Model Electrolux 790.78834601 Gas Range (Kenmore 79078834601) – Common Parts &amp; Diagrams

1

316401608 Frigidaire Back Appliance Backorder WCI 316401608 $80.21

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $15.85

2

Range Surface Burner Valve WCI 5303935233 Contact Us For Availability

2A

Range Surface Burner Valve WCI 5303935235 Contact Us For Availability

2C

Range Surface Burner Valve WCI 5303935234 Contact Us For Availability

3

Range Wire Harness WCI 316219009 Contact Us For Availability

4

Range Broil Drawer Outer Panel (White) WCI 316403401 Contact Us For Availability

4

Range Oven Door Outer Panel Assembly (White) WCI 316470100 Contact Us For Availability

4

Range Broil Drawer Outer Panel (Black) WCI 316403402 Contact Us For Availability

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

6A

Range Oven Rack WCI 316425801 Contact Us For Availability

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $45.72

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.88

8

316400603 Frigidaire Range Stove Bottom Panel In Stock WCI 316400603 $107.26

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

8

808608804 Frigidaire Oven Gas Range Spark Mod In Stock WCI 808608804 $54.56

10

316433300 Frigidaire Oven Range Door Handle M In Stock WCI 316433300 $9.04

10

Range Surface Burner Head WCI 316223300 Contact Us For Availability

10B

316008401 Frigidaire Washer P-1 Backorder WCI 316008401 $7.23

10C

316212400 Frigidaire Oven Primary Burner Asse In Stock WCI 316212400 $19.49

10D

316458900 Frigidaire Oven Burner Backorder WCI 316458900 $156.81

11

Frigidaire Range Surface Burner Igniter and O WCI 316430502 No Longer Available

11B

Range Surface Burner Igniter and Orifice Hold WCI 316430402 Contact Us For Availability

11D

Range Surface Burner Igniter and Orifice Hold WCI 316464100 Contact Us For Availability

11E

Range Surface Burner Igniter and Orifice Hold WCI 316464000 Contact Us For Availability

11F

Cooktop Igniter Orifice WCI 316464200 Contact Us For Availability

12

316445500 Frigidaire Oven Switch In Stock WCI 316445500 $38.11

12

5304498835 Frigidaire Range Seal In Stock WCI 5304498835 $63.63

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

14

5304521339 Frigidaire Regulator In Stock WCI 5304521339 $62.28

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $43.49

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

Range Control Panel Support, Right WCI 316411405 Contact Us For Availability

Range Control Panel Support, Right WCI 316411403 Contact Us For Availability

15A

Range Control Panel Support, Left WCI 316411404 Contact Us For Availability

15A

Universal/Multiflex (Frigidaire) Range Contro WCI 316411402 Contact Us For Availability

16

Range Main Top Assembly WCI 316411226 Contact Us For Availability

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $36.24

17

316404901 Frigidaire Range Valve In Stock WCI 316404901 $212.39

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.94

18

316404400 Frigidaire Range Burner Backorder WCI 316404400 $69.45

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $29.16

19

5304534663 Frigidaire Igniter In Stock WCI 5304534663 $55.69

20

316418501 Frigidaire Timer Clock Assembly Backorder WCI 316418501 $250.59

20

5304519024 Frigidaire Range Baffle In Stock WCI 5304519024 $47.49

20A

316352021 Frigidaire Range Overlay Assembly Backorder WCI 316352021 $53.77

20A

316419503 Frigidaire Range Overlay Backorder WCI 316419503 $28.53

21

Backorder WCI 154079601 $0.28

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.85

22

316271904 Frigidaire Oven Cap Backorder WCI 316271904 $123.26

22

Range Broil Burner Gas Supply Tube WCI 316405401 Contact Us For Availability

22A

Range Surface Burner Cap WCI 316206604 Contact Us For Availability

22B

Range Surface Burner Cap WCI 316213505 Contact Us For Availability

22C

Range Surface Burner Cap WCI 316458603 Contact Us For Availability

22D

Universal/Multiflex (Frigidaire) Range Surfac WCI 316458703 Contact Us For Availability

23

Range Oven Door Hinge WCI 316456302 Contact Us For Availability

23

Range Broil Burner WCI 316404300 Contact Us For Availability

24

5304516894 Frigidaire Range Elbow Assembly Backorder WCI 5304516894 $51.54

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.99

25

Range Broil Burner Baffle WCI 316401301 Contact Us For Availability

26

316489401 Frigidaire Igniter Assembly In Stock WCI 316489401 $107.26

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.34

30

Range Main Top Right Hinge Pin WCI 316217700 Contact Us For Availability

33

316402500 Frigidaire Range Shield Backorder WCI 316402500 $76.18

34

Range Griddle WCI 316465800 Contact Us For Availability

36

316442500 Frigidaire Range Knob Backorder WCI 316442500 $37.18

36

316442501 Frigidaire Range Black Control Knob Backorder WCI 316442501 $40.80

36

Range Surface Burner Knob WCI 316442502 Contact Us For Availability

36A

Range Surface Burner Knob WCI 316442504 Contact Us For Availability

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.23

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $39.37

39

316443601 Frigidaire Oven Handle In Stock WCI 316443601 $69.71

39

Range Oven Door Handle WCI 316443602 Contact Us For Availability

42

316416204 Frigidaire Range Trim Backorder WCI 316416204 $26.27

42

316416205 Frigidaire Range Trim Backorder WCI 316416205 $30.79

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

Range Surface Burner Orifice WCI 316237909 Contact Us For Availability

44A

Range Surface Burner Orifice Assembly WCI 316237903 Contact Us For Availability

44C

316237902 Frigidaire Orifice Top Burner In Stock WCI 316237902 $38.53

44D

Range Surface Burner Orifice WCI 316237913 Contact Us For Availability

47

Range LP Conversion Kit WCI 316243718 Contact Us For Availability

58A

316403700 Frigidaire Insulation In Stock WCI 316403700 $176.57

58B

Range Oven Insulation, Rear WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $33.06

82

316400801 Frigidaire Range Shield In Stock WCI 316400801 $94.62

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $14.03

88

316099500 Frigidaire Oven Pin Backorder WCI 316099500 $4.14

88

316232702 Frigidaire Rod Backorder WCI 316232702 $7.67

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $32.80

170

316112500 Frigidaire Oven Template Backorder WCI 316112500 $2.26

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $4.97

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.23

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.60

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $9.04

316401500 Frigidaire Range Cover Backorder WCI 316401500 $7.67

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $8.58

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.60

5303321319 Frigidaire Refrigerator White Touc In Stock WCI 5303321319 $9.23

Bisq Paint WCI 5304414035 Contact Us For Availability

Range Screw WCI 316021108 Contact Us For Availability
