Model Whirlpool TGP325LW1 30`` GAS FREESTANDING STANDARD CLEAN RANGE ELECTRO – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

814381 Whirlpool Pin Backorder WPL 814381 $3.70

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $28.80

1

WP98004218 Whirlpool Screw In Stock WPL WP98004218 $2.51

1

WP98004410 Whirlpool Top Burner In Stock WPL WP98004410 $37.31

1

WPW10116396 Whirlpool Flue Box Backorder WPL WPW10116396 $34.09

1

Literature Parts (Instructions, Installation WPL LIT4456640 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT98007031 Contact Us For Availability

1

Literature Parts (Installation Instr (Templat WPL LIT98007121 Contact Us For Availability

1

Literature Parts (Safer Cooking Tips) WPL LIT98007130 Contact Us For Availability

1

Literature Parts (Instructions Installation) WPL LIT98007137 Contact Us For Availability

1

Literature Parts (Guide, Use & Care) WPL LIT98012565 Contact Us For Availability

1

Rack, Oven (2) WPL 98013737 Contact Us For Availability

2

98013690 Whirlpool Clip Backorder WPL 98013690 $28.97

2

WP6610243 Whirlpool Venturi In Stock WPL WP6610243 $99.26

2

WP98003480 Whirlpool Grill Pan Backorder WPL WP98003480 $34.73

2

Cooktop (White/Des. White) WPL 98009677 Contact Us For Availability

3

98006392 Whirlpool Oven Light Switch Backorder WPL 98006392 $5.07

3

98010182 Whirlpool Door Liner Backorder WPL 98010182 $140.83

3

WP98016005 Whirlpool Broiler Pan Backorder WPL WP98016005 $46.57

3

Brkt., Venturi (4) WPL 98005500 Contact Us For Availability

3

Panel, Manifold (Black) WPL 98012602 Contact Us For Availability

3

Panel, Manifold (White) WPL 98012604 Contact Us For Availability

3

Shield, Insulation WPL 98011926 Contact Us For Availability

4

WP6610244 Whirlpool Venturi Assembly Backorder WPL WP6610244 $124.10

4

WP98006100 Whirlpool Knob In Stock WPL WP98006100 $13.62

4

WP98006102 Whirlpool Knob In Stock WPL WP98006102 $10.25

4

WP98010042 Whirlpool Side Panel Backorder WPL WP98010042 $76.40

4

Rack, Broiler WPL 98013721 Contact Us For Availability

5

98004952 Whirlpool Oven Clip Backorder WPL 98004952 $28.80

5

98004953 Whirlpool Clip Backorder WPL 98004953 $4.72

5

W11590249 Whirlpool Spark Module In Stock WPL W11590249 $7.74

5

Timer (White) WPL 8522811 Contact Us For Availability

5

Clip, Oven Bottom WPL 98005502 Contact Us For Availability

5

Bracket, Rack WPL 98005296 Contact Us For Availability

6

8190014 Whirlpool Grate Kit Primary In Stock WPL 8190014 $98.34

6

98004994 Whirlpool Oven Drawer Guide Backorder WPL 98004994 $46.65

6

WPW10206639 Whirlpool Drawer Guide Backorder WPL WPW10206639 $8.62

6

Hinge, Door (2) WPL 98004734 Contact Us For Availability

6

Counterweight WPL 98006710 Contact Us For Availability

6

Regulator WPL 98005520 Contact Us For Availability

7

98006739 Whirlpool Oven Wire Tie Backorder WPL 98006739 $26.21

7

98007192 Whirlpool Cover Model Backorder WPL 98007192 $26.21

7

W10206642 Whirlpool Drawer Guide Backorder WPL W10206642 $10.82

7

WPW10206641 Whirlpool Drawer Guide Backorder WPL WPW10206641 $8.62

7

Clip, Cooktop (2) WPL 98004722 Contact Us For Availability

8

3184020 Whirlpool Oven Wire Backorder WPL 3184020 $28.80

8

3196166 Whirlpool Screw Backorder WPL 3196166 $4.85

8

Frame, Front WPL 98005044 Contact Us For Availability

8

Spreader, Flame WPL 98011923 Contact Us For Availability

9

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $26.50

9

Bracket, Timer (Right) WPL 98008498 Contact Us For Availability

9

Bracket, Timer (Left) WPL 98008499 Contact Us For Availability

9

Liner, Door WPL 98004991 Contact Us For Availability

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP98005317 Whirlpool Door Handle In Stock WPL WP98005317 $85.63

WP98005318 Whirlpool Door Handle Backorder WPL WP98005318 $84.06

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

Burner, Oven WPL 98004314 Contact Us For Availability

Storage, Drawer WPL 98006209 Contact Us For Availability

WP98004449 Whirlpool Oven Bottom Backorder WPL WP98004449 $120.42

WP98004650 Whirlpool Nut In Stock WPL WP98004650 $3.70

WP98005518 Whirlpool Burner Cap Backorder WPL WP98005518 $33.86

Insulation, Door WPL 98012545 Contact Us For Availability

12

WP98007225 Whirlpool Screw Assembly Backorder WPL WP98007225 $2.51

12

Harness, Switch WPL 98005561 Contact Us For Availability

12

Panel, Door (White) WPL 98009337 Contact Us For Availability

98003847 Whirlpool Oven Bottom Baffle Backorder WPL 98003847 $78.46

98006794 Whirlpool Oven Door Trim Backorder WPL 98006794 $39.33

Bracket, Valve WPL 98011275 Contact Us For Availability

Handle, Brlr Door (White) WPL 98006623 Contact Us For Availability

14

98003830 Whirlpool Rail Base Backorder WPL 98003830 $37.08

14

Spacer, Handle WPL 98004773 Contact Us For Availability

98004564 Whirlpool Oven Retainer Backorder WPL 98004564 $67.77

98004629 Whirlpool Oven Retainer Backorder WPL 98004629 $67.77

98004723 Whirlpool Oven Bumper Backorder WPL 98004723 $6.33

Valve, Burner (4) (9,500 BTU) WPL 98005574 Contact Us For Availability

Support, Burner WPL 98004453 Contact Us For Availability

WP98010185 Whirlpool Door Trim In Stock WPL WP98010185 $35.69

WP98010187 Whirlpool Range Door Trim In Stock WPL WP98010187 $35.69

WPW10277003 Whirlpool Screw In Stock WPL WPW10277003 $2.51

Button, Plug (25/32``) WPL 98007388 Contact Us For Availability

Button, Plug (5/16``) WPL 98007389 Contact Us For Availability

Button, Plug (15/32``) WPL 98007390 Contact Us For Availability

Support, Rack WPL 98005295 Contact Us For Availability

17

Pipe, Manifold WPL 98010088 Contact Us For Availability

18

98004227 Whirlpool Oven Bumper Backorder WPL 98004227 $10.76

18

98009179 Whirlpool Oven Nut Backorder WPL 98009179 $9.59

18

Sleeve, 3/8`` WPL 98007127 Contact Us For Availability

19

98004938 Whirlpool Oven Retainer Backorder WPL 98004938 $49.59

19

Switch, Door WPL 98005765 Contact Us For Availability

WP3400805 Whirlpool Screw Assembly Backorder WPL WP3400805 $2.51

Insulation, Retainer-Bottom WPL 98012904 Contact Us For Availability

Back, Main WPL 98007461 Contact Us For Availability

Bracket, Connector WPL 98007183 Contact Us For Availability

W10918546 Whirlpool Oven Range Igniter In Stock WPL W10918546 $22.02

Top Trim, Door (White) WPL 98006885 Contact Us For Availability

Seal, Oven WPL 98009174 Contact Us For Availability

Screw WPL 98006644 Contact Us For Availability

22

W10837731 Whirlpool Screw Assembly In Stock WPL W10837731 $2.51

22

Washer, Valve (4) WPL 98007132 Contact Us For Availability

23

98007193 Whirlpool Oven Washer Backorder WPL 98007193 $7.54

23

Tubing (Regltr to Oven Valve) WPL 98011202 Contact Us For Availability

24

98007126 Whirlpool Oven Stand Bracket Backorder WPL 98007126 $27.21

26

98006715 Whirlpool Channel Assembly Backorder WPL 98006715 $42.36

27

98007191 Whirlpool Oven Heat Shield Backorder WPL 98007191 $62.61

28

WP98006631 Whirlpool Screw Backorder WPL WP98006631 $2.51

29

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $48.39

29

Fitting, Tube WPL 98005516 Contact Us For Availability

30

98005026 Whirlpool Oven Clip Backorder WPL 98005026 $7.54

30

Fitting, Female WPL 98005506 Contact Us For Availability

31

Retainer, Burner WPL 98014357 Contact Us For Availability

31

Tubing, Inlet WPL 98011226 Contact Us For Availability

32

Screw WPL 98014336 Contact Us For Availability

32

Nut, Loxit WPL 98005927 Contact Us For Availability

33

98004447 Whirlpool Top Backorder WPL 98004447 $61.32

34

98004451 Whirlpool Oven Side Panel Backorder WPL 98004451 $66.92

34

98004452 Whirlpool Oven Side Backorder WPL 98004452 $64.60

34

W11676351 Whirlpool Screw Backorder WPL W11676351 $8.11

35

98005768 Whirlpool Back Liner Backorder WPL 98005768 $153.76

35

W10837674 Whirlpool Screw In Stock WPL W10837674 $2.51

36

98015363 Whirlpool Oven Support Backorder WPL 98015363 $28.80

36

WPW10209656 Whirlpool Surface Ignitor In Stock WPL WPW10209656 $34.26

36

WPW10209657 Whirlpool Oven Surface Igniter In Stock WPL WPW10209657 $21.94

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

WPW10278150 Whirlpool Clip Assembly In Stock WPL WPW10278150 $18.14

LP Spud Kit (For Use With LP) WPL 98005978 Contact Us For Availability

Natural Spud Kit (For use with Natural Gas) WPL 98005982 Contact Us For Availability

Washer, Cut-Off WPL 98011072 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI131507A Contact Us For Availability

38

W10856866 Whirlpool Light Socket In Stock WPL W10856866 $3.70

39

Screw WPL 98006634 Contact Us For Availability

40

98007205 Whirlpool Oven Vent Cap Backorder WPL 98007205 $39.02

98004294 Whirlpool Insulation Wire Backorder WPL 98004294 $7.54

W11311894 Whirlpool Insulation Backorder WPL W11311894 $37.17

Sensor, Oven WPL 98005641 Contact Us For Availability

Insulation WPL ARI131508A Contact Us For Availability
