Model Frigidaire CFEF212CQ1 ELECTRIC RANGE – Common Parts & Diagrams

*
Screw,truss head ,8-18 x 0.375
Screw,truss head ,8-18 x 0.375 WCI 08016432 Contact Us For Availability
View on Model
1
Drawer
Drawer WCI 5303325610 Contact Us For Availability
View on Model
4
Panel,drawer ,bisque
Panel,drawer ,bisque WCI 318044224 Contact Us For Availability
View on Model
5
Glass,oven door ,tinted ,inner
Glass,oven door ,tinted ,inner WCI 5303310508 Contact Us For Availability
View on Model
7
Spacer
Spacer WCI 318014800 Contact Us For Availability
View on Model
9
Liner,oven door
Liner,oven door WCI 318156410 Contact Us For Availability
View on Model
10
Screw,10-24 x 0.625 ,handle mtg
Screw,10-24 x 0.625 ,handle mtg WCI 5303324305 Contact Us For Availability
View on Model
11
Bracket,drawer support ,(2)
Bracket,drawer support ,(2) WCI 5303324427 Contact Us For Availability
View on Model
12
Seal,oven door
Seal,oven door WCI 318053321 Contact Us For Availability
View on Model
13
Channel,drawer ,RH
Channel,drawer ,RH WCI 318018100 Contact Us For Availability
View on Model
13
Panel,oven door ,bisque
Panel,oven door ,bisque WCI 318009044 Contact Us For Availability
View on Model
13#
Switch,selector
Switch,selector WCI 318057910 Contact Us For Availability
View on Model
13A
Channel,drawer ,LH
Channel,drawer ,LH WCI 318018101 Contact Us For Availability
View on Model
15
Bracket,glass mtg ,RS
Bracket,glass mtg ,RS WCI 5303311153 Contact Us For Availability
View on Model
15A
Bracket,glass mtg ,LS
Bracket,glass mtg ,LS WCI 5303311154 Contact Us For Availability
View on Model
15A#
Element,surface ,small/6 inch ,1250W ,medalli
Element,surface ,small/6 inch ,1250W ,medalli WCI 5303299749 Contact Us For Availability
View on Model
16
Glass,oven door ,6.50 x 15.50 ,inner ,heat ba
Glass,oven door ,6.50 x 15.50 ,inner ,heat ba WCI 5303310533 Contact Us For Availability
View on Model
16
Main Top,bisque
Main Top,bisque WCI 318120924 Contact Us For Availability
View on Model
18
Gasket,door glass seal ,outer
Gasket,door glass seal ,outer WCI 318053203 Contact Us For Availability
View on Model
20
Spacer,handle ,bisque ,(2)
Spacer,handle ,bisque ,(2) WCI 318014303 Contact Us For Availability
View on Model
22
Bar,glass retainer
Bar,glass retainer WCI 5303310511 Contact Us For Availability
View on Model
23
Hinge,oven door
Hinge,oven door WCI 318024702 Contact Us For Availability
View on Model
25
Shield,oven bottom
Shield,oven bottom WCI 5303325069 Contact Us For Availability
View on Model
27#
Terminal Block,surface element
Terminal Block,surface element WCI 5303323704 Contact Us For Availability
View on Model
28
Medallion,surface element
Medallion,surface element WCI 5303301461 Contact Us For Availability
View on Model
39
Handle,door ,bisque
Handle,door ,bisque WCI 316091125 Contact Us For Availability
View on Model
39#
Cord,electric
Cord,electric WCI 318113105 Contact Us For Availability
View on Model
41
Cover,hinge cutout
Cover,hinge cutout WCI 5303310526 Contact Us For Availability
View on Model
50
Panel,side brace ,glass
Panel,side brace ,glass WCI 318144900 Contact Us For Availability
View on Model
54
Housing,oven light
Housing,oven light WCI 5303310514 Contact Us For Availability
View on Model
55
Bracket,glass support
Bracket,glass support WCI 318122300 Contact Us For Availability
View on Model
58A
Insulation,oven wrapper
Insulation,oven wrapper WCI 318133702 Contact Us For Availability
View on Model
58B
Insulation,oven back
Insulation,oven back WCI 318133748 Contact Us For Availability
View on Model
59
Tube,oven vent
Tube,oven vent WCI 5303324426 Contact Us For Availability
View on Model
71
Panel,cover
Panel,cover WCI 318086500 Contact Us For Availability
View on Model
74
Bumper,base
Bumper,base WCI 318147410 Contact Us For Availability
View on Model
76
Frame,oven front
Frame,oven front WCI 318123100 Contact Us For Availability
View on Model
81
Spring,oven
Spring,oven WCI 318192400 Contact Us For Availability
View on Model
83
Liner,oven complete
Liner,oven complete WCI 318089614 Contact Us For Availability
View on Model
86
Receptacle,hinge
Receptacle,hinge WCI 5303310524 Contact Us For Availability
View on Model
93
Support,terminal block ,(4)
Support,terminal block ,(4) WCI 5303324436 Contact Us For Availability
View on Model
219#
Thermostat,safety
Thermostat,safety WCI 318003602 Contact Us For Availability
View on Model
