Model GE TBX20KFBR Refrigerator – Common Parts & Diagrams
0
1
2
Common parts from model GE TBX20KFBR Refrigerator
5
GEN WR12X0463 GEN WR12X0463 Contact Us For Availability
6
GEN WR12X0468 GEN WR12X0468 Contact Us For Availability
7
GEN WR12X0469 GEN WR12X0469 Contact Us For Availability
8
GEN WR02X4924 GEN WR02X4924 Contact Us For Availability
9
GEN WR12X0509 GEN WR12X0509 Contact Us For Availability
10
GEN WR02X7140 GEN WR02X7140 Contact Us For Availability
11
SCREW 8-18 B 7/16 GEN WZ04X0352 Contact Us For Availability
13
GEN WR02X4945 GEN WR02X4945 Contact Us For Availability
14
GEN WR02X4946 GEN WR02X4946 Contact Us For Availability
15
GEN WR01X1564 GEN WR01X1564 Contact Us For Availability
16
GEN WR01X1565 GEN WR01X1565 Contact Us For Availability
18
GEN WR01X1566 GEN WR01X1566 Contact Us For Availability
19
GEN WR71X1685 GEN WR71X1685 Contact Us For Availability
20
GEN WR71X1684 GEN WR71X1684 Contact Us For Availability
21
GEN WR02X7232 GEN WR02X7232 Contact Us For Availability
23
GEN WR24X0308 GEN WR24X0308 Contact Us For Availability
24
GEN WR17X1589 GEN WR17X1589 Contact Us For Availability
25
GEN WR17X1209 GEN WR17X1209 Contact Us For Availability
26
GEN WR02X7230 GEN WR02X7230 Contact Us For Availability
27
GEN WR02X7229 GEN WR02X7229 Contact Us For Availability
28
GEN WR02X6278 GEN WR02X6278 Contact Us For Availability
30
GEN WR01X5475 GEN WR01X5475 Contact Us For Availability
101
GEN WR03X0408 GEN WR03X0408 Contact Us For Availability
103
GEN WR77X0446 GEN WR77X0446 Contact Us For Availability
104
GEN WR24X0309 GEN WR24X0309 Contact Us For Availability
105
GEN WR02X7233 GEN WR02X7233 Contact Us For Availability
106
GEN WR22X0303 GEN WR22X0303 Contact Us For Availability
107
GEN WR22X0308 GEN WR22X0308 Contact Us For Availability
108
GEN WR71X1686 GEN WR71X1686 Contact Us For Availability
109
GEN WR71X1687 GEN WR71X1687 Contact Us For Availability
110
GEN WR02X7231 GEN WR02X7231 Contact Us For Availability
111
GEN WR02X4929 GEN WR02X4929 Contact Us For Availability
112
GEN WR04X0173 GEN WR04X0173 Contact Us For Availability
114
GEN WR19X0030 GEN WR19X0030 Contact Us For Availability
114
GEN WR19X0031 GEN WR19X0031 Contact Us For Availability
115
GEN WR17X1530 GEN WR17X1530 Contact Us For Availability
116
GEN WR01X1570 GEN WR01X1570 Contact Us For Availability
117
GEN WR38X1033 GEN WR38X1033 Contact Us For Availability
119
GEN WR02X4928 GEN WR02X4928 Contact Us For Availability
120
GEN WR01X1592 GEN WR01X1592 Contact Us For Availability
122
GEN WR12X0471 GEN WR12X0471 Contact Us For Availability
128
GEN WR02X7234 GEN WR02X7234 Contact Us For Availability
150
SCREW SW. CRADLE GEN WR01X1464 Contact Us For Availability
176
GEN WZ05X0166 GEN WZ05X0166 Contact Us For Availability
200
GEN WR17X1599 GEN WR17X1599 Contact Us For Availability
201
GEN WR17X1597 GEN WR17X1597 Contact Us For Availability
202
GEN WR02X7019 GEN WR02X7019 Contact Us For Availability
203
GEN WR14X0316 GEN WR14X0316 Contact Us For Availability
203
GEN WR17X2017 GEN WR17X2017 Contact Us For Availability
204
GEN WR01X1655 GEN WR01X1655 Contact Us For Availability
204
SUPT-MULLION & NUTSTRIP GEN WR02X7014 Contact Us For Availability
205
PLUG BUTTON GEN WR02X7060 Contact Us For Availability
206
GEN WR71X1524 GEN WR71X1524 Contact Us For Availability
207
PLENUM GEN WR17X1540 Contact Us For Availability
209
GEN WR02X7015 GEN WR02X7015 Contact Us For Availability
210
GEN WR02X7016 GEN WR02X7016 Contact Us For Availability
211
GEN WR02X6261 GEN WR02X6261 Contact Us For Availability
212
GEN WR71X1508 GEN WR71X1508 Contact Us For Availability
218
GEN WR14X0329 GEN WR14X0329 Contact Us For Availability
219
GEN WR51X0303 GEN WR51X0303 Contact Us For Availability
228
GEN WR71X5975 GEN WR71X5975 Contact Us For Availability
229
GEN WR71X1662 GEN WR71X1662 Contact Us For Availability
231
GEN WR38X1017 GEN WR38X1017 Contact Us For Availability
232
GEN WR72X0076 GEN WR72X0076 Contact Us For Availability
233
GEN WR02X7018 GEN WR02X7018 Contact Us For Availability
233
GEN WR72X0077 GEN WR72X0077 Contact Us For Availability
235
GEN WR38X0973 GEN WR38X0973 Contact Us For Availability
236
GEN WR32X0857 GEN WR32X0857 Contact Us For Availability
237
GEN WR17X1608 GEN WR17X1608 Contact Us For Availability
240
GEN WR32X0854 GEN WR32X0854 Contact Us For Availability
241
GEN WR17X1564 GEN WR17X1564 Contact Us For Availability
243
GEN WR32X0858 GEN WR32X0858 Contact Us For Availability
244
GEN WR17X1622 GEN WR17X1622 Contact Us For Availability
245
COVER VEG. PAN GEN WR32X5220 Contact Us For Availability
249
SUPPORT PAN COVER GEN WR02X7017 Contact Us For Availability
252
GEN WR32X0746 GEN WR32X0746 Contact Us For Availability
253
GEN WR17X1554 GEN WR17X1554 Contact Us For Availability
255
GEN WR38X1028 GEN WR38X1028 Contact Us For Availability
256
GEN WR23X0203 GEN WR23X0203 Contact Us For Availability
257
SCR 6-32 D TR 3/8 SS GEN WZ05X0160 Contact Us For Availability
258
CHANNEL SUPPT COVER GEN WR17X1602 Contact Us For Availability
261
GEN WR02X4989 GEN WR02X4989 Contact Us For Availability
265
GEN WR02X3595 GEN WR02X3595 Contact Us For Availability
265
GEN WR02X3598 GEN WR02X3598 Contact Us For Availability
267
GEN WR82X0217 GEN WR82X0217 Contact Us For Availability
268
PAN WATER DISPOSAL ASM GEN WR32X0717 Contact Us For Availability
275
HINGE TOP & PIN ASM GEN WR13X0521 Contact Us For Availability
276
GEN WR13X0561 GEN WR13X0561 Contact Us For Availability
277
GEN WR17X1492 GEN WR17X1492 Contact Us For Availability
278
WHEEL ASM FRT GEN WR02X4858 Contact Us For Availability
279
GEN WR13X0562 GEN WR13X0562 Contact Us For Availability
281
GEN WR01X1114 GEN WR01X1114 Contact Us For Availability
281
GEN WR01X1355 GEN WR01X1355 Contact Us For Availability
282
GEN WR13X0553 GEN WR13X0553 Contact Us For Availability
283
SHIM HINGE-.031 THK. GEN WR02X7030 Contact Us For Availability
283
NUTSTRIP-BTM. HINGE GEN WR02X7143 Contact Us For Availability
285
BAFFLE AIR EXTN BTM GEN WR02X7003 Contact Us For Availability
286
BAFFLE AIR COND FAN GEN WR17X1531 Contact Us For Availability
288
GEN WR02X7079 GEN WR02X7079 Contact Us For Availability
288
GEN WR74X0179 GEN WR74X0179 Contact Us For Availability
289
GEN WR02X7154 GEN WR02X7154 Contact Us For Availability
290
GEN WR02X7155 GEN WR02X7155 Contact Us For Availability
291
GEN WR74X0177 GEN WR74X0177 Contact Us For Availability
292
GEN WR01X1326 GEN WR01X1326 Contact Us For Availability
293
GEN WR02X7080 GEN WR02X7080 Contact Us For Availability
295
GEN WR23X0162 GEN WR23X0162 Contact Us For Availability
296
COVER IM RECEPTACLE GEN WR02X4512 Contact Us For Availability
300
GEN WR02X7061 GEN WR02X7061 Contact Us For Availability
300
CONTROL TEMP GEN WR09X0352 Contact Us For Availability
301
SLEEVE VINYL GEN WR02X7010 Contact Us For Availability
301
GEN WR02X7146 GEN WR02X7146 Contact Us For Availability
302
GEN WR14X0312 GEN WR14X0312 Contact Us For Availability
302
HOUSING NOZZLE GEN WR17X1533 Contact Us For Availability
303
GEN WR02X7008 GEN WR02X7008 Contact Us For Availability
304
GEN WR02X7139 GEN WR02X7139 Contact Us For Availability
305
GEN WR02X7009 GEN WR02X7009 Contact Us For Availability
306
GEN WR17X1605 GEN WR17X1605 Contact Us For Availability
306
INSUL CONTROL HSG GEN WR82X0212 Contact Us For Availability
307
GEN WR17X1598 GEN WR17X1598 Contact Us For Availability
308
GEN WR02X7147 GEN WR02X7147 Contact Us For Availability
312
FUNNEL DRAIN GEN WR02X7006 Contact Us For Availability
313
TUBE DRAIN GEN WR17X1532 Contact Us For Availability
314
GEN WR02X4516 GEN WR02X4516 Contact Us For Availability
315
GROMMET DRAIN GEN WR02X7007 Contact Us For Availability
317
GEN WR02X7075 GEN WR02X7075 Contact Us For Availability
317
GEN WR02X7076 GEN WR02X7076 Contact Us For Availability
318
GEN WR17X1600 GEN WR17X1600 Contact Us For Availability
318
GEN WR17X1601 GEN WR17X1601 Contact Us For Availability
321
GEN WR02X4532 GEN WR02X4532 Contact Us For Availability
322
GEN WR02X6345 GEN WR02X6345 Contact Us For Availability
323
GEN WR17X1594 GEN WR17X1594 Contact Us For Availability
324
GEN WR02X7069 GEN WR02X7069 Contact Us For Availability
420
GEN WR30X0167 GEN WR30X0167 Contact Us For Availability
422
GEN WR01X1332 GEN WR01X1332 Contact Us For Availability
435
SOCKET LAMP GEN WR02X4049 Contact Us For Availability
445
R-E-D SERVICE PKG. GEN WR49X0233 Contact Us For Availability
450
GEN WR02X4194 GEN WR02X4194 Contact Us For Availability
452
SHIM HINGE BTM. GEN WR02X4497 Contact Us For Availability
452
GEN WR02X7011 GEN WR02X7011 Contact Us For Availability
551
GEN WZ04X0244 GEN WZ04X0244 Contact Us For Availability
553
SCR 6-20 B TR 1/4 SS GEN WZ04X0343 Contact Us For Availability
560
SCR 12-24 A HXW 7/8 SPP GEN WR01X1249 Contact Us For Availability
561
SCR 12-24 TT HXW 1 3/64 SPP GEN WR01X1645 Contact Us For Availability
564
SCR 1/4-14 BA HX 3/4 SN GEN WR01X1194 Contact Us For Availability
566
SCR 10-16 BAT HXW 1/2 SNS GEN WR01X1487 Contact Us For Availability
568
GEN WZ05X0137 GEN WZ05X0137 Contact Us For Availability
570
GEN WZ04 GEN WZ04 Contact Us For Availability
573
GEN WZ04X0254 GEN WZ04X0254 Contact Us For Availability
601
GEN WR17X1552 GEN WR17X1552 Contact Us For Availability
602
PLUG EVAP ACCESS GEN WR82X0214 Contact Us For Availability
603
LINER BTM FZ GEN WR17X1596 Contact Us For Availability
604
GEN WR02X7072 GEN WR02X7072 Contact Us For Availability
604
GEN WR17X2015 GEN WR17X2015 Contact Us For Availability
608
FOAM STRIP SE ADH GEN WR14X0313 Contact Us For Availability
608
GEN WR17X2016 GEN WR17X2016 Contact Us For Availability
616
SHIELD DEF HTR GEN WR17X1536 Contact Us For Availability
617
COVER DEF HTR GEN WR02X7013 Contact Us For Availability
618
GEN WR51X0249 GEN WR51X0249 Contact Us For Availability
621
GEN WR02X4495 GEN WR02X4495 Contact Us For Availability
621
BRACKET DEF HTR GEN WR02X7012 Contact Us For Availability
622
TROUGH DRAIN ASM GEN WR17X1547 Contact Us For Availability
623
GEN WR14X0289 GEN WR14X0289 Contact Us For Availability
623
COVER DUCT FF GEN WR17X1549 Contact Us For Availability
624
GEN WR17X1593 GEN WR17X1593 Contact Us For Availability
628
GEN WR02X7026 GEN WR02X7026 Contact Us For Availability
640
BRACKET COMP MTG-R.SIDE GEN WR02X7004 Contact Us For Availability
641
BRACKET COMP MTG-L.SIDE GEN WR02X7005 Contact Us For Availability
642
BUSHING COMP MTG GEN WR02X7028 Contact Us For Availability
644
GEN WR02X2375 GEN WR02X2375 Contact Us For Availability
644
TONGUE ASM GEN WR17X1284 Contact Us For Availability
649
GEN WR02X7027 GEN WR02X7027 Contact Us For Availability
651
GEN WR60X0117 GEN WR60X0117 Contact Us For Availability
652
GEN WR01X1683 GEN WR01X1683 Contact Us For Availability
653
GEN WR01X1515 GEN WR01X1515 Contact Us For Availability
654
BRACKET COND FAN GEN WR02X4801 Contact Us For Availability
655
GEN WR01X1601 GEN WR01X1601 Contact Us For Availability
682
GEN WX06X0134 GEN WX06X0134 Contact Us For Availability
683
SCR 8-32 SPECIAL GEN WZ05X0164 Contact Us For Availability
684
SCREW GEN WZ04X0417 Contact Us For Availability
685
SCR 1/4-14 AB HX 1/2S NS GEN WR01X1596 Contact Us For Availability
687
GEN WZ04X0224 GEN WZ04X0224 Contact Us For Availability
692
SCR 8-18 AB HXW 3/4 S GEN WZ04X0416 Contact Us For Availability
692
SCR 8-18 AB HX 1/2 S PL GEN WZ06X0129 Contact Us For Availability
694
GEN WZ05X0247 GEN WZ05X0247 Contact Us For Availability
725
MACHINE HIGH SIDE GEN WR87X0067 Contact Us For Availability
725
REFRIGERANT GEN WR97X0177 Contact Us For Availability
726
MACHINE LOW SIDE GEN WR85X0089 Contact Us For Availability
730
COND ASM GEN WR84X0043 Contact Us For Availability
731
CLIP COND GEN WR02X4621 Contact Us For Availability
733
RELAY COMP GEN WR07X0099 Contact Us For Availability
734
GEN WR02X3583 GEN WR02X3583 Contact Us For Availability
734
COVER RELAY GEN WR02X3867 Contact Us For Availability
735
GEN WR08X0030 GEN WR08X0030 Contact Us For Availability
736
COVER COMP MTG BRKT GEN WR02X7029 Contact Us For Availability
740
GEN WR96X0002 GEN WR96X0002 Contact Us For Availability
743
EXT COMP MTG GEN WR02X6157 Contact Us For Availability
745
NUTSTRIP COMP MTG D/J GEN WR02X3904 Contact Us For Availability
900
GEN WR78X7433 GEN WR78X7433 Contact Us For Availability
902
GEN WR78X7435 GEN WR78X7435 Contact Us For Availability
903
GEN WR78X7504 GEN WR78X7504 Contact Us For Availability
910
GEN WR78X7436 GEN WR78X7436 Contact Us For Availability
912
GEN WR78X7438 GEN WR78X7438 Contact Us For Availability
913
GEN WR78X7506 GEN WR78X7506 Contact Us For Availability
920
GEN WR02X4930 GEN WR02X4930 Contact Us For Availability
924
GEN WR02X4934 GEN WR02X4934 Contact Us For Availability
925
GEN WR02X7241 GEN WR02X7241 Contact Us For Availability
9999
GEN 31-5007 GEN 31-5007 Contact Us For Availability
9999
GEN 49-6360 GEN 49-6360 Contact Us For Availability
× ![]()
