Model Samsung RS2533SW/XAA Refrigerator – Common Parts &amp; Diagrams

1

DA97-00258C Samsung Refrigerator Ice Maker As In Stock SMG DA97-00258C $149.91

1

DA97-01293D Samsung Refrigerator Multi Cover Backorder SMG DA97-01293D $75.01

1

Refrigerator power cord SMG DA39-10165E Contact Us For Availability

1

Handle assembly SMG DA97-00704H Contact Us For Availability

1

Refrigerator shelf assembly SMG DA97-00698F Contact Us For Availability

1

Refrigerator hinge assembly SMG DA97-02337B Contact Us For Availability

1

Refrigerator bucket SMG DA97-00685N Contact Us For Availability

1A

Assy-handl SMG DA97-00704L Contact Us For Availability

1B

DA97-00704M Samsung Assembly Handle Mid Front Backorder SMG DA97-00704M $54.57

2

DA61-70254A Samsung Refrigerator Gasket Suppo Backorder SMG DA61-70254A $71.51

2

DA63-02236A Samsung Refrigerator Ice Bucket T Backorder SMG DA63-02236A $5.82

2

DA67-00534K Samsung Refrigerator Low Shelf As Backorder SMG DA67-00534K $52.30

2

DA97-00699F Samsung Refrigerator Low Wire She Backorder SMG DA97-00699F $38.94

2

DA97-00703A Samsung Refrigerator Rear Handle Backorder SMG DA97-00703A $37.22

2

Refrigerator hinge assembly SMG DA97-02338B Contact Us For Availability

2

Pcb case SMG DA61-00261C Contact Us For Availability

2

Refrigerator filter housing SMG DA97-01666A Contact Us For Availability

2A

Handle assembly SMG DA97-00703F Contact Us For Availability

2B

DA97-00703G Samsung Refrigerator Rear Handle Backorder SMG DA97-00703G $54.30

3

DA97-00174L Samsung Assembly Tray-Chilled (65 Backorder SMG DA97-00174L $103.71

3

Refrigerator run capacitor SMG 2501-001045 Contact Us For Availability

3

Refrigerator fresh food evaporator cover asse SMG DA97-02427E Contact Us For Availability

3

Refrigerator door assembly SMG DA91-01605A Contact Us For Availability

3

Refrigerator freezer wire basket, upper SMG DA97-00701F Contact Us For Availability

3

Refrigerator hinge SMG DA97-01763A Contact Us For Availability

3

Refrigerator ice cover SMG DA63-00777E Contact Us For Availability

3

Refrigerator door assembly SMG DA91-01606C Contact Us For Availability

3A

DA97-00546J Samsung Refrigerator Water Dispen Backorder SMG DA97-00546J $7.74

3A

Freezer door SMG DA91-01766A Contact Us For Availability

3A

Refrigerator door SMG DA91-01765A Contact Us For Availability

3B

Refrigerator door assembly SMG DA91-01766B Contact Us For Availability

3B

Refrigerator door assembly SMG DA91-01765B Contact Us For Availability

4

DA63-02183A Samsung Refrigerator Sensor Cover In Stock SMG DA63-02183A $1.94

4

DA97-01760A Samsung Refrigerator Hinge Assemb Backorder SMG DA97-01760A $23.24

4

Refrigerator ice route cover assembly SMG DA97-01437C Contact Us For Availability

4

Refrigerator ice maker auger motor assembly SMG DA61-00262E Contact Us For Availability

4

Chute cap SMG DA67-00513A Contact Us For Availability

4

Refrigerator case assembly SMG DA97-00700F Contact Us For Availability

4

Fixer main SMG DA71-00155B Contact Us For Availability

4

Refrigerator water tank SMG DA97-00670D Contact Us For Availability

4

Refrigerator crisper drawer cover SMG DA63-00864C Contact Us For Availability

5

DA27-00002A Samsung Refrigerator Coil Assembl Backorder SMG DA27-00002A $71.24

5

DA63-01290B Samsung Refrigerator Wire Cover B Backorder SMG DA63-01290B $22.47

5

DA66-00268A Samsung Refrigerator Cam Riser As Backorder SMG DA66-00268A $1.94

5

Refrigerator crisper drawer assembly SMG DA97-00144P Contact Us For Availability

5

Refrigerator gasket SMG DA97-01800C Contact Us For Availability

5

Refrigerator evaporator assembly SMG DA96-00020G Contact Us For Availability

5A

Refrigerator ice dispenser lever SMG DA97-00545J Contact Us For Availability

6

6003-001435 Samsung Refrigerator Screw, Tap T Backorder SMG 6003-001435 $0.92

6

DA34-10110E Samsung Refrigerator Door Light S Backorder SMG DA34-10110E $34.11

6

DA41-00134F Samsung Refrigerator Main Electro Backorder SMG DA41-00134F $208.10

6

DA61-00524A Samsung Refrigerator Ice Full Gui Backorder SMG DA61-00524A $5.42

6

DA61-01587A Samsung Refrigerator Dispenser Gu Backorder SMG DA61-01587A $6.97

6

DA63-00865C Samsung Refrigerator Low Veg Cove Backorder SMG DA63-00865C $29.63

6

Refrigerator freezer guard SMG DA63-00895E Contact Us For Availability

6

Handle-tri SMG DA64-00418B Contact Us For Availability

6

Trim wire SMG DA64-00676B Contact Us For Availability

6

Refrigerator ice guide SMG DA71-70003A Contact Us For Availability

6A

Handle-tri SMG DA64-00418G Contact Us For Availability

6B

Handle-tri SMG DA64-00418H Contact Us For Availability

7

6011-001442 Samsung Refrigerator Socket Bolt Backorder SMG 6011-001442 $1.17

7

DA62-00565A Samsung Refrigerator Multi Seal Backorder SMG DA62-00565A $2.71

7

DA63-00827E Samsung Refrigerator Top Low Guar Backorder SMG DA63-00827E $24.12

7

DA63-00843E Samsung Refrigerator Dispenser Tr Backorder SMG DA63-00843E $4.65

7

DA97-00148P Samsung Refrigerator Vegetable Ca Backorder SMG DA97-00148P $87.98

7

Handle-tri SMG DA64-00416B Contact Us For Availability

7

Trim wire SMG DA64-00676A Contact Us For Availability

7

Refrigerator pcb cover SMG DA63-00783C Contact Us For Availability

7A

Handle-tri SMG DA64-00416F Contact Us For Availability

8

6021-001125 Samsung Refrigerator Hexagon Nut Backorder SMG 6021-001125 $2.71

8

DA34-10120E Samsung Refrigerator Door Switch Backorder SMG DA34-10120E $26.19

8

DA61-20124A Samsung Dispenser Spring Assembly Backorder SMG DA61-20124A $3.88

8

DA63-01453B Samsung Refrigerator Ice Tray Ass In Stock SMG DA63-01453B $6.59

8

DA67-40250E Samsung Refrigerator Utility Tray Backorder SMG DA67-40250E $29.98

8

Refrigerator handle SMG DA64-00413F Contact Us For Availability

8

Case wire SMG DA61-00778D Contact Us For Availability

8

Refrigerator machine compartment cover SMG DA63-01135A Contact Us For Availability

8

Refrigerator lamp holder SMG DA47-00112A Contact Us For Availability

8A

Refrigerator handle SMG DA64-00413K Contact Us For Availability

9

DA60-30105A Samsung Refrigerator Water Line N Backorder SMG DA60-30105A $1.17

9

DA62-00517A Samsung Refrigerator Multi Insula Backorder SMG DA62-00517A $9.68

9

DA63-50207C Samsung Hinge Shim - Lower Backorder SMG DA63-50207C $1.56

9

DA97-00918A Samsung Refrigerator Pipe Connect Backorder SMG DA97-00918A $48.51

9

Handle-tri SMG DA64-00415B Contact Us For Availability

9

Trim wire SMG DA64-00675B Contact Us For Availability

9

Blade-movi SMG DA31-20120D Contact Us For Availability

9A

Handle-tri SMG DA64-00415F Contact Us For Availability

6002-000213 Samsung Air Conditioner Tapping S Backorder SMG 6002-000213 $0.92

DA60-30104A Samsung Refrigerator Water Line N Backorder SMG DA60-30104A $1.56

DA61-01607A Samsung Hinge Low Backorder SMG DA61-01607A $24.12

DA62-20001P Samsung Refrigerator PVC Zipel Tu Backorder SMG DA62-20001P $3.09

Refrigerator freezer wire basket, upper SMG DA61-00777D Contact Us For Availability

Thermostat blade SMG DA31-20121B Contact Us For Availability

Refrigerator seal cover SMG DA62-00225A Contact Us For Availability

6002-000613 Samsung Refrigerator Tapping Scre Backorder SMG 6002-000613 $0.92

DA74-40149D Samsung Refrigerator Water Inlet Backorder SMG DA74-40149D $89.40

Refrigerator shelf trim SMG DA64-00670B Contact Us For Availability

Refrigerator hex screw SMG 6009-001255 Contact Us For Availability

Blade-movi SMG DA31-20120E Contact Us For Availability

Refrigerator tray assembly SMG DA97-01285C Contact Us For Availability

Air plate SMG DA61-00527A Contact Us For Availability

6002-000227 Samsung Tapping Screw Backorder SMG 6002-000227 $0.92

DA97-00259G Samsung Refrigerator Spiral Conde Backorder SMG DA97-00259G $116.75

Refrigerator shelf wire SMG DA67-00765D Contact Us For Availability

Refrigerator bracket SMG DA97-02243A Contact Us For Availability

Refrigerator blade SMG DA31-20122B Contact Us For Availability

Refrigerator seal cover SMG DA62-00074A Contact Us For Availability

DA31-20120F Samsung Blade Moving Dispense Ass Backorder SMG DA31-20120F $9.30

DA32-10105U Samsung Refrigerator Temperature Backorder SMG DA32-10105U $14.33

DA61-00309A Samsung Reinforcement Handle Mid Backorder SMG DA61-00309A $19.76

DA63-01291A Samsung Refrigerator Water Fill P Backorder SMG DA63-01291A $15.12

DA63-40171B Samsung Refrigerator Suction Pipe Backorder SMG DA63-40171B $2.32

DA67-00766D Samsung Refrigerator Mid Wire She Backorder SMG DA67-00766D $39.97

DA74-40151G Samsung Refrigerator Ice Dispense Backorder SMG DA74-40151G $89.76

DA97-02244A Samsung Refrigerator Hinge Bracke Backorder SMG DA97-02244A $27.56

DA32-10109W Samsung Refrigerator Temperature In Stock SMG DA32-10109W $17.06

DA47-00110C Samsung Refrigerator Water Pipe H Backorder SMG DA47-00110C $18.59

DA61-01608A Samsung Refrigerator Low Hinge Backorder SMG DA61-01608A $42.69

DA63-00713A Samsung Refrigerator Motor Cover Backorder SMG DA63-00713A $4.26

DA63-00821B Samsung Refrigerator Cover Multi Backorder SMG DA63-00821B $28.95

Refrigerator handle SMG DA64-00414B Contact Us For Availability

Bucket plate SMG DA70-00394A Contact Us For Availability

14A

DA64-00414H Samsung Rear Mid Refrigerator Han Backorder SMG DA64-00414H $46.37

DA63-40167A Samsung Refrigerator Grommet Cove Backorder SMG DA63-40167A $1.17

DA97-00707A Samsung Refrigerator Water Pipe A Backorder SMG DA97-00707A $22.05

Handle-tri SMG DA64-00417B Contact Us For Availability

Refrigerator tapping screw SMG 6002-001197 Contact Us For Availability

Seal-al fo SMG DA62-00133B Contact Us For Availability

15A

Handle-tri SMG DA64-00417G Contact Us For Availability

15B

Handle-tri SMG DA64-00417H Contact Us For Availability

4713-001172 Samsung Refrigerator Incandescent Backorder SMG 4713-001172 $10.07

DA61-20139A Samsung Ice Maker Spring Assembly Backorder SMG DA61-20139A $4.26

DA63-00822L Samsung Refrigerator Front Leg Co Backorder SMG DA63-00822L $35.83

DA72-60040D Samsung Seal Cut Rubber Backorder SMG DA72-60040D $3.09

DA73-00070K Samsung Refrigerator Water Line P Backorder SMG DA73-00070K $17.44

Refrigerator door stopper SMG DA61-00430A Contact Us For Availability

16A

Refrigerator leg cover SMG DA63-00822R Contact Us For Availability

DA63-50192A Samsung Refrigerator Upper Hinge Backorder SMG DA63-50192A $1.17

DA97-00708B Samsung Water Pipe Assembly Backorder SMG DA97-00708B $61.97

Refrigerator hinge cam SMG DA66-90112C Contact Us For Availability

Refrigerator lamp cover SMG DA63-00813A Contact Us For Availability

6001-000716 Samsung Refrigerator Machine Scre Backorder SMG 6001-000716 $0.92

DA31-00020H Samsung Refrigerator BLDC Compres Backorder SMG DA31-00020H $107.26

DA61-01603B Samsung Hinge Up Left Assembly Backorder SMG DA61-01603B $26.19

DA61-01797A Samsung Fixer Grommet Door Assemb Backorder SMG DA61-01797A $0.92

DA66-90003A Samsung Refrigerator Solenoid Gea Backorder SMG DA66-90003A $0.92

Refrigerator ice bin auger drum SMG DA31-20009A Contact Us For Availability

DA63-00828D Samsung Refrigerator Door Bin Backorder SMG DA63-00828D $34.11

Refrigerator hinge cover SMG DA63-02261E Contact Us For Availability

Clamp-heli SMG DA65-00023A Contact Us For Availability

Refrigerator support SMG DA61-00244B Contact Us For Availability

Support-ci SMG DA61-00415A Contact Us For Availability

Refrigerator tapping screw SMG 6002-000601 Contact Us For Availability

19A

Refrigerator door hinge cover SMG DA63-02261M Contact Us For Availability

DA66-30138A Samsung Refrigerator Dispenser Le Backorder SMG DA66-30138A $7.74

DA67-30266K Samsung Refrigerator Cap Screw Backorder SMG DA67-30266K $0.92

DA71-00090A Samsung Refrigerator Bottle Guide Backorder SMG DA71-00090A $5.42

DA74-40154F Samsung Refrigerator Solenoid Val Backorder SMG DA74-40154F $61.40

DA96-00042A Samsung Refrigerator Motor Harnes Backorder SMG DA96-00042A $10.85

Fixer case SMG DA71-20270A Contact Us For Availability

6009-001252 Samsung Refrigerator Special Scre Backorder SMG 6009-001252 $1.17

DA61-60001A Samsung Refrigerator Dispenser So Backorder SMG DA61-60001A $0.92

DA63-00836D Samsung Refrigerator Dairy Guard Backorder SMG DA63-00836D $41.16

Refrigerator water supply tube cover SMG DA63-01275A Contact Us For Availability

Refrigerator ice container SMG DA63-00775D Contact Us For Availability

Amana refrigerator screw SMG 6002-001204 Contact Us For Availability

Assy cover-filter SMG DA97-00724C Contact Us For Availability

21A

Refrigerator cover tube SMG DA63-01275C Contact Us For Availability

DA63-00825A Samsung Refrigerator Dairy Bin Co Backorder SMG DA63-00825A $23.24

DA63-02262E Samsung Refrigerator Right Hinge Backorder SMG DA63-02262E $18.21

DA66-00034A Samsung Refrigerator Drain Water Backorder SMG DA66-00034A $19.76

Refrigerator water filter SMG DA29-00003A Contact Us For Availability

22A

DA63-02262M Samsung Refrigerator Hinge Cover Backorder SMG DA63-02262M $18.21

6002-000471 Samsung Refrigerator Screw Backorder SMG 6002-000471 $0.92

DA97-00697D Samsung Refrigerator Dairy Guard Backorder SMG DA97-00697D $55.71

Refrigerator door hinge SMG DA61-01604B Contact Us For Availability

Refrigerator turbo fan SMG DA31-00015C Contact Us For Availability

Fixer-air SMG DA61-00413A Contact Us For Availability

24

DA63-00814E Samsung Refrigerator Lamp Cover T Backorder SMG DA63-00814E $11.62

24

Refrigerator door gasket SMG DA97-01800D Contact Us For Availability

24

Refrigerator ice dispenser bucket seal SMG DA72-60315A Contact Us For Availability

25

DA31-00010D Samsung Refrigerator Fan Blade In Stock SMG DA31-00010D $13.18

25

Refrigerator air freshener filter SMG DA02-90106K Contact Us For Availability

DA31-00053A Samsung Refrigerator Backward Fan Backorder SMG DA31-00053A $17.44

DA60-20008A Samsung Hex Bolt Backorder SMG DA60-20008A $3.09

DA63-00855D Samsung Purifier Cover Assembly Backorder SMG DA63-00855D $5.42

Seal-pom SMG DA72-60313A Contact Us For Availability

DA61-00417A Samsung Refrigerator Motor Case Backorder SMG DA61-00417A $20.15

DA71-20231A Samsung Refrigerator Fixer Guard Backorder SMG DA71-20231A $2.71

Backorder SMG DA73-30102B $17.44

Refrigerator air filter cover SMG DA63-00856C Contact Us For Availability

28

DA61-00775A Samsung Refrigerator Dispenser St Backorder SMG DA61-00775A $0.92

28

MK183CL2U/E07 Samsung Refrigerator Compressor Backorder SMG MK183CL2U/E07 $233.08

28

Refrigerator freezer evaporator cover SMG DA63-00812B Contact Us For Availability

DA60-30108A Samsung Refrigerator Hex Nut Backorder SMG DA60-30108A $3.09

DA61-00565A Samsung Refrigerator Ice Route Co Backorder SMG DA61-00565A $1.94

DA63-01809A Samsung Refrigerator BLDC Motor C Backorder SMG DA63-01809A $10.07

DA63-02017A Samsung Refrigerator Compressor G Backorder SMG DA63-02017A $3.09

Refrigerator water reservoir heater SMG DA47-00094C Contact Us For Availability

30

DA34-10003S Samsung Refrigerator Compressor O In Stock SMG DA34-10003S $19.82

30

DA63-10016A Samsung Refrigerator Dispenser Cr Backorder SMG DA63-10016A $26.19

31

DA63-01808A Samsung Refrigerator Front Motor Backorder SMG DA63-01808A $3.09

31

Refrigerator compressor start relay SMG DA35-10013Q Contact Us For Availability

31

Plate washer SMG DA60-40116A Contact Us For Availability

32

DA31-00020E Samsung Refrigerator Freezer Evap In Stock SMG DA31-00020E $117.04

32

DA63-01866A Samsung Refrigerator Compressor O Backorder SMG DA63-01866A $10.85

33

DA39-00060K Samsung Refrigerator Motor with H Backorder SMG DA39-00060K $111.53

33

DA39-00084D Samsung Refrigerator Relay Wire H Backorder SMG DA39-00084D $12.39

33

DA61-00774A Samsung Refrigerator Case Motor Backorder SMG DA61-00774A $10.47

34

DA60-10107A Samsung Screw Machine Backorder SMG DA60-10107A $1.94

34

DA63-01146A Samsung Refrigerator Rear Motor G Backorder SMG DA63-01146A $3.50

34

Refrigerator fan motor SMG DA31-00002S Contact Us For Availability

35

DA63-40119A Samsung Refrigerator Grommet for In Stock SMG DA63-40119A $1.56

35

DA97-00555D Samsung Refrigerator Compressor C Backorder SMG DA97-00555D $97.54

36

DA60-10004A Samsung Hex Bolt Backorder SMG DA60-10004A $1.17

36

Refrigerator evaporator assembly SMG DA59-00233H Contact Us For Availability

36

Refrigerator tapping screw SMG 6002-000480 Contact Us For Availability

37

DA60-90146A Samsung Refrigerator Caster Pin M Backorder SMG DA60-90146A $1.56

37

DA63-01283A Samsung Refrigerator Motor Cover Backorder SMG DA63-01283A $6.59

38

DA31-00016A Samsung Evaporator Circuit Fan Bl Backorder SMG DA31-00016A $9.30

38

Refrigerator defrost bi-metal thermostat SMG DA47-10160H No Longer Available

38

DA61-40126B Samsung Refrigerator Rear Caster Backorder SMG DA61-40126B $2.32

39

DA61-20128A Samsung Refrigerator Spring and F Backorder SMG DA61-20128A $0.92

40

DA65-20110B Samsung Refrigerator Cable Clamp Backorder SMG DA65-20110B $3.50

40

Plate evaporator SMG DA61-00827A Contact Us For Availability

41

DA71-20208A Samsung Refrigerator Water Valve Backorder SMG DA71-20208A $0.92

41

Refrigerator spacer evaporator SMG DA60-00042A Contact Us For Availability

41

Seal-air r SMG DA62-00083A Contact Us For Availability

42

DA62-00158A Samsung Evaporator Cover Seal Backorder SMG DA62-00158A $0.92

42

DA62-00224B Samsung Refrigerator Check Valve Backorder SMG DA62-00224B $60.27

42

Refrigerator evaporator drip pan heater SMG DA97-00111C Contact Us For Availability

43

DA71-20207A Samsung Refrigerator Water Valve Backorder SMG DA71-20207A $0.92

43

Refrigerator defrost drain trough heater SMG DA47-00090C Contact Us For Availability

44

DA61-00477A Samsung Refrigerator Drain Plate Backorder SMG DA61-00477A $24.47

44

Refrigerator spacer evaporator SMG DA60-00041A Contact Us For Availability

44

Caster, front SMG DA61-00056A Contact Us For Availability

45

DA32-10105R Samsung Refrigerator Defrost Temp In Stock SMG DA32-10105R $20.15

45

DA61-30102A Samsung Refrigerator Front Foot Backorder SMG DA61-30102A $10.47

45

Refrigerator freezer evaporator assembly SMG DA96-00021N Contact Us For Availability

46

DA47-00095E Samsung Refrigerator Thermal Fuse In Stock SMG DA47-00095E $19.41

46

DA60-10122C Samsung Screw-HEX;HH,-,-,-,M5,L16 Backorder SMG DA60-10122C $0.92

46

Multi-cover SMG DA63-02179A Contact Us For Availability

47

DA60-90124A Samsung Rivet Backorder SMG DA60-90124A $0.92

47

DA61-00453A Samsung Refrigerator Ice Maker Se Backorder SMG DA61-00453A $0.92

47

Refrigerator insulation SMG DA62-00761A Contact Us For Availability

48

Refrigerator evaporator SMG DA59-00234H Contact Us For Availability

48

Refrigerator insulation SMG DA62-00762A Contact Us For Availability

48

Caster, front SMG DA61-40115A Contact Us For Availability

49

DA39-20389E Samsung Refrigerator Earth Wire H Backorder SMG DA39-20389E $0.92

49

DA61-00299C Samsung Refrigerator Basket Rail Backorder SMG DA61-00299C $7.74

50

Refrigerator crisper drawer slide rail SMG DA97-00730G Contact Us For Availability

51

Refrigerator basket rail assembly SMG DA61-00298C Contact Us For Availability

52

Refrigerator crisper drawer slide rail SMG DA97-00731G Contact Us For Availability

53

Grommet SMG DA63-00202A Contact Us For Availability

54

Chiller rail SMG DA61-00294B Contact Us For Availability

55

Refrigerator rail assembly SMG DA97-00173C Contact Us For Availability

56

Refrigerator rail SMG DA61-00295B Contact Us For Availability

57

Refrigerator top right rail assembly SMG DA97-00159C Contact Us For Availability

NI

Refrigerator door foam assembly SMG NLA Contact Us For Availability

NI

See note (qty 12) screw-tapping currently SMG 00000000 Contact Us For Availability
