Model Electrolux TSX120EN0F REFRIGERATOR – Common Parts & Diagrams
02 - DOOR PARTS
03 - CABINET PARTS
04 - RACKS AND TRAYS
05 - SYSTEM AND AUTOMATIC DEFROST PARTS
Common parts from model Electrolux TSX120EN0F REFRIGERATOR
*17035
WCI G162977-10 WCI G162977-10 Contact Us For Availability
*17040
KIT-DOOR CONVERSION-COFE WCI G168981-10 Contact Us For Availability
*17083
COVER-HINGE COFE WCI G183558-10 Contact Us For Availability
*17103
WCI G164571 WCI G164571 Contact Us For Availability
*17104
HARNESS-WIRE WCI G174917 Contact Us For Availability
*17106
PLATE, TAPPING (2) WCI G157591 Contact Us For Availability
*17107
PLUG BUTTON LINER (2) WCI G162892-01 Contact Us For Availability
*17125
HOT TUBE REPAIR KIT WCI G189377 Contact Us For Availability
*17127
HARNESS-COMP WIRING WCI G166062-01 Contact Us For Availability
1
WCI G189991-10 WCI G189991-10 Contact Us For Availability
1
BRACKET-MTR MTG REAR WCI G185303 Contact Us For Availability
1
BOTTOM ( FREEZER ) WCI G162857 Contact Us For Availability
2
LABEL-NAMEPLATE WCI G189500-01 Contact Us For Availability
2
DIVIDER WCI G163219 Contact Us For Availability
2
BLOCK, EVAPORATOR, RH WCI G185299 Contact Us For Availability
3
WCI G178292 WCI G178292 Contact Us For Availability
3
TROUGH-DRAIN WCI G163216 Contact Us For Availability
3
TOP-REFRIGERATOR WCI G174713 Contact Us For Availability
3
WCI G164637 WCI G164637 Contact Us For Availability
3A
TAPE-DOUBLE FACED (NON-ILLUSTRATED) WCI G153407-60 Contact Us For Availability
4
WCI G164867 WCI G164867 Contact Us For Availability
4
COVER-COIL WCI G163214 Contact Us For Availability
4
WCI G187921 WCI G187921 Contact Us For Availability
4
WCI G164924 WCI G164924 Contact Us For Availability
5
WCI G189454-02 WCI G189454-02 Contact Us For Availability
5A
INSERT-HANDLE GRIP (2) (NON-ILLUSTRATED) WCI G189456-01 Contact Us For Availability
6
END-HANDLE-TOP WCI G189452-01 Contact Us For Availability
6
BRACKET-MTR MTG FRONT WCI G185302 Contact Us For Availability
6
SPACER-MULLION MTG WCI G166848 Contact Us For Availability
6
EXCHANGER-HEAT WCI G149013 Contact Us For Availability
7
END-HANDLE (2) WCI G189453-01 Contact Us For Availability
7
WASHER-NO. 10 (2) WCI G166847 Contact Us For Availability
8
END-HANDLE BOTTOM WCI G189451-01 Contact Us For Availability
8
RING, FAN ORIFICE WCI G167217 Contact Us For Availability
8
WCI G166709 WCI G166709 Contact Us For Availability
8A
NUT-ORIFICE (2) (NON-ILLUSTRATED) WCI G167542 Contact Us For Availability
9
WCI G164861 WCI G164861 Contact Us For Availability
9
SCREW-MULLION (2) WCI G183103 Contact Us For Availability
10
PANEL-INNER FRZR WCI G180238-01 Contact Us For Availability
10
NUT, PUSH WCI G162662 Contact Us For Availability
10
MULLION-COFE WCI G174520-10 Contact Us For Availability
10
CORD, SERVICE WCI G162549-01 Contact Us For Availability
11
WCI G162747-27 WCI G162747-27 Contact Us For Availability
11
CLIP-COMP MTG (3) WCI G163204 Contact Us For Availability
12
WCI G166151-03 WCI G166151-03 Contact Us For Availability
12
WCI 3015462 WCI 3015462 Contact Us For Availability
12
CONTROL-TEMP. WCI G162205-12 Contact Us For Availability
12
WASHER-COMP MTG (3) WCI G164634 Contact Us For Availability
13
RACK-FREEZER WCI G161019-84 Contact Us For Availability
13
DAMPER FAN COVER WCI G162661 Contact Us For Availability
13
WCI G176722-03 WCI G176722-03 Contact Us For Availability
14
GASKET-FREEZER WCI G186932-05 Contact Us For Availability
14
TUBE, RUBBER WCI G85642 Contact Us For Availability
14
LABEL-CONTROL BOX WCI G189710 Contact Us For Availability
14
WCI G188885-01 WCI G188885-01 Contact Us For Availability
15
DOOR, DAIRY WCI G161776-51 Contact Us For Availability
15
WCI G163669 WCI G163669 Contact Us For Availability
15
SWITCH SLIDE WCI G178402-01 Contact Us For Availability
15
STRAP-CAPAC MTG WCI G188897 Contact Us For Availability
16
RACK-REFRIG (2) WCI G161019-85 Contact Us For Availability
16
WCI G183861 WCI G183861 Contact Us For Availability
17
PANEL-INNER REF WCI G180236-01 Contact Us For Availability
17
BRACKET, TOP HINGE WCI G183714 Contact Us For Availability
18
WCI G103903 No Longer Available
18
SOCKET LIGHT WCI G168302 Contact Us For Availability
18
CLIP-OVERLOAD WCI G188957 Contact Us For Availability
19
GASKET-REFRIG WCI G186932-04 Contact Us For Availability
19
TRIM-CAB CORNER (4)-COFE WCI G162364-10 Contact Us For Availability
19
WCI G107080 WCI G107080 Contact Us For Availability
19
PLATE-COMP MTG WCI G162822 Contact Us For Availability
20
BEARING HINGE (8) WCI G183138 Contact Us For Availability
20
WASHER-NYLON (2) WCI G164355 Contact Us For Availability
20
KNOB, CONTROL WCI G490107-02 Contact Us For Availability
20
WCI G188877 WCI G188877 Contact Us For Availability
21
WCI G189994-10 WCI G189994-10 Contact Us For Availability
21
WCI G142220 WCI G142220 Contact Us For Availability
21
WCI G172172-01 WCI G172172-01 Contact Us For Availability
21
WCI G182225-18 WCI G182225-18 Contact Us For Availability
22
WCI G163207 WCI G163207 Contact Us For Availability
22
COMPRESSOR WCI G190360 Contact Us For Availability
23
DEFLECTOR AIR WCI G162675 Contact Us For Availability
23
WCI G162957-02 WCI G162957-02 Contact Us For Availability
23
PAN, DEFROST WCI G184715 Contact Us For Availability
24
COVER, AIR DEFLECTOR WCI G162178 Contact Us For Availability
24
WCI 3015463 WCI 3015463 Contact Us For Availability
24
NUT, LOCK WCI G164958 Contact Us For Availability
25
SUPPORT-CRISPER CVR WCI G166310-02 Contact Us For Availability
25
BLOCK-EVAPORATOR LH WCI G188375 Contact Us For Availability
26
BRACKET, LOWER HINGE WCI G181019 Contact Us For Availability
26
STRAP-ALUMINUM (2) WCI G165548 Contact Us For Availability
27
SHIM, LOWER HINGE WCI G163203 Contact Us For Availability
27
WCI G162432-01 WCI G162432-01 Contact Us For Availability
28
PLUG-BUTTON WCI G166912 Contact Us For Availability
28
EVAPORATOR WCI G162297 Contact Us For Availability
29
SCREW, LEVELING (2) WCI G185713 Contact Us For Availability
29
INSULATOR-PLASTIC WCI G169024-01 Contact Us For Availability
29A
NUT ANCHOR (2) (NON-ILLUSTRATED) WCI G183073 Contact Us For Availability
30
TUBE-DRAIN WCI G163205 Contact Us For Availability
31
BASE-CABINET WCI G161998-01 Contact Us For Availability
32
WCI G174747-10 WCI G174747-10 Contact Us For Availability
33
WCI G174733 WCI G174733 Contact Us For Availability
34
WCI G174734 WCI G174734 Contact Us For Availability
× ![]()
