Model C2Y366SEL1SS – Common Parts & Diagrams

Common parts from model C2Y366SEL1SS

WB28K10538 GE Oven LP Conversion Kit

WB28K10538 GE Oven LP Conversion Kit Out of Stock GEN WB28K10538 $59.96

WB28T10117 GE Oven Orifice Spud LP Main

WB28T10117 GE Oven Orifice Spud LP Main Out of Stock GEN WB28T10117 $7.18

WB28T10118 GE Oven Orifice Spud LP Main

WB28T10118 GE Oven Orifice Spud LP Main Out of Stock GEN WB28T10118 $7.18

WB28T10155 GE Oven Orifice Spud (NG Main)

WB28T10155 GE Oven Orifice Spud (NG Main) Out of Stock GEN WB28T10155 $7.18

WB28T10159 GE Oven Orifice Spud (NG Simmer)

WB28T10159 GE Oven Orifice Spud (NG Simmer) Out of Stock GEN WB28T10159 $7.00

WB01K10002 GE Oven Screw 8-32

WB01K10002 GE Oven Screw 8-32 In Stock GEN WB01K10002 $14.24

WB01T10104 GE Oven Screw 8-32 MCH PNT15

WB01T10104 GE Oven Screw 8-32 MCH PNT15 In Stock GEN WB01T10104 $5.11

WB18X31492 GE Harness Burner Box

WB18X31492 GE Harness Burner Box In Stock GEN WB18X31492 $94.75

WB01T10092 GE Oven Screw Simmer Main HD

WB01T10092 GE Oven Screw Simmer Main HD In Stock GEN WB01T10092 $5.11

WB01K10067 GE Oven Screw 8 HD 1/4 20

WB01K10067 GE Oven Screw 8 HD 1/4 20 In Stock GEN WB01K10067 $5.02

WB26T10037 GE Oven Motor PSC Convection

WB26T10037 GE Oven Motor PSC Convection Out of Stock GEN WB26T10037 $116.03

WB13X27503 GE Oven Module Spark

WB13X27503 GE Oven Module Spark In Stock GEN WB13X27503 $104.74

WB28K10493 GE Oven Tube and Nut Assembly

WB28K10493 GE Oven Tube and Nut Assembly Out of Stock GEN WB28K10493 $20.47

WB28K10498 GE Oven Tube and Nut Assembly

WB28K10498 GE Oven Tube and Nut Assembly Out of Stock GEN WB28K10498 $19.55

WB28T10114 GE Oven Injet Burner 18K

WB28T10114 GE Oven Injet Burner 18K Out of Stock GEN WB28T10114 $60.64

WB24K10048 GE Oven Encoder Assembly

WB24K10048 GE Oven Encoder Assembly Out of Stock GEN WB24K10048 $163.74

WB02K10219 GE Range Endcap Extension

WB02K10219 GE Range Endcap Extension Out of Stock GEN WB02K10219 $14.98

WB55K10062 GE Oven Liner Oven Door Assembly

WB55K10062 GE Oven Liner Oven Door Assembly Out of Stock GEN WB55K10062 $158.93

WB27K10458 GE Oven Control Display Module

WB27K10458 GE Oven Control Display Module Out of Stock GEN WB27K10458 $137.09

WB01X26995 GE Oven Screw 8-18 AB X 5/16S

WB01X26995 GE Oven Screw 8-18 AB X 5/16S Out of Stock GEN WB01X26995 $5.11

WB02X29479 GE Oven Badge Assembly

WB02X29479 GE Oven Badge Assembly Out of Stock GEN WB02X29479 $8.95

WB10K10017 GE Oven Hinge Right Door (36)

WB10K10017 GE Oven Hinge Right Door (36) Out of Stock GEN WB10K10017 $99.42

WB10K10018 GE Oven Hinge Left Door (36)

WB10K10018 GE Oven Hinge Left Door (36) In Stock GEN WB10K10018 $99.42

WB57K10138 GE Oven Glass Door

WB57K10138 GE Oven Glass Door Out of Stock GEN WB57K10138 $104.20

WB16X26480 GE Range Cooktop Burner Head Assem

WB16X26480 GE Range Cooktop Burner Head Assem Out of Stock GEN WB16X26480 $53.88

WB48K10035 GE Oven Rack Oven Slide Assembly

WB48K10035 GE Oven Rack Oven Slide Assembly Out of Stock GEN WB48K10035 $310.46

WB48K10024 GE Oven Rack

WB48K10024 GE Oven Rack Out of Stock GEN WB48K10024 $150.08

WB02K10395 GE Oven Guide Oven Rack Left Hand

WB02K10395 GE Oven Guide Oven Rack Left Hand Out of Stock GEN WB02K10395 $85.86

WB08K10011 GE Oven Lamp Halogen Assembly

WB08K10011 GE Oven Lamp Halogen Assembly Out of Stock GEN WB08K10011 $172.37

WB25T10064 GE Oven Lamp Halogen 20W

WB25T10064 GE Oven Lamp Halogen 20W In Stock GEN WB25T10064 $11.16

WB44K10024 GE Oven Shield Broil Assembly

WB44K10024 GE Oven Shield Broil Assembly Out of Stock GEN WB44K10024 $181.78

WB44T10056 GE Oven Element Bake

WB44T10056 GE Oven Element Bake Out of Stock GEN WB44T10056 $107.10

WB19K10061 GE Oven Relay Board Assembly RT

WB19K10061 GE Oven Relay Board Assembly RT In Stock GEN WB19K10061 $313.10

WB21K10130 GE Oven Switch Sail Assembly

WB21K10130 GE Oven Switch Sail Assembly Out of Stock GEN WB21K10130 $58.80

WB21K10127 GE Oven High Limit Switch

WB21K10127 GE Oven High Limit Switch Out of Stock GEN WB21K10127 $43.09

WB02K10195 GE Oven Gasket Frame Front

WB02K10195 GE Oven Gasket Frame Front Out of Stock GEN WB02K10195 $26.30

WB02K10221 GE Oven Door Gasket 27"

WB02K10221 GE Oven Door Gasket 27" Out of Stock GEN WB02K10221 $40.82

WB07K10441 GE Oven Trim Vent Assembly

WB07K10441 GE Oven Trim Vent Assembly Out of Stock GEN WB07K10441 $166.65

WB49X24032 GE Oven Kit Leg

WB49X24032 GE Oven Kit Leg In Stock GEN WB49X24032 $119.24

WB02K10237 GE Oven Bracket Anti Tip

WB02K10237 GE Oven Bracket Anti Tip Out of Stock GEN WB02K10237 $17.37

WB02K10224 GE Oven Brace Anti Tip

WB02K10224 GE Oven Brace Anti Tip Out of Stock GEN WB02K10224 $12.29

WB21X22134 GE Oven Sensor Assembly

WB21X22134 GE Oven Sensor Assembly In Stock GEN WB21X22134 $13.81

WB26K10010 GE Oven Blower Tangetial 45MM

WB26K10010 GE Oven Blower Tangetial 45MM Out of Stock GEN WB26K10010 $186.48

WB31K10252 GE Oven Burner Grate

WB31K10252 GE Oven Burner Grate In Stock GEN WB31K10252 $131.73

WB31K10253 GE Oven Burner Grate

WB31K10253 GE Oven Burner Grate In Stock GEN WB31K10253 $191.02

WB25T10063 GE Oven Crystal Lamp

WB25T10063 GE Oven Crystal Lamp Out of Stock GEN WB25T10063 $51.03

WB02T10034 GE Oven Body Side Support

WB02T10034 GE Oven Body Side Support Out of Stock GEN WB02T10034 $5.11

WB44T10058 GE Oven Element Convection

WB44T10058 GE Oven Element Convection Out of Stock GEN WB44T10058 $48.01

WB21K10162 GE Oven Valve Dual

WB21K10162 GE Oven Valve Dual Out of Stock GEN WB21K10162 $97.76

WB27K10298 GE Oven Transformer

WB27K10298 GE Oven Transformer In Stock GEN WB27K10298 $72.77

WB21K10129 GE Oven Regulator

WB21K10129 GE Oven Regulator Out of Stock GEN WB21K10129 $78.10

WB19K10038 GE Oven Valve Shut Off

WB19K10038 GE Oven Valve Shut Off Out of Stock GEN WB19K10038 $35.68

WB02K10273 GE Oven Bracket Latch

WB02K10273 GE Oven Bracket Latch Out of Stock GEN WB02K10273 $28.35

WB02K10206 GE Oven Latch Oven

WB02K10206 GE Oven Latch Oven Out of Stock GEN WB02K10206 $79.70

WB13T10067 GE Oven Burner Cap

WB13T10067 GE Oven Burner Cap In Stock GEN WB13T10067 $47.21

WB02T10289 GE Oven Stirrer Fan Blade

WB02T10289 GE Oven Stirrer Fan Blade In Stock GEN WB02T10289 $15.70

WB02T10017 GE Oven Nut

WB02T10017 GE Oven Nut Out of Stock GEN WB02T10017 $6.25

WB02T10293 GE Range Convex Meter Mounting

WB02T10293 GE Range Convex Meter Mounting In Stock GEN WB02T10293 $9.27

WB35K10128 GE Oven Insulation

WB35K10128 GE Oven Insulation Out of Stock GEN WB35K10128 $10.91

WB13T10065 GE Oven Electrode Top

WB13T10065 GE Oven Electrode Top In Stock GEN WB13T10065 $20.61

WB16T10047 GE Range/Cooktop Base Burner 18K-S

WB16T10047 GE Range/Cooktop Base Burner 18K-S In Stock GEN WB16T10047 $62.67

WB09T10011 GE Oven Spring Ignitor

WB09T10011 GE Oven Spring Ignitor Out of Stock GEN WB09T10011 $5.11

WB02T10323 GE Oven Washer Ignitor

WB02T10323 GE Oven Washer Ignitor Out of Stock GEN WB02T10323 $5.11

WB27T10662 GE Oven Capacitor

WB27T10662 GE Oven Capacitor Out of Stock GEN WB27T10662 $5.00

WB20K10030 GE Oven Probe Thermistor

WB20K10030 GE Oven Probe Thermistor Out of Stock GEN WB20K10030 $57.96

WB20K10032 GE Oven Probe Receptacle

WB20K10032 GE Oven Probe Receptacle Out of Stock GEN WB20K10032 $67.02

WB01K10042 GE Oven Screw 8-18 AB IHW 3/8 SN

WB01K10042 GE Oven Screw 8-18 AB IHW 3/8 SN In Stock GEN WB01K10042 $5.11

WB02K10359 GE Oven Tape Mastic 4IN X 2IN

WB02K10359 GE Oven Tape Mastic 4IN X 2IN Out of Stock GEN WB02K10359 $19.98

WB02T10111 GE CleanER-SS

WB02T10111 GE CleanER-SS Out of Stock GEN WB02T10111 $14.61

WB02T10303 GE Lubricant Cleaner

WB02T10303 GE Lubricant Cleaner Out of Stock GEN WB02T10303 $35.53

WB01K10086 GE Oven Screw 8-18 AB TRPO 3/8 Sta

WB01K10086 GE Oven Screw 8-18 AB TRPO 3/8 Sta Out of Stock GEN WB01K10086 $5.00

WR01X10590 GE Refrigerator Screw 10-16 Ab Pnt

WR01X10590 GE Refrigerator Screw 10-16 Ab Pnt In Stock GEN WR01X10590 $5.11

WB18K10050 GE Oven Harness HV

WB18K10050 GE Oven Harness HV In Stock GEN WB18K10050 $28.73

WB02K10392 GE Oven Rod Extension

WB02K10392 GE Oven Rod Extension In Stock GEN WB02K10392 $26.66

WB24K10063 GE Oven Harness Serial Dual

WB24K10063 GE Oven Harness Serial Dual Out of Stock GEN WB24K10063 $67.93
