Model Whirlpool 3XARG477GF03 REFRIGERATOR – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI12734A2 Contact Us For Availability

1

Shelf, Ladder (2) WPL 2163756 Contact Us For Availability

2

WP2182381 Whirlpool Refrigerator Bimetallic D In Stock WPL WP2182381 $37.79

2

Grommet (2) WPL 531933 Contact Us For Availability

2

Shelf, Ladder Center WPL 2163826 Contact Us For Availability

3

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

4

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

4

Timer, Defrost WPL 2193095 Contact Us For Availability

5

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

6

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

6

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

6

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

6

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

7

Wire Assy. Control Box WPL 2200632 Contact Us For Availability

7

Frame Assembly, Shelf WPL 2174446 Contact Us For Availability

8

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $84.60

8

2159327 Whirlpool Refrigerator Door Gasket In Stock WPL 2159327 $78.12

8

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

8

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

9

WP2314548 Whirlpool Refrigerator Cover Backorder WPL WP2314548 $96.71

9

Damper, Air WPL 2179858 Contact Us For Availability

10

Enclosure, Terminal Block WPL 2188194 Contact Us For Availability

10

Fan Motor WPL 2183828 Contact Us For Availability

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

11

WP2169921 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2169921 $118.25

11

Terminal Block WPL 1129346 Contact Us For Availability

12

Control Box WPL 2179790 Contact Us For Availability

12

Frame Assembly, Meat Shelf WPL 2179716 Contact Us For Availability

4387562 Whirlpool Refrigerator Thermostat Col Backorder WPL 4387562 $116.21

Tray, Door WPL 2159302 Contact Us For Availability

Bushing WPL 1129449 Contact Us For Availability

Gasket, Crisper Cover WPL 2172683 Contact Us For Availability

14

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

14

Clip, Defrost Timer WPL 2176341 Contact Us For Availability

15

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $50.82

15

Screw WPL 489412 Contact Us For Availability

WP2254618 Whirlpool Center Door Hinge In Stock WPL WP2254618 $25.07

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

Cover, Evaporator WPL 2183152 Contact Us For Availability

Track Assembly, Shelf WPL 2176240 Contact Us For Availability

17

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $69.61

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

17

Hole Plug WPL 2166844 Contact Us For Availability

18

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

18

Weight, Thermal WPL 2163802 Contact Us For Availability

18

Hook, Shelf WPL 2169608 Contact Us For Availability

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $89.14

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

Clip, Heater WPL 2182338 Contact Us For Availability

20

WP2218127K Whirlpool Meat Pan Backorder WPL WP2218127K $81.90

20

WP2254473 Whirlpool Refrigerator Door Hinge In Stock WPL WP2254473 $3.70

20

Wire Assembly, Freezer Compartment WPL 2199112 Contact Us For Availability

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

21

Wire Assembly WPL 2199068 Contact Us For Availability

21

Screw WPL 489419 Contact Us For Availability

22

Gasket WPL 2167227 Contact Us For Availability

22

Knob, Thermostat WPL 2193455 Contact Us For Availability

22

Shelf Assembly, Spillguard L/A WPL 2195349 Contact Us For Availability

WP2159312 Whirlpool Refrigerator Door Trim Backorder WPL WP2159312 $41.05

WP2176222 Whirlpool Refrigerator Slide In Stock WPL WP2176222 $9.97

Air Tower WPL 2182340 Contact Us For Availability

CLIP, GRILLE (2) WPL 2189356 Contact Us For Availability

WP2163835 Whirlpool Track Assembly In Stock WPL WP2163835 $11.91

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $42.62

Fitting, Water Tube (Not Serviced) WPL ARI12732A7 Contact Us For Availability

25

W10856580 Whirlpool Crisper Pan In Stock WPL W10856580 $90.63

25

WP2151652 Whirlpool Refrigerator Button Plug Backorder WPL WP2151652 $8.20

25

Freezer Floor WPL 2190590 Contact Us For Availability

26

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $30.98

26

Air Diffuser, Top WPL 2200793 Contact Us For Availability

26

Cover, Water Valve WPL 2166251 Contact Us For Availability

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $3.70

WP2217784 Whirlpool Refrigerator Cover Backorder WPL WP2217784 $15.98

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

Trim, Crisper Pan WPL 2195340 Contact Us For Availability

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $24.72

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $27.12

WP2254386 Whirlpool Refrigerator Grille Backorder WPL WP2254386 $31.60

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

Installation Kit WPL 482801 Contact Us For Availability

29

WP489467 Whirlpool Hinge Shim In Stock WPL WP489467 $4.59

29

Bracket, Fan Motor WPL 2200511 Contact Us For Availability

29

Trim, Meat Pan WPL 2176356 Contact Us For Availability

30

WP2254360 Whirlpool Refrigerator Gasket In Stock WPL WP2254360 $8.67

30

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

30

Shelf Assembly, Spillguard (2) WPL 2195500 Contact Us For Availability

31

4388450 Whirlpool Refrigerator Insert Backorder WPL 4388450 $27.03

31

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

31

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

32

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

32

Rail Center (Not Serviced) WPL ARI12733A9 Contact Us For Availability

33

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

33

Insulation WPL 2200777 Contact Us For Availability

33

Shelf, Ice Tray WPL 2183995 Contact Us For Availability

34

WP2189475 Whirlpool Refrigerator Unit Cover Backorder WPL WP2189475 $68.24

34

Knob, Damper WPL 2176297 Contact Us For Availability

35

WP2175210 Whirlpool Refrigerator Shroud Backorder WPL WP2175210 $26.21

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

37

Sleeve WPL 2179712 Contact Us For Availability

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

38

Shield WPL 2190519 Contact Us For Availability

39

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

39

Housing Base WPL 2182382 Contact Us For Availability

41

Wire Harness, Freezer light WPL 2198891 Contact Us For Availability

42

Electrical Shield, Freezer Light WPL 2193491 Contact Us For Availability

43

WP67002552 Whirlpool Refrigerator Light Bulb In Stock WPL WP67002552 $2.56

43

Blade, Fan WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Post, Damper WPL 2179859 Contact Us For Availability

45

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

48

Gasket, Rear WPL 2166284 Contact Us For Availability

49

Pullout, Freezer Floor (Includes Item 56) WPL 2201045 Contact Us For Availability

50

REAR FENCE PULL-OUT FREEZER FLOOR WPL 2198768 Contact Us For Availability

51

Roller, Slide WPL 2176246 Contact Us For Availability

52

Side Support, Floor Assembly WPL 2179713 Contact Us For Availability

53

Center Support, Floor Assembly WPL 2179714 Contact Us For Availability

56

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

56

Insulation, Freezer Floor WPL 2179772 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

59

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

FeaturePak (Includes 4,7,12, 16,18,20,21,22,4 WPL 2199043 Contact Us For Availability
