Model Whirlpool SF380LEPT3 30`` GAS FREESTANDING SELF CLEAN RANGE SEALED BURN – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $27.58

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $31.46

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.41

8523599 Whirlpool Range Wire Harness Backorder WPL 8523599 $80.82

W11244557 Whirlpool Screw Backorder WPL W11244557 $9.59

W11447673 Whirlpool Range Tip Anchor In Stock WPL W11447673 $12.59

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.13

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

WPL 8524207 WPL 8524207 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

1

W11457094 Whirlpool Range Flue Backorder WPL W11457094 $87.10

1

WPW10016370 Whirlpool Door Trim Backorder WPL WPW10016370 $84.11

1

Trim, Top (Black) WPL W10016380 Contact Us For Availability

1

Trim, Top (Biscuit) WPL W10016450 Contact Us For Availability

1

Screw, Valve WPL 8273096 Contact Us For Availability

2

WP3191898 Whirlpool Surface Burner Cap Black Backorder WPL WP3191898 $44.27

2

WP3191901 Whirlpool Burner Cap Backorder WPL WP3191901 $56.96

2

WP3191903 Whirlpool Burner Cap In Stock WPL WP3191903 $101.63

2

WP3191904 Whirlpool Burner Cap Backorder WPL WP3191904 $100.55

2

WP3191905 Whirlpool Burner Cap Backorder WPL WP3191905 $46.21

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $2.64

2

WP8272747 Whirlpool Heat Shield Backorder WPL WP8272747 $27.52

2

WP8273700 Whirlpool Base Burner In Stock WPL WP8273700 $58.44

2

Cap, Burner (RR) (Grey) WPL 3191899 Contact Us For Availability

3

W11379351 Whirlpool Burner Box Backorder WPL W11379351 $36.75

3

Tubing, Burner W/Orifice (Left Front) WPL 8273693 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Rear) WPL 8273697 Contact Us For Availability

4

W10162246 Whirlpool Side Panel Backorder WPL W10162246 $85.61

4

W11730303 Whirlpool Side Panel In Stock WPL W11730303 $58.52

4

WP4455980 Whirlpool Burner Head In Stock WPL WP4455980 $39.31

4

WP4455981 Whirlpool Burner Head Backorder WPL WP4455981 $54.75

4

WP9761344 Whirlpool Door Liner In Stock WPL WP9761344 $118.41

4

WPW10575396 Whirlpool Side Panel Backorder WPL WPW10575396 $79.59

4

Burner (RR (5K)) WPL 4455979 Contact Us For Availability

4

Screw WPL 4449746 Contact Us For Availability

5

WPW10295998 Whirlpool Wire Harness Backorder WPL WPW10295998 $85.63

5

Shield, Heat (2) WPL 9761490 Contact Us For Availability

6

8053505 Whirlpool Range Shield Backorder WPL 8053505 $57.07

6

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $25.99

6

8523855 Whirlpool Range Manifold Panel Backorder WPL 8523855 $65.09

6

WP3196813 Whirlpool Rivet Backorder WPL WP3196813 $4.43

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.43

6

WP8523793 Whirlpool Oven Surface Igniter In Stock WPL WP8523793 $17.68

6

WP8523854 Whirlpool Manifold Panel Backorder WPL WP8523854 $119.62

7

3149360 Whirlpool Light Switch Backorder WPL 3149360 $37.94

7

WP4314961 Whirlpool Lite Switch Backorder WPL WP4314961 $31.90

7

WP8273103 Whirlpool Black Control Knob In Stock WPL WP8273103 $9.46

7

WP8273104 Whirlpool Knob In Stock WPL WP8273104 $9.17

7

WP8273106 Whirlpool Knob Backorder WPL WP8273106 $10.89

7

Switch, Rocker (Biscuit) WPL 8273501 Contact Us For Availability

7

Shield, Heat (2) WPL 3195813 Contact Us For Availability

8

WP9757218 Whirlpool Burner Valve In Stock WPL WP9757218 $128.80

8

Knob, Accusimmer (White) WPL 8273108 Contact Us For Availability

8

Valve (Right Rear) WPL 8273004 Contact Us For Availability

8

Cover, Upper WPL 9756301 Contact Us For Availability

8

Frame, Front Not Serviced WPL ARI164035A Contact Us For Availability

9

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $27.82

9

Nut (4) WPL 8273060 Contact Us For Availability

9

Shield, Heat WPL 8053910 Contact Us For Availability

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $2.51

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

Stainless Model WPL 8272822 Contact Us For Availability

Cover, Lower WPL 8273132 Contact Us For Availability

8523412 Whirlpool Mounting Bracket Backorder WPL 8523412 $98.66

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $85.47

WPW10447925 Whirlpool Grate Kit In Stock WPL WPW10447925 $198.76

Grate, Burner (4) (Espresso) WPL 8522853 Contact Us For Availability

WP6610449 Whirlpool Electronic Control Board Backorder WPL WP6610449 $197.65

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $98.14

WP8523166 Whirlpool Door Trim In Stock WPL WP8523166 $38.19

WP8523167 Whirlpool Door Trim Assembly Backorder WPL WP8523167 $37.19

WP8523172 Whirlpool Left Door Trim In Stock WPL WP8523172 $38.10

WP8523173 Whirlpool Door Trim Backorder WPL WP8523173 $37.24

WPW10181986 Whirlpool Range Sensor In Stock WPL WPW10181986 $66.20

Control, Range (White) WPL 6610450 Contact Us For Availability

Control, Range (Biscuit) WPL 6610451 Contact Us For Availability

13

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $112.34

13

WPW10118454 Whirlpool Range Outer Door Glass In Stock WPL WPW10118454 $198.05

13

Spreader, Flame (Oven) WPL 8053970 Contact Us For Availability

8053969 Whirlpool Heat Shield Backorder WPL 8053969 $38.41

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

WP9758078 Whirlpool Range Burner In Stock WPL WP9758078 $99.73

WP9781235 Whirlpool Clip Backorder WPL WP9781235 $5.22

15

8053968 Whirlpool Range Heat Shield Backorder WPL 8053968 $30.89

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $57.62

WP9758079 Whirlpool Range Igniter In Stock WPL WP9758079 $26.99

WPW10031790 Whirlpool Screw In Stock WPL WPW10031790 $2.51

WPW10306546 Whirlpool Base Rail In Stock WPL WPW10306546 $53.16

17

W10647259 Whirlpool Hinge Receiver In Stock WPL W10647259 $2.51

17

Tubing (Broiler Fitting To Valve) WPL 8272222 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

18

Seal, Oven Flange WPL W10008830 Contact Us For Availability

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $28.09

WP8273564 Whirlpool Clip Backorder WPL WP8273564 $5.22

WP8523175 Whirlpool Door Trim Assembly In Stock WPL WP8523175 $49.54

WP8523177 Whirlpool Door Trim Assembly In Stock WPL WP8523177 $54.86

WP8523178 Whirlpool Door Trim Backorder WPL WP8523178 $54.73

WP8523180 Whirlpool Door Trim Assembly Backorder WPL WP8523180 $55.15

WP8273064 Whirlpool Orifice Backorder WPL WP8273064 $34.55

WP8273065 Whirlpool Orifice Backorder WPL WP8273065 $34.55

WP8273067 Whirlpool Orifice Backorder WPL WP8273067 $34.62

Back, Main WPL 9757098 Contact Us For Availability

21

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $21.59

22

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

22

Brace, Main Back WPL 8053971 Contact Us For Availability

23

3196265 Whirlpool Range Screw Backorder WPL 3196265 $9.59

23

9761448 Whirlpool Range Retainer Backorder WPL 9761448 $130.62

23

9761449 Whirlpool Range Retainer Backorder WPL 9761449 $130.62

24

Clip, Panel (6) WPL 3196576 Contact Us For Availability

25

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.11

25

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $50.80

26

9757239 Whirlpool Oven Door Rod Backorder WPL 9757239 $33.16

26

W10854965 Whirlpool Orifice Spud Backorder WPL W10854965 $33.42

26

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

27

W11243424 Whirlpool Light Switch Backorder WPL W11243424 $53.23

28

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $36.67

29

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $90.99

31

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $30.25

32

WPW10107830 Whirlpool Stove Door Lock Latch A Backorder WPL WPW10107830 $121.04

33

Glide, Drawer WPL 8522669 Contact Us For Availability

34

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

36

Button, Plug WPL 3196439 Contact Us For Availability

38

Screw WPL 3196152 Contact Us For Availability

39

3196166 Whirlpool Screw Backorder WPL 3196166 $4.85

39

Screw (Biscuit) WPL 8281194 Contact Us For Availability

40

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

42

Screw WPL 3196179 Contact Us For Availability

44

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $2.51

45

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

46

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.59

8053915 Whirlpool Range Insulation Backorder WPL 8053915 $7.59

W10491985 Whirlpool Screw Backorder WPL W10491985 $2.51

W11684915 Whirlpool Insulation Backorder WPL W11684915 $47.58

W11688737 Whirlpool Insulation Backorder WPL W11688737 $47.58

Insulation WPL ARI164036A Contact Us For Availability
