Model Kenmore 253.44723100 REFRIGERATOR – Common Parts & Diagrams
Common parts from model Kenmore 253.44723100 REFRIGERATOR
*
Insulation, 24", drain tube WCI 297001704 Contact Us For Availability
*
Sleeve, suction line WCI 216502500 Contact Us For Availability
5
Harness-main WCI 297033700 Contact Us For Availability
10
Tubing- heater, formed WCI 216999400 Contact Us For Availability
13
Door Stop WCI 5303271076 Contact Us For Availability
18
Insulator-evap, styrofoam WCI 216727600 Contact Us For Availability
19
Insulator-evap, styrofoam WCI 216727700 Contact Us For Availability
22
Clamp, cap tube, cold control WCI 216823500 Contact Us For Availability
22
Base, condenser WCI 216970300 Contact Us For Availability
24
Bracket-timer WCI 216968500 Contact Us For Availability
28
Hinge, bracket, lower, RH WCI 216978200 Contact Us For Availability
31
Pan-drain WCI 216732400 Contact Us For Availability
32
Valve, breather, door base WCI 5309950074 Contact Us For Availability
34
Sleeve-compressor WCI 5306594529 Contact Us For Availability
35
Screw, Ind hex sems, 1/4-28 unfx, compressor WCI 5303272328 Contact Us For Availability
38
Hinge-upper WCI 216939100 Contact Us For Availability
40
Cover-upper hinge, black WCI 216809001 Contact Us For Availability
50A
Bracket, fan motor mount WCI 240524001 Contact Us For Availability
59
Bearing, door closer WCI 216974500 Contact Us For Availability
87
Screw, ph truss head, 6-32(T) x 0.500, thread WCI 08037849 Contact Us For Availability
107
Shield, compressor, Compartment WCI 297051401 Contact Us For Availability
138A
Trim-shelf, side WCI 216983601 Contact Us For Availability
139
Trim-shelf, rear WCI 297050800 Contact Us For Availability
146
Shroud-fan orfice WCI 216970200 Contact Us For Availability
152
Bearing, hinge closer WCI 216974600 Contact Us For Availability
155
Clip, (2) WCI 5303313703 Contact Us For Availability
× ![]()
