Model Electrolux EI32AF80QSE FREEZER, UPRIGHT, W/ICE MAKER – Common Parts &amp; Diagrams

1

5300083897 Frigidaire Refrigerator Condenser In Stock WCI 5300083897 $389.21

1

5304505782 Frigidaire Refrigerator Door Gaske In Stock WCI 5304505782 $123.27

2

297345201 Frigidaire Freezer Icemaker In Stock WCI 297345201 $144.11

2

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

3

216503100 Frigidaire Refrigerator Drain Scree Backorder WCI 216503100 $38.53

5

297325503 Frigidaire Freezer Wiring Harness Backorder WCI 297325503 $67.78

6

297200900 Frigidaire Refrigerator Breaker Kit Backorder WCI 297200900 $43.91

8

BUSHING, MOTOR MTG., (2) WCI 5304495760 Contact Us For Availability

9

297200100 Frigidaire Refrigerator W/Corner Br In Stock WCI 297200100 $36.75

9

297280801 Frigidaire Refrigerator Inner Door Backorder WCI 297280801 $126.31

11

PANEL-OUTER DOOR, STAINLESS WCI 297329321 Contact Us For Availability

12

241873301 Frigidaire Refrigerator Nameplate In Stock WCI 241873301 $7.27

13

5304504914 Frigidaire Freezer Motor In Stock WCI 5304504914 $85.83

13

DOOR STOP, LH WCI 297302801 Contact Us For Availability

14

216730700 Frigidaire Refrigerator Defrost Hea In Stock WCI 216730700 $79.93

14

216822900 Frigidaire Refrigerator Switch In Stock WCI 216822900 $44.37

15

LIGHT-LED WCI 241891105 No Longer Available

15

297414901 Frigidaire Refrigerator Evaporator In Stock WCI 297414901 $97.49

15A

297217900 Frigidaire Refrigerator Suction Tub In Stock WCI 297217900 $49.52

17

BOX-CONTROL WCI 297269000 No Longer Available

18

241881309 Frigidaire Refrigerator Handle In Stock WCI 241881309 $153.45

18

297078701 Frigidaire Refrigerator Evaporator Backorder WCI 297078701 $2.26

19

216204902 Frigidaire Refrigerator Evaporator Backorder WCI 216204902 $21.74

19

INSULATOR-EVAP, STYROFOAM, LH WCI 297078801 Contact Us For Availability

20

297216600 Frigidaire Refrigerator Defrost The In Stock WCI 297216600 $13.53

21A

297197500 Frigidaire Refrigerator Screw Backorder WCI 297197500 $9.04

22

216970802 Frigidaire Refrigerator/Freezer Top In Stock WCI 216970802 $6.79

25

COVER-EVAPORATOR WCI 297099255 Contact Us For Availability

26

216524201 Frigidaire Refrigerator Gasket In Stock WCI 216524201 $31.69

27

5303212828 Frigidaire Refrigerator Primary Cl In Stock WCI 5303212828 $10.41

28

297302513 Frigidaire Freezer Lower Hinge Backorder WCI 297302513 $19.91

29

5304494536 Frigidaire Compressor In Stock WCI 5304494536 $510.77

29

5304510353 Frigidaire Refrigerator Hose In Stock WCI 5304510353 $8.73

30

297237702 Frigidaire Refrigerator Start Relay In Stock WCI 297237702 $42.14

31

297165800 Frigidaire Refrigerator Drain Pan Backorder WCI 297165800 $53.66

32

5304511843 Frigidaire Refrigerator Sleeve In Stock WCI 5304511843 $8.62

35

216273000 Frigidaire Refrigerator Strap Backorder WCI 216273000 $14.03

37

297273906 Frigidaire Refrigerator Corner Trim Backorder WCI 297273906 $4.51

38

HINGE-UPPER, LH WCI 297303901 Contact Us For Availability

40

COVER-HINGE, GRAY, LH WCI 297304001 Contact Us For Availability

41

240578902 Frigidaire Screw Mounting Hinge In Stock WCI 240578902 $9.04

42

SHELF-GLASS WCI 297296600 Contact Us For Availability

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

47

297192903 Frigidaire Refrigerator Baffle Backorder WCI 297192903 $15.85

47A

297291300 Frigidaire Refrigerator Glass Backorder WCI 297291300 $78.43

47B

297291301 Frigidaire Refrigerator Glass Backorder WCI 297291301 $81.13

48

BRACKET-FAN MOTOR WCI 297436400 Contact Us For Availability

49

297291700 Frigidaire Refrigerator Door Bin Backorder WCI 297291700 $58.76

50

216394050 Frigidaire Refrigerator Bracket Backorder WCI 216394050 $13.59

50A

BOARD-LED POWER WCI 241891608 Contact Us For Availability

51

TUBE, WATER, ICE MAKER WCI 216887500 Contact Us For Availability

55

242252603 Frigidaire Refrigerator Water Inlet In Stock WCI 242252603 $31.75

55

297286812 Frigidaire Run Capacitor Assembly In Stock WCI 297286812 $7.03

57

297269402 Frigidaire Refrigerator Overlay Backorder WCI 297269402 $46.18

59

BEARING, DOOR STOP WCI 297302900 Contact Us For Availability

59

BASKET, ASSY, TALL WCI 297304400 Contact Us For Availability

59B

BASKET, ASSY-MID LEVEL WCI 297297500 Contact Us For Availability

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.71

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.41

63

216396900 Frigidaire Dryer Adjustable Levelin In Stock WCI 216396900 $14.92

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $6.79

64

PLUG-BUTTON, HOLE FILLER, DOOR BASE WCI 216403701 Contact Us For Availability

64A

297014702 Frigidaire Refrigerator Suction Lin Backorder WCI 297014702 $5.86

71A

SCREW, 8-18AB X.470 QX WCI 297146820 Contact Us For Availability

79

218755401 Frigidaire Refrigerator Screw Set In Stock WCI 218755401 $14.94

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.60

100

297366805 Frigidaire Refrigerator Cord Backorder WCI 297366805 $42.57

107

ACCESS COVER, MACHINE COMPT. WCI 297165400 Contact Us For Availability

130

297244700 Frigidaire Refrigerator Support Backorder WCI 297244700 $2.72

136

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

137

297296511 Frigidaire Refrigerator Shelf Brack Backorder WCI 297296511 $54.23

138

TRIM-SHELF WCI 297296300 Contact Us For Availability

138D

297350900 Frigidaire Refrigerator Gasket Backorder WCI 297350900 $11.32

146

SHROUD-FAN ORFICE WCI 297164000 Contact Us For Availability

148

FRAME, BASKET-COVER, TALL WCI 297288802 Contact Us For Availability

148A

FRAME, BASKET, MID-LEVEL WCI 297288803 Contact Us For Availability

148B

297142600 Frigidaire Refrigerator/Freezer Scr Backorder WCI 297142600 $8.15

151

5304497789 Frigidaire Freezer Controller Backorder WCI 5304497789 $183.25

169

216912401 Frigidaire Refrigerator Screw Backorder WCI 216912401 $8.14

170

297280403 Frigidaire Refrigerator Valve Backorder WCI 297280403 $13.59

171

297092700 Frigidaire Refrigerator Bracket In Stock WCI 297092700 $33.06

172

297092701 Frigidaire Refrigerator Bracket In Stock WCI 297092701 $33.97

173

5304517648 Frigidaire Freezer Basket-Slide Backorder WCI 5304517648 $44.82

174

5304517649 Frigidaire Freezer Basket-Slide Backorder WCI 5304517649 $48.41

175

297099500 Frigidaire Refrigerator Support In Stock WCI 297099500 $28.07

207

SHIELD-LIGHT, WHITE WCI 297294501 Contact Us For Availability

210

216905301 Frigidaire Refrigerator Screw Backorder WCI 216905301 $9.06

216858001 Frigidaire Refrigerator Screw In Stock WCI 216858001 $6.80

240537301 Frigidaire Refrigerator Anchor Nut Backorder WCI 240537301 $7.23

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $6.32

297110400 Frigidaire Refrigerator Thermistor In Stock WCI 297110400 $49.29

5304485759 Frigidaire Refrigerator Tape Backorder WCI 5304485759 $0.46

INSULATION, 24", SUCTION LINE WCI 297001704 Contact Us For Availability

SCREW, ANCHOR, #8, WHITE WCI 297048000 Contact Us For Availability

216337701 Frigidaire Refrigerator Screw Backorder WCI 216337701 $8.58

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $13.13

5304406520 Frigidaire Refrigerator Clip 40 Pa In Stock WCI 5304406520 $81.17

WCI 297164651 WCI 297164651 Contact Us For Availability

NIAA

241852501 Frigidaire Refrigerator Clip Backorder WCI 241852501 $9.93

NIB

WCI 297164650 WCI 297164650 Contact Us For Availability
