Model Whirlpool TGS326MS1 30`` GAS FREESTANDING SELF CLEAN RANGE – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

814381 Whirlpool Pin Backorder WPL 814381 $3.70

8523599 Whirlpool Oven Wire Harness Backorder WPL 8523599 $76.96

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WP9781235 Whirlpool Clip Backorder WPL WP9781235 $5.22

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $28.80

WPL 8524207 WPL 8524207 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

1

W11457094 Whirlpool Oven Flue Backorder WPL W11457094 $82.95

1

WP8273096 Whirlpool Screw Backorder WPL WP8273096 $2.51

1

Guide, Use & Care WPL LIT9756131 Contact Us For Availability

1

Literature Parts (Install, Instr (French)) WPL LIT9756849 Contact Us For Availability

1

Literature Parts (Instructions, Installation) WPL LIT9756904 Contact Us For Availability

2

WP3191898 Whirlpool Surface Burner Cap Black Backorder WPL WP3191898 $42.16

2

WP3191901 Whirlpool Burner Cap Backorder WPL WP3191901 $54.85

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $41.94

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $2.51

2

WP8272747 Whirlpool Heat Shield Backorder WPL WP8272747 $26.21

2

WP8273700 Whirlpool Base Burner In Stock WPL WP8273700 $55.66

3

W11379351 Whirlpool Burner Box Backorder WPL W11379351 $34.99

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $167.94

3

Tubing, Burner W/Orifice (Right Front) WPL 8273695 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Rear) WPL 8273697 Contact Us For Availability

3

Tubing, Burner W/Orifice (Left Rear) WPL 8273698 Contact Us For Availability

3

Tubing, Burner W/Orifice (Left Front) WPL 8273699 Contact Us For Availability

4

W11730303 Whirlpool Side Panel In Stock WPL W11730303 $58.52

4

WP4455979 Whirlpool Range Small Burner Head Backorder WPL WP4455979 $34.15

4

WP4455980 Whirlpool Burner Head Backorder WPL WP4455980 $37.44

4

Screw WPL 4449746 Contact Us For Availability

4

Tubing (Manifold to Regulator) WPL 8523402 Contact Us For Availability

5

W11213958 Whirlpool Oven Cooktop Backorder WPL W11213958 $266.02

5

WPW10295998 Whirlpool Wire Harness In Stock WPL WPW10295998 $81.56

5

Shield, Heat (2) WPL 8524111 Contact Us For Availability

6

8053505 Whirlpool Oven Shield Backorder WPL 8053505 $54.35

6

8523249 Whirlpool Oven Support Bracket Backorder WPL 8523249 $24.74

6

8523855 Whirlpool Oven Manifold Panel Backorder WPL 8523855 $61.99

6

WP8053948 Whirlpool Door Glass In Stock WPL WP8053948 $67.09

6

WP8523793 Whirlpool Oven Surface Igniter In Stock WPL WP8523793 $17.68

7

WP8273103 Whirlpool Black Control Knob In Stock WPL WP8273103 $9.46

7

Pipe, Manifold WPL 8523407 Contact Us For Availability

7

Shield, Heat (2) WPL 3196136 Contact Us For Availability

8

WP9757218 Whirlpool Burner Valve In Stock WPL WP9757218 $122.66

8

Valve (1) WPL 8273004 Contact Us For Availability

8

Frame, Front Not Serviced WPL ARI131553A Contact Us For Availability

9

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $26.50

9

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $3.70

9

Nut (4) WPL 8273060 Contact Us For Availability

10

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $2.51

10

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

10

Hinge, Door (2) WPL 8272822 Contact Us For Availability

11

WP3195097 Whirlpool Oven Bottom In Stock WPL WP3195097 $81.40

11

WPW10268483 Whirlpool Grate Kit In Stock WPL WPW10268483 $80.83

12

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $93.47

12

WPW10181986 Whirlpool Oven Sensor In Stock WPL WPW10181986 $50.55

12

Trim, Bottom WPL 8053950 Contact Us For Availability

13

8053967 Whirlpool Oven Heat Baffle Backorder WPL 8053967 $106.98

13

Spreader, Flame (Oven) WPL 8053970 Contact Us For Availability

8053969 Whirlpool Heat Shield Backorder WPL 8053969 $36.58

WP3368921 Whirlpool Screw In Stock WPL WP3368921 $1.52

WP8523180 Whirlpool Door Trim Assembly Backorder WPL WP8523180 $53.11

WP9758078 Whirlpool Oven Burner In Stock WPL WP9758078 $94.99

15

8053968 Whirlpool Oven Heat Shield Backorder WPL 8053968 $29.43

15

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

15

WPW10293048 Whirlpool Gas Valve In Stock WPL WPW10293048 $313.77

16

WP8054129 Whirlpool Oven Igniter In Stock WPL WP8054129 $70.95

16

WP9758079 Whirlpool Oven Igniter In Stock WPL WP9758079 $26.99

16

WPW10306546 Whirlpool Base Rail Backorder WPL WPW10306546 $50.64

17

Tubing (Broiler Fitting To Valve) WPL 8272222 Contact Us For Availability

18

Seal, Oven Flange WPL 8524109 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

19

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $26.75

19

WP3196925 Whirlpool Clip Assembly Backorder WPL WP3196925 $5.16

19

Cover, Igniter WPL 8272403 Contact Us For Availability

WP8273065 Whirlpool Orifice Backorder WPL WP8273065 $32.90

WP8273066 Whirlpool Orifice Backorder WPL WP8273066 $32.98

WP8273067 Whirlpool Orifice In Stock WPL WP8273067 $32.98

Orifice, Burner (Left Front) WPL 8273063 Contact Us For Availability

Back, Main WPL 9757098 Contact Us For Availability

21

W10137062 Whirlpool Burner Baffle Backorder WPL W10137062 $154.20

21

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $21.59

22

Brace, Main Back WPL 8053971 Contact Us For Availability

23

3196265 Whirlpool Oven Screw Backorder WPL 3196265 $9.59

23

Retainer, Insul. (Right Hand) WPL 3195726 Contact Us For Availability

23

Retainer, Insul. (Left Hand) WPL 3196523 Contact Us For Availability

24

Clip, Panel (6) WPL 3196576 Contact Us For Availability

25

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.11

25

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $48.39

26

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

26

Spuds, LP Gas (Kit of 4) WPL 8523416 Contact Us For Availability

26

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI131552A Contact Us For Availability

27

WP3195993 Whirlpool Light Switch Backorder WPL WP3195993 $56.02

28

Suppressor, Trans WPL 9756133 Contact Us For Availability

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $86.66

31

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $28.80

32

WPW10107830 Whirlpool Stove Door Lock Latch A Backorder WPL WPW10107830 $121.04

33

WP3195546 Whirlpool Drawer Glide In Stock WPL WP3195546 $3.70

34

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $36.62

35

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

36

Button, Plug WPL 3196439 Contact Us For Availability

38

Screw WPL 3196152 Contact Us For Availability

39

3196166 Whirlpool Screw Backorder WPL 3196166 $4.85

40

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

41

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

42

Screw WPL 3196179 Contact Us For Availability

44

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $2.51

45

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

8053915 Whirlpool Oven Insulation Backorder WPL 8053915 $7.59

W10491985 Whirlpool Screw In Stock WPL W10491985 $2.51

W11684915 Whirlpool Insulation Backorder WPL W11684915 $45.31

W11688737 Whirlpool Insulation Backorder WPL W11688737 $45.31

Insulation WPL ARI131554A Contact Us For Availability
