Model Electrolux 253.31135303 Refrigerator (Kenmore 25331135303) – Common Parts &amp; Diagrams

*

5304458371 Frigidaire Refrigerator Ice Maker In Stock WCI 5304458371 $114.17

*#

5303918330 Frigidaire Refrigerator Heat Excha Backorder WCI 5303918330 $236.98

1

218976903 Frigidaire Refrigerator Water Inlet Backorder WCI 218976903 $53.85

1

5304472169 Frigidaire Refrigerator Condenser Backorder WCI 5304472169 $104.48

2

240367001 Frigidaire Refrigerator Air Damper Backorder WCI 240367001 $38.43

2

Spring, shut-off arm WCI 5304420650 Contact Us For Availability

3

Label, ID plate WCI 3206299 Contact Us For Availability

4

240534901 Frigidaire Refrigerator Door Rack In Stock WCI 240534901 $34.22

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $17.52

4

5304469403 Frigidaire Gear Backorder WCI 5304469403 $15.29

4

Refrigerator Air Damper WCI 240367401 Contact Us For Availability

4B

240534701 Frigidaire Refrigerator Door Rack In Stock WCI 240534701 $20.55

5

Plate-mounting WCI 3206303 Contact Us For Availability

5#

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $33.33

6

218359202 Frigidaire Refrigerator Screw Backorder WCI 218359202 $8.14

6

Refrigerator Wire Harness WCI 240581701 Contact Us For Availability

6A

240388701 Frigidaire Refrigerator Wiring Harn Backorder WCI 240388701 $60.80

6B

Refrigerator Wire Harness WCI 240524701 Contact Us For Availability

6C

Wire Harness WCI 240581801 Contact Us For Availability

7#

5303918277 Frigidaire Refrigerator Ice Maker In Stock WCI 5303918277 $69.79

8

240534801 Frigidaire Refrigerator Freezer Doo In Stock WCI 240534801 $38.04

8

Spacer-hold switch WCI 3206312 Contact Us For Availability

9

Refrigerator Evaporator Fan Motor Bracket, Fr WCI 5303292396 Contact Us For Availability

9

Cam WCI 3206313 Contact Us For Availability

10

Clamp WCI 3206315 Contact Us For Availability

10A

240568606 Frigidaire Refrigerator Coil Cover Backorder WCI 240568606 $9.79

11

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $30.36

11

Kenmore Pro Refrigerator Ice Maker Thermal Cu WCI 3206319 Contact Us For Availability

11

Shelf, freezer, full-width, wire WCI 240358003 Contact Us For Availability

12

240545901 Frigidaire Refrigerator Air Diffuse Backorder WCI 240545901 $53.83

12#

Wiring Harness, ICE MAKER, internal, with plu WCI 5304420651 Contact Us For Availability

13

240312422 Frigidaire Refrigerator Door Stop Backorder WCI 240312422 $10.11

13

240362601 Frigidaire Refrigerator P1 Diffuser Backorder WCI 240362601 $32.08

13

Refrigerator Ice Maker Thermostat WCI 3206322 Contact Us For Availability

13A

Refrigerator Door Stop WCI 240312406 Contact Us For Availability

14

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $11.62

14

Screw, 4 x 0.750, switch mtg. WCI 5304420652 Contact Us For Availability

14#

241554901 Frigidaire Refrigerator Light/Lamp Backorder WCI 241554901 $54.39

14#

5303918247 Frigidaire Refrigerator Defrost He Backorder WCI 5303918247 $119.04

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $11.08

15#

5303918274 Frigidaire Refrigerator Evaporator In Stock WCI 5303918274 $294.70

15#

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $61.08

16

241559801 Frigidaire Light Socket Refrigerato Backorder WCI 241559801 $55.74

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $47.84

16

Support, phenolic WCI 5304420653 Contact Us For Availability

17

240368105 Frigidaire Refrigerator Control Box Backorder WCI 240368105 $86.14

17

241801301 Frigidaire Refrigerator Drain Troug Backorder WCI 241801301 $43.00

17#

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $78.31

18

Refrigerator Door Handle (Charcoal Gray) WCI 218779903 Contact Us For Availability

18

Refrigerator Temperature Control Knob WCI 240360801 Contact Us For Availability

18

Ejector-ice WCI 3206328 Contact Us For Availability

18A

Refrigerator Freezer Door Handle Assembly (Ch WCI 218779814 Contact Us For Availability

19

Bearing & Inlet WCI 3206330 Contact Us For Availability

20

Refrigerator Evaporator Air Block WCI 240518402 Contact Us For Availability

20

Screw, 8-32 x 0.375 WCI 5304408581 Contact Us For Availability

21

Ice Stripper WCI 3206332 Contact Us For Availability

21#

241537103 Frigidaire Refrigerator Temperature In Stock WCI 241537103 $41.13

21#

5303918202 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918202 $21.52

215774918 Frigidaire Refrigerator Button Plug Backorder WCI 215774918 $6.56

5304507147 Frigidaire Refrigerator Hinge Bear In Stock WCI 5304507147 $5.04

Complete Plate WCI 240330001 Contact Us For Availability

Shut-off Arm WCI 3206333 Contact Us For Availability

22A

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $10.85

22A

5303916855 Frigidaire Refrigerator Tube Backorder WCI 5303916855 $46.76

23

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $32.60

23

Screw, 8-32 x 0.875, mold-to-support, (3) WCI 5304408582 Contact Us For Availability

23#

215846602 Frigidaire Refrigerator 8-Hour Defr In Stock WCI 215846602 $18.41

23*

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $11.33

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $44.43

24

Refrigerator Shelf Frame WCI 240372407 Contact Us For Availability

24A

240372408 Frigidaire Refrigerator Shelf Frame Backorder WCI 240372408 $120.09

25

Cover-crisper pan, with beam, humid cont WCI 240364767 Contact Us For Availability

25

Compressor Screw WCI 240491501 Contact Us For Availability

25

Screw, 8-18 x 0.562, lever arm/sprt WCI 3206336 Contact Us For Availability

25B

5304492617 Frigidaire Refrigerator Humidity D Backorder WCI 5304492617 $8.11

26

240343803 Frigidaire Refrigerator Clear Crisp In Stock WCI 240343803 $113.87

26

241697603 Frigidaire Defrost Pan Backorder WCI 241697603 $53.89

26

Screw-thermo/sprt, 4-24 x 0.375, (4) WCI 5304420654 Contact Us For Availability

27

Screw, 4-40 x 1.000, hold switch mtg, (2) WCI 3206338 Contact Us For Availability

28

Screw-timing stop, 4-40 x 0.375 WCI 3206339 Contact Us For Availability

29

240357704 Frigidaire Refrigerator Front Shelf In Stock WCI 240357704 $52.73

29

Refrigerator Compressor WCI 5303918297 Contact Us For Availability

29

Screw, 4-24 x 0.750, (6) WCI 3206323 Contact Us For Availability

30

Screw-timing adj, 8-32 x 1.000 WCI 3206341 Contact Us For Availability

30#

5304433579 Frigidaire Refrigerator P-1 Relay Backorder WCI 5304433579 $22.04

31

240530811 Frigidaire Refrigerator Meat Crispe In Stock WCI 240530811 $97.16

31

Insulator WCI 3206342 Contact Us For Availability

31#

216954208 Frigidaire Refrigerator Controller Backorder WCI 216954208 $57.09

32

Plate-valve switch WCI 3206343 Contact Us For Availability

33

Spring-timing adj WCI 5304408583 Contact Us For Availability

240311303 Frigidaire Refrigerator Nylon Hinge In Stock WCI 240311303 $7.68

240385201 Frigidaire Refrigerator Ice Contain In Stock WCI 240385201 $73.57

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $15.21

Screw, plazscrew, 8-10, (3) WCI 5304420655 Contact Us For Availability

35

240313803 Frigidaire Refrigerator Center Hing Backorder WCI 240313803 $115.02

35

Screw WCI 5304408585 Contact Us For Availability

35A

240336802 Frigidaire Refrigerator Hinge Space Backorder WCI 240336802 $14.11

36

Cover-ice maker WCI 3206347 Contact Us For Availability

37

Refrigerator Corner Trim (Black) WCI 240337603 Contact Us For Availability

37A

Refrigerator Door Handle Trim Cap (Black) WCI 218771203 Contact Us For Availability

40

240354404 Frigidaire Refrigerator Upper Hinge Backorder WCI 240354404 $41.86

40

Refrigerator Glass Shelf WCI 240350692 Contact Us For Availability

41

240561502 Frigidaire Rear Shelf Trim In Stock WCI 240561502 $54.91

41A

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.88

42

240530601 Frigidaire Refrigerator Left Meat P In Stock WCI 240530601 $44.00

42A

240530701 Frigidaire Refrigerator Right Meat In Stock WCI 240530701 $44.00

44

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $43.95

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $10.89

45*

218843801 Frigidaire Refrigerator Screw Backorder WCI 218843801 $9.57

47

Refrigerator Glass Shelf WCI 240350689 Contact Us For Availability

51

241796405 Frigidaire Refrigerator Fill Water In Stock WCI 241796405 $14.11

55#

242252603 Frigidaire Refrigerator Water Inlet In Stock WCI 242252603 $54.75

56

Refrigerator Terminal Cover WCI 240582001 Contact Us For Availability

57

240542601 Frigidaire Wiring Harness Clip Backorder WCI 240542601 $68.87

59

Refrigerator Condenser Bracket WCI 5304430246 Contact Us For Availability

59A

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $22.81

60

218362501 Frigidaire Refrigerator Screw In Stock WCI 218362501 $9.26

60

5303918774 Frigidaire Fan Motor Kit Condenser In Stock WCI 5303918774 $121.05

61

218721500 Frigidaire Refrigerator Leveling Br Backorder WCI 218721500 $55.99

61

240524102 Frigidaire Refrigerator Condenser F In Stock WCI 240524102 $19.05

62

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $10.31

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $8.14

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $34.80

82

5304418225 Frigidaire Refrigerator Roller P-1 Backorder WCI 5304418225 $34.41

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $27.66

85

Tube-conne WCI 240493101 Contact Us For Availability

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $45.03

123

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $11.41

NI02

218990901 Frigidaire Clip Backorder WCI 218990901 $57.09

NI03

5303321321 Frigidaire Refrigerator Black Touc In Stock WCI 5303321321 $14.20

NI04

Refrigerator Service Data Sheet WCI 240379014 Contact Us For Availability

NI05

Refrigerator Owner's Manual WCI 240432307 Contact Us For Availability

NI06

Refrigerator Energy Label WCI 240598605 Contact Us For Availability

NI07

Refrigerator Label WCI 5303270944 Contact Us For Availability

NI08

Refrigerator Repair Parts List WCI 5995403465 Contact Us For Availability

NI10

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $14.69

NI12

Hot Tube WCI 5304421289 Contact Us For Availability
