Model Whirlpool 106.70172990 Top-Mount Refrigerator (Kenmore 10670172990) – Common Parts &amp; Diagrams

1

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

1

Refrigerator Technical Sheet WPL LIT2201079 Contact Us For Availability

1A

Refrigerator Energy Guide WPL LIT2204726 Contact Us For Availability

1B

Refrigerator Energy Guide WPL LIT2204733 Contact Us For Availability

1C

Refrigerator Owner's Manual WPL LIT2199013 Contact Us For Availability

1D

Service Sheet WPL LIT628370 Contact Us For Availability

1E

Refrigerator Parts List WPL LIT2204934 Contact Us For Availability

1F

Refrigerator Installation Instructions WPL 2195516 Contact Us For Availability

2

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $35.91

2

Grommet WPL 531933 Contact Us For Availability

3

WP2254360 Whirlpool Refrigerator Gasket Backorder WPL WP2254360 $8.67

3

WP2261963 Whirlpool Refrigerator Door Hinge In Stock WPL WP2261963 $45.73

3

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

3

Refrigerator Door Trim Screw WPL 489487 Contact Us For Availability

4

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

4

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $30.18

4

Refrigerator Defrost Timer WPL 2193084 Contact Us For Availability

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

6

Refrigerator Crisper Drawer Humidity Control WPL 2176222 Contact Us For Availability

7

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $3.70

7

Refrigerator Wire Harness WPL 2200632 Contact Us For Availability

8

2159060 Whirlpool Refrigerator Gasket In Stock WPL 2159060 $120.49

8

2159061 Whirlpool Refrigerator Door Gasket In Stock WPL 2159061 $98.99

8

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $34.28

8

WP489467 Whirlpool Hinge Shim In Stock WPL WP489467 $4.59

9

Refrigerator Air Damper WPL 2179858 Contact Us For Availability

10

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

10

Refrigerator Screw WPL 2174650 Contact Us For Availability

10

Evaporator Motor WPL 2200546 Contact Us For Availability

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $27.28

11

WP2204812 Whirlpool Refrigerator Door Bin In Stock WPL WP2204812 $50.01

11

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

12

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

12

Refrigerator Control Box WPL 2200820 Contact Us For Availability

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

Shim WPL 2172743 Contact Us For Availability

Refrigerator Inlet Tube WPL 2174755 Contact Us For Availability

Refrigerator Thermostat WPL 2200830 Contact Us For Availability

13A

4387913 Whirlpool Refrigerator Primary Overlo In Stock WPL 4387913 $35.14

14

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

14

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

14

Refrigerator Defrost Timer Clip WPL 2176341 Contact Us For Availability

14A

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $3.70

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

15

Refrigerator Screw WPL 489412 Contact Us For Availability

WP2254618 Whirlpool Center Door Hinge In Stock WPL WP2254618 $27.91

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

Refrigerator Clip WPL 2166683 Contact Us For Availability

Refrigerator Evaporator Cover WPL 2189823 Contact Us For Availability

4388239 Whirlpool Refrigerator Primary Cabine Backorder WPL 4388239 $43.76

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $8.24

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

Refrigerator Freezer Door Shelf Trim WPL 2195947 Contact Us For Availability

18

Refrigerator Cold Control Sensor Thermal Weig WPL 2200831 Contact Us For Availability

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $15.76

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

Refrigerator Defrost Heater Bracket WPL 2182338 Contact Us For Availability

Refrigerator Door Trim (White) WPL 2193144W Contact Us For Availability

20

WP2254473 Whirlpool Refrigerator Door Hinge In Stock WPL WP2254473 $3.70

20

Refrigerator Wire Harness WPL 2200630 Contact Us For Availability

21

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

21

Refrigerator Air Damper Cover WPL 2176281 Contact Us For Availability

22

W10829461 Whirlpool Refrigerator Thermal Knob Backorder WPL W10829461 $12.08

22

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $17.55

22

Refrigerator Support Evaporator WPL 2189906 Contact Us For Availability

23

Refrigerator Freezer Air Tower WPL 2182340 Contact Us For Availability

23

Refrigerator Compressor Start Relay WPL 2176805 Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $29.83

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $47.43

Refrigerator Compressor Access Panel WPL 2198740 Contact Us For Availability

25

Refrigerator Freezer Floor WPL 2184617 Contact Us For Availability

26

Refrigerator Diffuser WPL 2204690 Contact Us For Availability

27

WP2151652 Whirlpool Refrigerator Button Plug In Stock WPL WP2151652 $8.20

27

WP2217784 Whirlpool Refrigerator Cover Backorder WPL WP2217784 $17.79

27A

Refrigerator Button Plug WPL 2201013 Contact Us For Availability

28

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

28

Plug WPL 1103725 Contact Us For Availability

29

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $24.91

29

Refrigerator Motor Bracket WPL 2200511 Contact Us For Availability

30

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

31

WP627792 Whirlpool Refrigerator Shut Off Arm In Stock WPL WP627792 $39.24

31

Refrigerator Water Inlet Valve Cover WPL 2166251 Contact Us For Availability

32

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

32

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $25.41

32A

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $90.19

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

33

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

34

Refrigerator Knob Damper WPL 2176297 Contact Us For Availability

35

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $30.52

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

35A

Filler Al WPL 2201015 Contact Us For Availability

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

36

Refrigerator Grille WPL 2201006 Contact Us For Availability

36A

Refrigerator Grille WPL 2201007 Contact Us For Availability

37

Refrigerator Toe Grille Clip WPL 2189356 Contact Us For Availability

37

Post Damper WPL 2179859 Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

39

Refrigerator Condenser Fan Shroud WPL 2198921 Contact Us For Availability

40

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

40

Refrigerator Bracket WPL 2163810 Contact Us For Availability

40A

Refrigerator Hinge Cover (Almond) WPL 2160404 Contact Us For Availability

41

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $6.28

42

Refrigerator Wire Harness WPL 2200798 Contact Us For Availability

43

Refrigerator Condenser Fan WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Refrigerator Cover Unit WPL 2200508 Contact Us For Availability

45

Refrigerator Insulation WPL 2200778 Contact Us For Availability

46

Refrigerator Tube WPL 2184451 Contact Us For Availability

47

Refrigerator Tube WPL 2189173 Contact Us For Availability

48

2154109 Whirlpool Refrigerator Tube Backorder WPL 2154109 $37.73

49

Refrigerator Tube WPL 2174670 Contact Us For Availability

56

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

57

Refrigerator Screw WPL 489462 Contact Us For Availability

58

Refrigerator Drain Pan WPL 2189433 Contact Us For Availability

NI01

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.82

NI02

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $35.96

NI03

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $37.79

NI05

Refrigerator Service Valve WPL 978029 Contact Us For Availability

NI06

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $39.53

NI07

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

NI10

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $30.25

NI11

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

NI14

Foam Slab WPL 876029 Contact Us For Availability

NI15

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $64.36

NI16

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

NI17

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $24.56

NI19

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $29.17

NI22

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $43.61

NI23

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.33

NI25

350930 Whirlpool White Spray Paint In Stock WPL 350930 $21.41

NI26

350956 Whirlpool Spray Assembly In Stock WPL 350956 $28.82

NI27

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.92

NI28

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

NI29

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

NI30

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

NI32

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

NI36

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability
