 Frigidaire Dishwasher Screw Backorder WCI 808326801 $1,679.98

4

BRACE, FRONT FRAME WCI 5304508587 Contact Us For Availability

6

5303943103 Frigidaire Dishwasher P-1 Screw Ki Backorder WCI 5303943103 $11.32

7

LINER ASSEMBLY, DOOR, W/WIPER, & REINFORCEMEN WCI 5304520007 Contact Us For Availability

8

154745501 Frigidaire Dishwasher Toekick Plate In Stock WCI 154745501 $13.59

8

PC BOARD, TACTILE SWITCH WCI 5304525208 Contact Us For Availability

9

5304501482 Frigidaire Dishwasher Kick Plate A In Stock WCI 5304501482 $32.62

9

5304506521 Frigidaire Dishwasher Dispenser In Stock WCI 5304506521 $53.40

10

154103702 Frigidaire Dishwasher Screw Backorder WCI 154103702 $8.60

10

807145201 Frigidaire Dishwasher Cover-Volute In Stock WCI 807145201 $10.85

10

SCREW, PHILLIPS HEAD, WHITE WCI 154371301 Contact Us For Availability

11

154200701 Frigidaire Dishwasher Screw Backorder WCI 154200701 $8.60

11

807111601 Frigidaire Sump Cover and Filter In Stock WCI 807111601 $11.32

12

LATCH ASSEMBLY, SERVICE KIT, WHITE, W/CONNECT WCI 5304525220 Contact Us For Availability

13

154246801 Frigidaire Dishwasher Primary Gaske Backorder WCI 154246801 $31.71

14

154728201 Frigidaire Dishwasher Sump Assembly In Stock WCI 154728201 $39.44

15

LEG, LEVELING, 1/4-20 WCI 5304506540 Contact Us For Availability

16

RETAINER, SUMP WCI 154246502 Contact Us For Availability

20

154758501 Frigidaire Power Cord Cover In Stock WCI 154758501 $12.67

20

154829001 Frigidaire Dishwasher Door Assembly Backorder WCI 154829001 $87.63

21

154754701 Frigidaire Dishwasher Screw Backorder WCI 154754701 $2.26

22

5300809968 Frigidaire Dishwasher P-1 Washer Backorder WCI 5300809968 $27.18

22

TUBING, INLET WATER WCI 5304523457 Contact Us For Availability

24

807117001 Frigidaire Dishwasher Drain Hose In Stock WCI 807117001 $21.49

24

SPRAY ARM, BLUE, LOWER, W/HEAT SHIELD WCI 5304517203 Contact Us For Availability

24A

5304506740 Frigidaire Dishwasher Spray Arm Ce In Stock WCI 5304506740 $24.98

24B

NOZZLE, SHOWER, ASSEMBLY WCI 154754302 Contact Us For Availability

28

154773201 Frigidaire Dishwasher Switch Assemb In Stock WCI 154773201 $35.33

29

THERMOSTAT, SERVICE KIT, HIGH LIMIT, W/CONNEC WCI 5304525221 Contact Us For Availability

30

154241101 Frigidaire Dishwasher Retainer Backorder WCI 154241101 $2.26

32A

154406401 Frigidaire Delivery Tube Gasket In Stock WCI 154406401 $5.45

33

154553501 Frigidaire Dishwasher Gasket Backorder WCI 154553501 $27.05

49

5304500204 Frigidaire Gasket Bottom Door Seal In Stock WCI 5304500204 $16.54

51

CLAMP, DRIP LOOP, WIRE WCI 154320301 Contact Us For Availability

58

154246402 Frigidaire Dishwasher P-1 Ball Asse Backorder WCI 154246402 $35.78

61

5304506517 Frigidaire Dishwasher Grommet Asse In Stock WCI 5304506517 $9.95

70

MOTOR & PUMP ASSY, LEILI, W/O-RINGS WCI 5304519906 Contact Us For Availability

154294701 Frigidaire Dishwasher Screw Backorder WCI 154294701 $5.86

154380601 Frigidaire Dishwasher Clamp Assembl In Stock WCI 154380601 $46.60

154647101 Frigidaire Dishwasher Pin Hinge Backorder WCI 154647101 $9.06

154686401 Frigidaire Dishwasher Bearing Backorder WCI 154686401 $6.79

154753101 Frigidaire Dishwasher Thermistor In Stock WCI 154753101 $15.83

154783101 Frigidaire Dishwasher Screw Backorder WCI 154783101 $4.51

BRACKET KIT, COUNTERTOP MTG, W/SCRWS & INSTR WCI 154406801 Contact Us For Availability

154106202 Frigidaire Dishwasher Heater Nut In Stock WCI 154106202 $4.88

154297701 Frigidaire Dishwasher Screw Backorder WCI 154297701 $8.60

154491101 Frigidaire Dishwasher Screw Backorder WCI 154491101 $2.26

154754901 Frigidaire Dishwasher Screw In Stock WCI 154754901 $2.70

154779601 Frigidaire Dishwasher Screw Backorder WCI 154779601 $0.87

807048001 Frigidaire Dishwasher Check Valve In Stock WCI 807048001 $5.88

NIB

154289801 Frigidaire Dishwasher Shield Backorder WCI 154289801 $4.97

NIB

154741501 Frigidaire Dishwasher Screw Backorder WCI 154741501 $8.60
