Electrolux FCRG3051ASA RANGE/OVEN, GAS, FREESTANDING, 30 INCH Parts List

1

DRAWER, UTILITY WCI 316408706 Contact Us For Availability

View on Model

1

WCI 316281802 WCI 316281802 Contact Us For Availability

View on Model

2A

VALVE, TOP BURNER, BLACK STEM, 500BTU WCI 5304506547 Contact Us For Availability

View on Model

2B

5304506549 Frigidaire Range Valve In Stock WCI 5304506549 $41.69

View on Model

2C

5304506548 Frigidaire Range Valve In Stock WCI 5304506548 $48.87

View on Model

4

PANEL, DRAWER, STAINLESS WCI 5304510527 Contact Us For Availability

View on Model

4

GLASS, OVEN DOOR, BLACK, W/FOIL WCI 316452754 Contact Us For Availability

View on Model

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

View on Model

5A

LEVELING LEG ASSY, METAL, FRONT, (2), BRACKET WCI 5304509869 Contact Us For Availability

View on Model

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $57.70

View on Model

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $45.72

View on Model

8

316400603 Frigidaire Range Stove Bottom Panel In Stock WCI 316400603 $107.26

View on Model

8

808608802 Frigidaire Range Spark Ignition Fou In Stock WCI 808608802 $52.45

View on Model

9

316423807 Frigidaire Range Door Liner In Stock WCI 316423807 $98.56

View on Model

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

View on Model

10

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $36.24

View on Model

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

View on Model

10B

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $49.31

View on Model

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $33.50

View on Model

10D

316438000 Frigidaire Sealed Burner 12K Assemb Backorder WCI 316438000 $42.87

View on Model

11

316536621 Frigidaire Igniter and Orifice Asse Backorder WCI 316536621 $89.54

View on Model

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $58.42

View on Model

11B

316536602 Frigidaire Range Igniter/Orifice As In Stock WCI 316536602 $60.14

View on Model

11C

316536612 Frigidaire Igniter Assembly/Orifice Backorder WCI 316536612 $73.66

View on Model

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $9.04

View on Model

12

5304498835 Frigidaire Range Seal In Stock WCI 5304498835 $63.63

View on Model

13

316489100 Frigidaire Range Tube Backorder WCI 316489100 $49.29

View on Model

13

GLIDE, DRAWER, BLACK, RH INNER WCI 5304517905 Contact Us For Availability

View on Model

13

PANEL, OVEN DOOR, STAINLESS WCI 316604001 Contact Us For Availability

View on Model

13A

GLIDE, DRAWER, BLACK, LH INNER WCI 5304517903 Contact Us For Availability

View on Model

14

RECEPTACLE, OVEN LIGHT WCI 316116400 Contact Us For Availability

View on Model

14

GLIDE, DRAWER, BLACK, RH OUTER WCI 5304517904 Contact Us For Availability

View on Model

14A

GLIDE, DRAWER, BLACK, LH OUTER WCI 5304517902 Contact Us For Availability

View on Model

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $43.49

View on Model

15

5304493644 Frigidaire Range Cap Backorder WCI 5304493644 $39.44

View on Model

15A

5304493646 Frigidaire Range Cap In Stock WCI 5304493646 $39.44

View on Model

16

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

View on Model

16

TUBE, VALVE TO REGUL, 3/8 WCI 316065006 Contact Us For Availability

View on Model

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.94

View on Model

17

WCI 316572800 WCI 316572800 Contact Us For Availability

View on Model

17

RETAINER, LENS WCI 316087500 Contact Us For Availability

View on Model

18

316404400 Frigidaire Range Burner Backorder WCI 316404400 $69.45

View on Model

19

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $67.63

View on Model

19

PANEL, BACKGUARD, STAINLESS WCI 5304509065 Contact Us For Availability

View on Model

20

807327101 Frigidaire Range Grate Assembly Backorder WCI 807327101 $145.79

View on Model

20

WCI 5304521341 WCI 5304521341 Contact Us For Availability

View on Model

20

BAFFLE, OVEN BURNER WCI 5304519024 Contact Us For Availability

View on Model

20

SPACER, DOOR HANDLE, (2) WCI 316284102 Contact Us For Availability

View on Model

20A

807412601 Frigidaire Range Grate Backorder WCI 807412601 $143.66

View on Model

20A

OVERLAY, CLOCK, BLACK WCI 316220729 Contact Us For Availability

View on Model

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.85

View on Model

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.32

View on Model

23

316575906 Frigidaire Range Hinge Backorder WCI 316575906 $55.12

View on Model

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.99

View on Model

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $31.23

View on Model

33

SHIELD, REAR WALL WCI 316405900 Contact Us For Availability

View on Model

35

WCI 316542102 WCI 316542102 Contact Us For Availability

View on Model

36

KNOB, TOP VALVE, BLACK WCI 5304507386 Contact Us For Availability

View on Model

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $39.37

View on Model

37

SCREW, ASSY MTG, (8), IGNITOR/ORIFICE WCI 316240600 Contact Us For Availability

View on Model

42

DEFLECTOR, BACKGUARD WCI 808754601 Contact Us For Availability

View on Model

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

View on Model

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

View on Model

44

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.65

View on Model

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.48

View on Model

44B

316527508 Frigidaire Range Orifice Assembly Backorder WCI 316527508 $11.78

View on Model

44C

316527502 Frigidaire Oven Orifice Backorder WCI 316527502 $14.50

View on Model

47

GRLP4 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP4 $43.89

View on Model

55

BRACKET, GLASS SUPPORT, (4) WCI 316408301 Contact Us For Availability

View on Model

56

SHIELD, BACKGUARD, INNER WCI 316230708 Contact Us For Availability

View on Model

58G

INSULATION, MAIN FRONT WCI 08067973 Contact Us For Availability

View on Model

66

WCI 5304521340 WCI 5304521340 Contact Us For Availability

View on Model

82

316400801 Frigidaire Range Shield Backorder WCI 316400801 $94.62

View on Model

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $14.03

View on Model

NI

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $1.83

View on Model

NI

316210800 Frigidaire Button Plug Backorder WCI 316210800 $6.80

View on Model

NI

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $9.04

View on Model

NI

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

View on Model

NI

SCREW, HEX HEAD CUP PT, 8-18 X 0.375, BLACK WCI 316021105 Contact Us For Availability

View on Model

NI

SCREW, WAFER HEAD, 8-32T X 0.500, BLACK, 44* WCI 5303285179 Contact Us For Availability

View on Model

NI

SCREW, 10-16 X .486 WCI 316089500 Contact Us For Availability

View on Model

NI

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

View on Model

NI

WCI 5303288566 WCI 5303288566 Contact Us For Availability

View on Model

NIA

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

View on Model

NIA

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06

View on Model

NIA

HANDLE INSERT, DRAWER WCI 5304511879 Contact Us For Availability

View on Model
