Model Whirlpool TMH14XMD2 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

1

Deflector, Air WPL 8185096 Contact Us For Availability

1

Cover, Inlet WPL 8185255 Contact Us For Availability

2

Socket, Motor Wire WPL 8185097 Contact Us For Availability

2

Cover, Hole WPL 8169448 Contact Us For Availability

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $55.48

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Base Plate WPL 8205563 Contact Us For Availability

3

Nails/Bushings (5 of each) WPL 8184549 Contact Us For Availability

4

Turntable WPL 4393799 Contact Us For Availability

4

Air Guide (Right) WPL 8185098 Contact Us For Availability

5

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $20.42

5

Thermostat WPL 4393945 Contact Us For Availability

6

W10708076 Whirlpool Microwave Power Cord In Stock WPL W10708076 $8.66

6

Complete Door WPL 8205793 Contact Us For Availability

6

Deflector, Cooling Air WPL 8185099 Contact Us For Availability

7

8169738 Whirlpool Microwave Door Handle In Stock WPL 8169738 $54.85

7

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $2.91

7

W10435116 Whirlpool Microwave Turntable Rolle In Stock WPL W10435116 $12.02

7

Case, Outer WPL 8185093 Contact Us For Availability

8

8184608 Whirlpool Microwave Oven Vent Grille In Stock WPL 8184608 $37.10

8

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $79.94

8

TCO, Bracket Assembly WPL 8205578 Contact Us For Availability

8

Cooling Air Guide WPL 8185215 Contact Us For Availability

9

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $2.51

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $2.73

9

Motor, Fan WPL 8184825 Contact Us For Availability

9

Cover, Terminal WPL 4393756 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $32.67

W10844213 Whirlpool Microwave Magnetron Backorder WPL W10844213 $152.26

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $2.51

Shield WPL 8205355 Contact Us For Availability

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

11

Thermostat WPL 8183698 Contact Us For Availability

11

Air Guide, Sealing Plate WPL 8204996 Contact Us For Availability

12

Plate, Cam (2) WPL 8183824 Contact Us For Availability

12

Screw WPL 4393828 Contact Us For Availability

13

8205572 Whirlpool Microwave Interlock In Stock WPL 8205572 $3.70

13

Screw WPL 4393838 Contact Us For Availability

14

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $2.51

14

Block, Transformer WPL 8205579 Contact Us For Availability

14

Screw WPL 8169478 Contact Us For Availability

15

Screw WPL 4393833 Contact Us For Availability

15

Air Guide, Cooling WPL 8205580 Contact Us For Availability

15

Screw WPL 4393830 Contact Us For Availability

16

Socket, Light WPL 8169539 Contact Us For Availability

16

Air Guide (Left) WPL 8185115 Contact Us For Availability

16

Left Block, Magnetron WPL 8205583 Contact Us For Availability

17

Chassis WPL 8205582 Contact Us For Availability

17

Cover, Light WPL 8185118 Contact Us For Availability

17

Middle Block, Magnetron WPL 8205584 Contact Us For Availability

8205948 Whirlpool Microwave Mount In Stock WPL 8205948 $7.89

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $3.00

Holder, Capacitor WPL 8185102 Contact Us For Availability

Upper Template WPL 8184731 Contact Us For Availability

Cover, Motor WPL 8185090 Contact Us For Availability

Main Harness WPL 8205632 Contact Us For Availability

Lamp Wire Assy. WPL 8205633 Contact Us For Availability

H.V. Wire Assy. WPL 8205634 Contact Us For Availability

Ground Wire Assy. WPL 8205635 Contact Us For Availability

Miscellaneous WPL ARI131652A Contact Us For Availability

Right Block, Magnetron WPL 8205585 Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $10.01

19

Filter WPL 8169561 Contact Us For Availability

20

W10850446 Whirlpool Microwave Magnetron Capac In Stock WPL W10850446 $118.69

21

Transformer, H.V. WPL 8205560 Contact Us For Availability

23

W10269458 Whirlpool Microwave Door Switch In Stock WPL W10269458 $15.87

24

W10211974 Whirlpool Microwave Door Interlock In Stock WPL W10211974 $24.34

25

Bracket, Right WPL 8205559 Contact Us For Availability

26

Capacitor WPL 8184091 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $19.18

29

Thermostat WPL 8183703 Contact Us For Availability

30

Screw WPL 8169474 Contact Us For Availability

31

Air guide, Magnetron WPL 8205581 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $2.73

37

Screw WPL 4393839 Contact Us For Availability

38

Resistor WPL 8205152 Contact Us For Availability
