Model Electrolux TGO356BFD4 RANGE – Common Parts &amp; Diagrams

*13006

WASHER-HINGE,BLACK WCI 3131737 Contact Us For Availability

*13007

WCI 08013188 WCI 08013188 Contact Us For Availability

*13008

WCI 08067961 WCI 08067961 Contact Us For Availability

*13009

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

*13010

SHIELD-INSULATION WCI 08067992 Contact Us For Availability

*13011

WCI 5304400432 WCI 5304400432 Contact Us For Availability

*13012

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $8.44

*13013

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.11

1

WCI 316029412 WCI 316029412 Contact Us For Availability

1

DRAWER-UTILITY WCI 316011501 Contact Us For Availability

1

WCI 08011721 WCI 08011721 Contact Us For Availability

2

GLASS-OVEN DOOR, REAR WCI 08011722 Contact Us For Availability

2

WCI 3131314 WCI 3131314 Contact Us For Availability

2

HINGE-OVEN DOOR WCI 5303051166 Contact Us For Availability

2

WCI 3131975 WCI 3131975 Contact Us For Availability

3

LAMP-FLUORESCENT, BACKGUARD WCI 3131275 Contact Us For Availability

3

PANEL CONTROL,ALMOND ,RH WCI 316081036 Contact Us For Availability

3

Trim,oven door ,black WCI 316067802 Contact Us For Availability

3

WCI 316090100 WCI 316090100 Contact Us For Availability

4

WCI 3011597 WCI 3011597 Contact Us For Availability

4

PLATE-BOTTOM HINGE WCI 08011665 Contact Us For Availability

4

WCI 316084406 WCI 316084406 Contact Us For Availability

4

GLASS-OVEN DOOR,BLACK ,OUTER WCI 316089000 Contact Us For Availability

4

WCI 318090230 WCI 318090230 Contact Us For Availability

5

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

5

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $5.78

5

Glass,oven door ,airwash WCI 316088700 Contact Us For Availability

5

SCREW-LEVELLING WCI 316107300 Contact Us For Availability

6

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $63.90

6

GLASS-OVEN LIGHT LENS WCI 08011668 Contact Us For Availability

6

WCI 316088401 WCI 316088401 Contact Us For Availability

6

WCI 5303290112 WCI 5303290112 Contact Us For Availability

7

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $2.33

7

WCI 316007002 No Longer Available

7

GASKET-OVEN LIGHT WCI 3200506 Contact Us For Availability

7

WCI 316076403 WCI 316076403 Contact Us For Availability

7

GUSSET-OVEN DOOR WCI 08011727 Contact Us For Availability

8

5303912606 Frigidaire Oven Range Spark Module Backorder WCI 5303912606 $81.46

8

WCI 316088600 WCI 316088600 Contact Us For Availability

8

WCI 5303300406 WCI 5303300406 Contact Us For Availability

8

COVER-LIGHT, UPPER WCI 08011669 Contact Us For Availability

8

CHANNEL, FRAME WCI 316013100 Contact Us For Availability

9

WCI 08011729 WCI 08011729 Contact Us For Availability

9

WCI 318138800 WCI 318138800 Contact Us For Availability

9

SEAL-OVEN DOOR WCI 316024201 Contact Us For Availability

9

WCI 316066610 WCI 316066610 Contact Us For Availability

WCI 316057100 WCI 316057100 Contact Us For Availability

SCREW-HANDLE MTG, WAFER HEAD, 10-24(T) X 2 WCI 5303280308 Contact Us For Availability

WCI 318126400 WCI 318126400 Contact Us For Availability

WCI 5303284147 WCI 5303284147 Contact Us For Availability

WCI 316081701 WCI 316081701 Contact Us For Availability

WCI 316099800 WCI 316099800 Contact Us For Availability

WCI 318073101 WCI 318073101 Contact Us For Availability

SPACER-DOOR WCI 3051302 Contact Us For Availability

3016993 Frigidaire Oven Retainer Backorder WCI 3016993 $51.16

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $199.68

THERMOSTAT-OVEN, LOWER WCI 5303270076 Contact Us For Availability

WCI 316027702 WCI 316027702 Contact Us For Availability

WCI 318109801 WCI 318109801 Contact Us For Availability

13

WCI 316065005 WCI 316065005 Contact Us For Availability

13

WCI 316026800 WCI 316026800 Contact Us For Availability

13

WCI 5303290121 WCI 5303290121 Contact Us For Availability

5303208655 Frigidaire Reflector Assembly Backorder WCI 5303208655 $36.13

5304521339 Frigidaire Regulator In Stock WCI 5304521339 $61.25

RACK-OVEN, FLAT WCI 08011675 Contact Us For Availability

REFLECTOR, ALUMINUM FOIL WCI 5303208656 Contact Us For Availability

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $42.77

15

318090310 Frigidaire Oven Latch Backorder WCI 318090310 $28.94

15

WCI 316081403 WCI 316081403 Contact Us For Availability

5304524341 Frigidaire Lens In Stock WCI 5304524341 $8.02

WCI 316085701 WCI 316085701 Contact Us For Availability

WCI 318025902 WCI 318025902 Contact Us For Availability

PANEL-BODYSIDE,ALMOND ,LH WCI 318025912 Contact Us For Availability

MAIN TOP, ALMOND WCI 3131455 Contact Us For Availability

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $35.65

5303208499 Frigidaire Gas Safety Valve Backorder WCI 5303208499 $353.12

WCI 316066900 WCI 316066900 Contact Us For Availability

VALVE-SAFETY WCI 3131623 Contact Us For Availability

SHIELD-WOOL WCI 5303208706 Contact Us For Availability

WCI 5303015453 WCI 5303015453 Contact Us For Availability

STARTER-LAMP WCI 3206218 Contact Us For Availability

BRACKET-HINGE,MAIN TOP LH WCI 08067746 Contact Us For Availability

BRACKET-HINGE,MAIN TOP RH WCI 08067747 Contact Us For Availability

18A

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $36.58

5303935066 Frigidaire Oven Flat Igniter 17-In In Stock WCI 5303935066 $23.27

IGNITOR-OVEN, UPPER WCI 5303200508 Contact Us For Availability

WCI 5303131357 WCI 5303131357 Contact Us For Availability

20

WCI 3203218 WCI 3203218 Contact Us For Availability

20

WCI 5303290105 WCI 5303290105 Contact Us For Availability

20

GRATE,BLACK ,(4) WCI 316085201 Contact Us For Availability

21

SPACER-BODYSIDE, (8) WCI 3014099 Contact Us For Availability

21

WCI 3200505 WCI 3200505 Contact Us For Availability

WCI 316065002 WCI 316065002 Contact Us For Availability

SWITCH-LATCH WCI 5303269499 Contact Us For Availability

STUD SPACER WCI 08067978 Contact Us For Availability

WCI 5303290177 WCI 5303290177 Contact Us For Availability

23

WCI 08067776 WCI 08067776 Contact Us For Availability

23

WCI 318036701 WCI 318036701 Contact Us For Availability

24

5308015487 Frigidaire Oven Light Switch Backorder WCI 5308015487 $36.11

24

SHIELD-LATCH, TOP WCI 3131593 Contact Us For Availability

24

WCI 5303290130 WCI 5303290130 Contact Us For Availability

25

SHIELD-BAKE LOWER,LOWER WCI 5303288580 Contact Us For Availability

25

WCI 5303290095 WCI 5303290095 Contact Us For Availability

26

WCI 08067757 WCI 08067757 Contact Us For Availability

27

CLIP-THERMO BULB WCI 08067754 Contact Us For Availability

28

Clip,wire ,bodyside WCI 3011813 Contact Us For Availability

28

STRIKE-DOOR WCI 316012800 Contact Us For Availability

29

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $1.73

29

WCI 316029008 WCI 316029008 Contact Us For Availability

31

WCI 316019167 WCI 316019167 Contact Us For Availability

31

SHIELD-HEAT WCI 3131620 Contact Us For Availability

32

KNOB-THERMOSTAT LOWER,LOWER OVEN WCI 316019164 Contact Us For Availability

32

BRACKET-CONNECTOR WCI 3200500 Contact Us For Availability

33

WCI 316014400 WCI 316014400 Contact Us For Availability

33

RETAINER, UPPER OVN BRNR WCI 3200519 Contact Us For Availability

34

WCI 5304403075 WCI 5304403075 Contact Us For Availability

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.11

35

WCI 5303290119 WCI 5303290119 Contact Us For Availability

36

WCI 316023020 WCI 316023020 Contact Us For Availability

36

WCI 3131931 WCI 3131931 Contact Us For Availability

38

WCI 316014300 WCI 316014300 Contact Us For Availability

39

5304529996 Frigidaire Handle Kit Backorder WCI 5304529996 $85.73

39

5304534000 Frigidaire Cord Backorder WCI 5304534000 $19.59

40

WCI 3200836 WCI 3200836 Contact Us For Availability

41

WCI 3131570 WCI 3131570 Contact Us For Availability

42

WCI 5303288578 WCI 5303288578 Contact Us For Availability

44

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $32.52

45

SHIELD-WIRE WCI 08068018 Contact Us For Availability

46

WCI 5303208642 WCI 5303208642 Contact Us For Availability

46

TUBE-POST RH WCI 5303208643 Contact Us For Availability

52

WCI 316081303 WCI 316081303 Contact Us For Availability

53

WCI 5303288579 WCI 5303288579 Contact Us For Availability

55

316008401 Frigidaire Washer P-1 In Stock WCI 316008401 $7.11

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $32.52

WCI 316047708 WCI 316047708 Contact Us For Availability

INSULATION, OVEN TOP WCI 3131304 Contact Us For Availability

Insulation, 2`` ,oven back WCI 316054200 Contact Us For Availability

WCI 318132601 WCI 318132601 Contact Us For Availability

WCI 318132602 WCI 318132602 Contact Us For Availability

WCI 318132606 WCI 318132606 Contact Us For Availability

WCI 318132607 WCI 318132607 Contact Us For Availability

REFLECTOR, ALUMINUM FOIL WCI 3204440 Contact Us For Availability

59

BUTTON WCI 316013300 Contact Us For Availability

60

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

72

COVER-LIGHT/SWITCH ROD WCI 5303285692 Contact Us For Availability

83

WCI 316054311 WCI 316054311 Contact Us For Availability

83

WCI 318109600 WCI 318109600 Contact Us For Availability

170

316112005 Frigidaire Oven Anti-Tip Range Brac In Stock WCI 316112005 $8.29

217

WCI 316065306 WCI 316065306 Contact Us For Availability

235

SHIELD-LATCH WCI 3051413 Contact Us For Availability

255

316064600 Frigidaire Oven Support Backorder WCI 316064600 $11.13
