Bosch WFE2020GB/12 Parts List

Model Bosch WFE2020GB/12 Washer – Common Parts & Diagrams

Common parts from model Bosch WFE2020GB/12 Washer

00153813 Bosch Laundry Auxiliary Tool

00153813 Bosch Laundry Auxiliary Tool Backorder BOS 00153813 $8.24

00493529 Bosch Laundry Fixing Kit

00493529 Bosch Laundry Fixing Kit Backorder BOS 00493529 $52.16

00606923 Bosch Laundry Holder

00606923 Bosch Laundry Holder Backorder BOS 00606923 $5.49

00118917 Bosch Laundry Lock Clamp

00118917 Bosch Laundry Lock Clamp Backorder BOS 00118917 $17.39

00171270 Bosch Screw

00171270 Bosch Screw Backorder BOS 00171270 $3.66

Pulley

Pulley BOS 00118921 Contact Us For Availability

00056766 Bosch Laundry Shaft Seal

00056766 Bosch Laundry Shaft Seal Backorder BOS 00056766 $43.01

00086309 Bosch Laundry Bearing Set

00086309 Bosch Laundry Bearing Set Backorder BOS 00086309 $129.94

00278339 Bosch Washer Drive Belt

00278339 Bosch Washer Drive Belt Backorder BOS 00278339 $34.77

00263726 Bosch Laundry Heating Element

00263726 Bosch Laundry Heating Element Backorder BOS 00263726 $95.93

00066212 Bosch Laundry Guide Spring

00066212 Bosch Laundry Guide Spring Backorder BOS 00066212 $15.56

00056764 Bosch Laundry Spring Tank

00056764 Bosch Laundry Spring Tank Backorder BOS 00056764 $30.20

Spring guide

Spring guide BOS 00029863 Contact Us For Availability

00056765 Bosch Laundry Spring

00056765 Bosch Laundry Spring Backorder BOS 00056765 $21.96

00118869 Bosch Laundry Shock Absorber

00118869 Bosch Laundry Shock Absorber Backorder BOS 00118869 $70.59

Screw

Screw BOS 00059345 Contact Us For Availability

00059320 Bosch Laundry Holder

00059320 Bosch Laundry Holder Backorder BOS 00059320 $10.98

00154740 Bosch Washer Carbon Brush

00154740 Bosch Washer Carbon Brush In Stock BOS 00154740 $59.73

00167517 Bosch Laundry Carbon Brush

00167517 Bosch Laundry Carbon Brush In Stock BOS 00167517 $82.36

00289673 Bosch Laundry Agitator Paddle

00289673 Bosch Laundry Agitator Paddle Backorder BOS 00289673 $8.24

00118922 Bosch Laundry Sealing Assembly

00118922 Bosch Laundry Sealing Assembly Backorder BOS 00118922 $34.77

00289500 Bosch Laundry Boot Gasket

00289500 Bosch Laundry Boot Gasket Backorder BOS 00289500 $69.69

Hose connection inlet

Hose connection inlet BOS 00056769 Contact Us For Availability

00272654 Bosch Laundry Hose

00272654 Bosch Laundry Hose Backorder BOS 00272654 $66.97

00171263 Bosch Laundry Sump Ball

00171263 Bosch Laundry Sump Ball Backorder BOS 00171263 $11.90

00603523 Bosch Fastening Ring

00603523 Bosch Fastening Ring Backorder BOS 00603523 $12.81

00432060 Bosch Laundry Outlet Hose

00432060 Bosch Laundry Outlet Hose Backorder BOS 00432060 $40.26

00027696 Bosch Laundry Stud

00027696 Bosch Laundry Stud Backorder BOS 00027696 $11.90

00655300 Bosch Laundry Holder

00655300 Bosch Laundry Holder Backorder BOS 00655300 $13.73

00144487 Bosch Laundry Drain Pump

00144487 Bosch Laundry Drain Pump Backorder BOS 00144487 $121.93

00050871 Bosch Laundry Branching Piece

00050871 Bosch Laundry Branching Piece Backorder BOS 00050871 $31.11

00154645 Bosch Laundry Valve

00154645 Bosch Laundry Valve Backorder BOS 00154645 $46.67
