Model Electrolux CRG3485QSG RANGE/OVEN, GAS, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

316408706 Frigidaire Oven Drawer Assembly In Stock WCI 316408706 $65.66

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $15.59

2

SHIELD, BACKGUARD, INNER WCI 316497600 Contact Us For Availability

2A

5304506547 Frigidaire Oven Valve In Stock WCI 5304506547 $40.11

2B

5304506551 Frigidaire Oven Valve Backorder WCI 5304506551 $36.09

2C

5304506549 Frigidaire Oven Valve In Stock WCI 5304506549 $41.01

2D

5304506548 Frigidaire Oven Valve In Stock WCI 5304506548 $48.06

3

5303935378 Frigidaire Oven Door Trim Kit (Bla In Stock WCI 5303935378 $39.25

3

5304506557 Frigidaire Oven Harness Backorder WCI 5304506557 $59.51

4

316453033 Frigidaire Assembly Glass Backorder WCI 316453033 $146.59

4

DRAWER PANEL, ASSY, STAINLESS, W/OVERLAY WCI 316581601 Contact Us For Availability

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.46

5

316446401 Frigidaire Oven Glass In Stock WCI 316446401 $72.75

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $3.55

6

316402316 Frigidaire Shield Backorder WCI 316402316 $51.57

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $56.76

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $44.97

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.78

8

316400603 Frigidaire Oven Stove Bottom Panel Backorder WCI 316400603 $105.46

8

808608804 Frigidaire Oven Gas Range Spark Mod In Stock WCI 808608804 $52.87

9

316423807 Frigidaire Oven Door Liner Backorder WCI 316423807 $96.90

9

PAN, BROILER OPTIONAL ACCESSORY WCI 316081900 Contact Us For Availability

10

INSERT, BROILER PAN OPTIONAL ACCESSORY WCI 316082000 Contact Us For Availability

10A

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $35.65

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $49.38

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $32.96

10D

316559300 Frigidaire Oven Burner Backorder WCI 316559300 $107.19

11

316536614 Frigidaire Igniter/Orifice Assembly Backorder WCI 316536614 $69.64

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $57.31

11B

316536600 Frigidaire Igniter Assembly In Stock WCI 316536600 $77.16

11C

316536602 Frigidaire Oven Igniter/Orifice Ass In Stock WCI 316536602 $77.14

11D

316536623 Frigidaire Igniter/Orifice Assembly In Stock WCI 316536623 $89.18

12

316445501 Frigidaire Oven Switch In Stock WCI 316445501 $56.00

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $8.89

12

5304498835 Frigidaire Oven Seal In Stock WCI 5304498835 $62.59

13

316489101 Frigidaire Suppl Tube-Manifold Backorder WCI 316489101 $63.49

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $60.82

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $36.58

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $42.77

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

15

SUPPORT, BACKGUARD, BLACK, RH WCI 316411405 Contact Us For Availability

15A

SUPPORT, BACKGUARD, BLACK, LH WCI 316411404 Contact Us For Availability

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $72.74

5304507348 Frigidaire Oven Tube Backorder WCI 5304507348 $27.63

5304524341 Frigidaire Lens In Stock WCI 5304524341 $8.02

MAINTOP PANEL, BLACK WCI 316469645 Contact Us For Availability

17

316031501 Frigidaire Oven Valve In Stock WCI 316031501 $168.94

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $35.65

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.70

18

316404400 Frigidaire Oven Burner In Stock WCI 316404400 $64.80

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $29.00

19

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $73.52

19

PANEL, BACKGUARD, BLACK WCI 316416097 Contact Us For Availability

20

316499502 Frigidaire Oven Grate In Stock WCI 316499502 $160.36

20

5304509983 Frigidaire Oven Control Board In Stock WCI 5304509983 $90.97

20

5304519024 Frigidaire Oven Baffle Backorder WCI 5304519024 $46.72

20A

316419141 Frigidaire Oven Overlay In Stock WCI 316419141 $32.94

20A

316551802 Frigidaire Oven Grate Backorder WCI 316551802 $175.11

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.68

21

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.13

22

5304507768 Frigidaire Oven Tube Backorder WCI 5304507768 $29.41

22A

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.05

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $26.28

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $20.95

22D

316559604 Frigidaire Oven Cap Backorder WCI 316559604 $44.95

23

316404302 Frigidaire Oven Burner Backorder WCI 316404302 $64.78

23

316441600 Frigidaire Bracket-Clock Mounting Backorder WCI 316441600 $12.02

23

316575909 Frigidaire Range Door Hinge In Stock WCI 316575909 $57.30

24

5304516894 Frigidaire Oven Elbow Assembly Backorder WCI 5304516894 $50.69

24

5304527841 Frigidaire Oven Rocker Switch (Bla In Stock WCI 5304527841 $6.69

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.14

25

5304497666 Frigidaire Oven Baffle Backorder WCI 5304497666 $54.65

26

5304506545 Frigidaire Gas Oven Range Igniter In Stock WCI 5304506545 $70.07

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $30.72

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.11

33

316405900 Frigidaire Shield Backorder WCI 316405900 $58.63

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.11

36

316220009 Frigidaire Oven Black Range Top Bur In Stock WCI 316220009 $32.47

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.11

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $36.07

39

5304515659 Frigidaire Oven Power Cord In Stock WCI 5304515659 $25.39

39

HANDLE, DOOR, BLACK WCI 316270200 Contact Us For Availability

40

BRACKET, GLASS, AIRWASH, (2) WCI 316446301 Contact Us For Availability

42

316416204 Frigidaire Oven Trim Backorder WCI 316416204 $25.85

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.57

44

316527502 Frigidaire Oven Orifice In Stock WCI 316527502 $14.26

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.24

44B

316527511 Frigidaire Oven Orifice Backorder WCI 316527511 $12.44

44C

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.35

47

GRLP4 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP4 $32.09

52

316575501 Frigidaire Oven Cap In Stock WCI 316575501 $64.35

56

316230708 Frigidaire Oven Shield Backorder WCI 316230708 $38.35

58A

316403700 Frigidaire Insulation Backorder WCI 316403700 $173.42

58B

INSULATION, OVEN BACK WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $32.52

60B

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

82

316400801 Frigidaire Oven Shield Backorder WCI 316400801 $93.03

86

316441300 Frigidaire Receptacle Backorder WCI 316441300 $13.81

88

316232702 Frigidaire Rod Backorder WCI 316232702 $7.55

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $31.49

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $6.22

316001017 Frigidaire Screw Backorder WCI 316001017 $1.80

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.11

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.46

316215600 Frigidaire Oven Screw Backorder WCI 316215600 $8.89

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $8.91

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.46

5304494425 Frigidaire Oven Harness Backorder WCI 5304494425 $50.24

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $4.89

316401500 Frigidaire Oven Cover Backorder WCI 316401500 $7.55

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $8.91

SCREW, HANDLE MTG., 10 14 X .4 TRUS, (2) WCI 316437500 Contact Us For Availability
