Model Kenmore 25362872201 REFRIGERATOR – Common Parts &amp; Diagrams

*

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $12.24

*

5304414035 Frigidaire Refrigerator Touch Up P Backorder WCI 5304414035 $9.00

*

Hot Tube Repair Kit,Service WCI 5303918222 Contact Us For Availability

*#

5303918263 Frigidaire Refrigerator Primary He In Stock WCI 5303918263 $316.98

1#

5304472169 Frigidaire Refrigerator Condenser Backorder WCI 5304472169 $88.52

2

240367001 Frigidaire Refrigerator Air Damper In Stock WCI 240367001 $34.41

4

Damper-fan cover WCI 240367401 Contact Us For Availability

4#

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $18.59

5#

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $31.93

6

Wiring Harness,machine compt, w/electric cord WCI 240496101 Contact Us For Availability

6*#

Wiring Harness,control box WCI 240375501 Contact Us For Availability

6*#

Wiring Harness,freezer section WCI 240385401 Contact Us For Availability

9

Bracket-motor mtg,front WCI 5303292396 Contact Us For Availability

215667501 Frigidaire Refrigerator Ice Tray Pr In Stock WCI 215667501 $3.44

240381301 Frigidaire Refrigerator Button Plug In Stock WCI 240381301 $11.32

240381303 Frigidaire Hinge Plug Backorder WCI 240381303 $41.22

Plug-button,bisque ,hinge brg hole ,(2) WCI 240381302 Contact Us For Availability

11

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $27.18

11*

5303299664 Frigidaire Refrigerator Shelf Spac In Stock WCI 5303299664 $15.40

12

Plug-ice maker harness,rectangular WCI 240366801 Contact Us For Availability

12A

Plug-wtr inlet tube,round ,1" WCI 240374401 Contact Us For Availability

240312421 Frigidaire Refrigerator Door Stop Backorder WCI 240312421 $9.06

240312422 Frigidaire Refrigerator Door Stop Backorder WCI 240312422 $9.06

240312423 Frigidaire Refrigerator Door Stop Backorder WCI 240312423 $7.25

240362601 Frigidaire Refrigerator P1 Diffuser In Stock WCI 240362601 $26.72

13A

240312414 Frigidaire Refrigerator Door Stop Backorder WCI 240312414 $12.20

13A

Door Stop,black ,frzr WCI 240312406 Contact Us For Availability

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $10.41

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $10.85

240494003 Frigidaire Refrigerator Button Plug In Stock WCI 240494003 $10.85

Plug-button,bisque WCI 240494002 Contact Us For Availability

14#

240505801 Frigidaire Light Switch In Stock WCI 240505801 $42.13

14#

5303918208 Frigidaire Defrost Heater Kit In Stock WCI 5303918208 $69.03

15#

5303918274 Frigidaire Refrigerator Evaporator In Stock WCI 5303918274 $190.06

16

241559801 Frigidaire Light Socket Refrigerato Backorder WCI 241559801 $45.94

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

17

241801301 Frigidaire Refrigerator Drain Troug Backorder WCI 241801301 $38.09

17

Control Box WCI 240352701 Contact Us For Availability

218779901 Frigidaire Refrigerator White Fresh In Stock WCI 218779901 $43.91

Handle-door, bisque, refr, w/block & screw WCI 218779904 No Longer Available

Handle-door, charcoal gray, refr, w/block & s WCI 218779903 Contact Us For Availability

Knob-control WCI 240360801 Contact Us For Availability

Insulation Block,RH WCI 240362301 Contact Us For Availability

18A

Handle-door,bisque, frzr, w/nameplate, block WCI 218779810 No Longer Available

18A

Handle-door,white ,frzr WCI 218779809 Contact Us For Availability

18A

Handle-door,gray, frzr, w/nameplate, block & WCI 218779811 Contact Us For Availability

20

Insulation Block,LH WCI 240362401 Contact Us For Availability

21#

241537103 Frigidaire Refrigerator Temperature In Stock WCI 241537103 $52.96

21#

5303918202 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918202 $11.09

22

215774901 Frigidaire Refrigerator Button Plug In Stock WCI 215774901 $10.87

22

215774918 Frigidaire Refrigerator Button Plug Backorder WCI 215774918 $5.88

22

Plate-compr mtg WCI 240330001 Contact Us For Availability

22*

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.04

22A

240468202 Frigidaire Refrigerator Tube Backorder WCI 240468202 $5.42

23

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $27.16

23#

Control-defrost, adaptive timer, PC board WCI 240375801 Contact Us For Availability

23*

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $10.85

24

241616607 Frigidaire Refrigerator Spill Safe In Stock WCI 241616607 $108.84

25

240364787 Frigidaire Refrigerator Crisper Pan In Stock WCI 240364787 $72.81

25

Screw-compressor mtg,1/4-28 x 1.16,shoulder,t WCI 240491501 Contact Us For Availability

25B

5304492617 Frigidaire Refrigerator Humidity D Backorder WCI 5304492617 $4.53

26

240337103 Frigidaire Crisper Drawer In Stock WCI 240337103 $77.85

26

241920605 Frigidaire Refrigerator Defrost Pan In Stock WCI 241920605 $32.71

28

End Cap,freezer shelf ,protector WCI 3201150 No Longer Available

29

5304511983 Frigidaire Refrigerator Compressor Backorder WCI 5304511983 $487.91

30#

5304491942 Frigidaire Refrigerator Starter Ki Backorder WCI 5304491942 $76.64

31

240530811 Frigidaire Refrigerator Meat Crispe In Stock WCI 240530811 $88.77

32

5304497418 Frigidaire Refrigerator Clip Backorder WCI 5304497418 $5.86

34

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

35

240313802 Frigidaire Refrigerator Center Hing Backorder WCI 240313802 $44.37

35

240313803 Frigidaire Refrigerator Center Hing Backorder WCI 240313803 $99.00

35

Bracket-ctr hinge,bisque WCI 240313804 Contact Us For Availability

37

Trim-cabinet corner,black WCI 240337603 Contact Us For Availability

37A

Trim-handle, 28.18", white, lower, w/mtg lock WCI 218779310 Contact Us For Availability

37A*

Lock-handle trim,stick-on WCI 218776501 Contact Us For Availability

37A*

Plug-button,white , refr door front, lower WCI 218074001 Contact Us For Availability

40

240354401 Frigidaire Upper Hinge Cover Backorder WCI 240354401 $37.05

40

240354404 Frigidaire Refrigerator Upper Hinge In Stock WCI 240354404 $37.05

40

Cover-upper hinge,bisque WCI 240354403 Contact Us For Availability

41

Screw,hex washer head ,8-32 x 1/4 WCI 218897001 Contact Us For Availability

41*

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.07

41*

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $7.67

42

240356501 Frigidaire Tray Hanger Pan In Stock WCI 240356501 $36.26

42

240365401 Frigidaire Refrigerator Left-Hand M In Stock WCI 240365401 $36.77

44

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $41.66

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

47

240350608 Frigidaire Refrigerator Crisper Gla In Stock WCI 240350608 $30.39

48

240338101 Frigidaire Refrigerator Bottom Door In Stock WCI 240338101 $34.13

48

Channel-shelf mtg,center WCI 5303292395 Contact Us For Availability

48A

240337901 Frigidaire Refrigerator Bar-Door In Stock WCI 240337901 $33.54

48B

240338001 Frigidaire Refrigerator Gallon Door In Stock WCI 240338001 $21.91

55#

5304464438 Frigidaire Compressor Run Capacito In Stock WCI 5304464438 $14.74

57

240542601 Frigidaire Wiring Harness Clip Backorder WCI 240542601 $57.37

58

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

59

Shroud-cond fan WCI 240315501 Contact Us For Availability

59*

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.01

59*

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.26

59A

240346501 Frigidaire Refrigerator Support Bra Backorder WCI 240346501 $14.05

59B

Grommet-bracket,(3) WCI 240346601 Contact Us For Availability

60#

5303918774 Frigidaire Fan Motor Kit Condenser In Stock WCI 5303918774 $111.27

61#

Fan Blade,galv steel ,condenser fan WCI 240315401 Contact Us For Availability

61A

Nut,speed WCI 215004700 Contact Us For Availability

61B

Grommet-silencer WCI 215004800 Contact Us For Availability

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $28.99

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $30.80

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.04

84

240500801 Frigidaire Refrigerator Drain Tube In Stock WCI 240500801 $41.24

85

Tube-connector,suction WCI 240493101 Contact Us For Availability

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $39.88

123

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $9.50
