Model Whirlpool SF380LEMQ0 30`` GAS FREESTANDING SELF CLEAN RANGE SEALED BURN – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $27.58

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.41

814381 Whirlpool Pin In Stock WPL 814381 $3.70

8523599 Whirlpool Range Wire Harness Backorder WPL 8523599 $80.82

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.13

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

WPL 8524207 WPL 8524207 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

1

Screw, Valve WPL 8273096 Contact Us For Availability

1

Safer Cooking Tips WPL LIT3191638 Contact Us For Availability

1

Literature Parts (Instruct, Install (Template WPL LIT8523048 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT9755996 Contact Us For Availability

1

Guide, Use & Care WPL LIT9756385 Contact Us For Availability

1

Literature Parts (Instructions, Installation) WPL LIT9756438 Contact Us For Availability

1

Endcap (Left Hand White) WPL 3186190 Contact Us For Availability

1

Endcap (Right Hand White) WPL 3186191 Contact Us For Availability

1

Endcap (Left Hand-Biscuit) WPL 8272507 Contact Us For Availability

1

Endcap (Right Hand-Biscuit) WPL 8272508 Contact Us For Availability

2

WP3191903 Whirlpool Burner Cap In Stock WPL WP3191903 $101.63

2

WP3191905 Whirlpool Burner Cap Backorder WPL WP3191905 $46.21

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $44.05

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $2.64

2

WP8273343 Whirlpool Burner Cap In Stock WPL WP8273343 $37.04

2

WP8273344 Whirlpool Burner Cap Backorder WPL WP8273344 $37.04

2

WP8273345 Whirlpool Burner Cap Backorder WPL WP8273345 $91.93

2

WP8273700 Whirlpool Base Burner In Stock WPL WP8273700 $58.44

2

Cap, Burner (RR) (Grey) WPL 3191899 Contact Us For Availability

2

Support, Endcap (Left Hand) WPL 8523408 Contact Us For Availability

2

Support, Endcap (Right Hand) WPL 8523409 Contact Us For Availability

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $176.34

3

Tubing, Burner W/Orifice (Right Front) WPL 8273695 Contact Us For Availability

3

Tubing, Burner W/Orifice (Left Front) WPL 8273692 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Rear) WPL 8273697 Contact Us For Availability

3

Panel, Control (Biscuit) WPL 8523930 Contact Us For Availability

3

Panel, Control (White) WPL 8523931 Contact Us For Availability

4

WP4455980 Whirlpool Burner Head In Stock WPL WP4455980 $39.31

4

WP4455981 Whirlpool Burner Head Backorder WPL WP4455981 $54.75

4

Burner (RR-6K) WPL 4455979 Contact Us For Availability

4

Screw WPL 4449746 Contact Us For Availability

5

8195546 Whirlpool Range Cooktop O/S2 Backorder WPL 8195546 $264.99

5

W11213959 Whirlpool Cooktop In Stock WPL W11213959 $253.93

5

WPW10295998 Whirlpool Wire Harness Backorder WPL WPW10295998 $85.63

5

WPW10331686 Whirlpool Range Spark Module In Stock WPL WPW10331686 $178.45

6

8053505 Whirlpool Range Shield Backorder WPL 8053505 $57.07

6

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $25.99

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.43

6

WP8053948 Whirlpool Door Glass In Stock WPL WP8053948 $68.30

6

WP8523793 Whirlpool Oven Surface Igniter In Stock WPL WP8523793 $17.68

6

WP8523854 Whirlpool Manifold Panel Backorder WPL WP8523854 $119.62

6

Panel, Manifold (Biscuit) WPL 8523856 Contact Us For Availability

7

3149360 Whirlpool Light Switch Backorder WPL 3149360 $37.94

7

WP8273104 Whirlpool Knob In Stock WPL WP8273104 $9.17

7

WP8273106 Whirlpool Knob Backorder WPL WP8273106 $10.89

7

Shield, Heat (2) WPL 3196136 Contact Us For Availability

7

Switch, Rocker (Biscuit) WPL 8273501 Contact Us For Availability

8

WP9757218 Whirlpool Burner Valve In Stock WPL WP9757218 $128.80

8

Valve (Right Rear) WPL 8273004 Contact Us For Availability

8

Frame, Front Not Serviced WPL ARI163874A Contact Us For Availability

8

Cover, Upper WPL 9756301 Contact Us For Availability

9

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $27.82

9

Nut (4) WPL 8273060 Contact Us For Availability

9

Shield, Heat WPL 8053910 Contact Us For Availability

WP8053807 Whirlpool Range Door Hinge In Stock WPL WP8053807 $49.45

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $2.51

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

Cover, Lower WPL 8273132 Contact Us For Availability

8523412 Whirlpool Mounting Bracket Backorder WPL 8523412 $98.66

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $85.47

WPW10447925 Whirlpool Grate Kit In Stock WPL WPW10447925 $198.76

Grate, Burner (4) (Espresso) WPL 8522853 Contact Us For Availability

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $98.14

WP8523166 Whirlpool Door Trim In Stock WPL WP8523166 $38.19

WP8523167 Whirlpool Door Trim Assembly Backorder WPL WP8523167 $37.19

WP8523172 Whirlpool Left Door Trim In Stock WPL WP8523172 $38.10

WP8523173 Whirlpool Door Trim Backorder WPL WP8523173 $37.24

WPW10181986 Whirlpool Range Sensor In Stock WPL WPW10181986 $66.20

Control, Range (White) WPL 6610395 Contact Us For Availability

Control, Range (Biscuit) WPL 6610396 Contact Us For Availability

13

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $112.34

13

Spreader, Flame (Oven) WPL 8053970 Contact Us For Availability

14

8053969 Whirlpool Heat Shield Backorder WPL 8053969 $38.41

14

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

14

WP3368921 Whirlpool Screw In Stock WPL WP3368921 $1.52

15

8053968 Whirlpool Range Heat Shield Backorder WPL 8053968 $30.89

16

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $57.62

16

WPW10306546 Whirlpool Base Rail In Stock WPL WPW10306546 $53.16

17

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $71.57

18

Seal, Oven Flange WPL 8524109 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $28.09

WP8273564 Whirlpool Clip Backorder WPL WP8273564 $5.22

WP8523175 Whirlpool Door Trim Assembly In Stock WPL WP8523175 $49.54

WP8523178 Whirlpool Door Trim Backorder WPL WP8523178 $54.73

20

WP8273065 Whirlpool Orifice Backorder WPL WP8273065 $34.55

20

WP8273067 Whirlpool Orifice Backorder WPL WP8273067 $34.62

20

Back, Main WPL 9757098 Contact Us For Availability

21

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $21.59

22

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

22

Brace, Main Back WPL 8053971 Contact Us For Availability

3196265 Whirlpool Range Screw Backorder WPL 3196265 $9.59

Clip, Door Stop (2) WPL 3196925 Contact Us For Availability

Retainer, Insul. (Right Hand) WPL 3195726 Contact Us For Availability

Retainer, Insul. (Left Hand) WPL 3196523 Contact Us For Availability

24

Clip, Panel (6) WPL 3196576 Contact Us For Availability

25

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.11

25

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $50.80

26

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

26

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

26

Spuds, LP Gas (Kit of 4) WPL 8523418 Contact Us For Availability

27

Switch, Door WPL 3195993 Contact Us For Availability

28

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $36.67

29

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $90.99

31

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $30.25

32

WPW10107830 Whirlpool Stove Door Lock Latch A Backorder WPL WPW10107830 $121.04

33

Glide, Drawer WPL 8522669 Contact Us For Availability

34

Screw WPL 3400228 Contact Us For Availability

35

Suppressor, Trans WPL 9756133 Contact Us For Availability

36

Button, Plug WPL 3196439 Contact Us For Availability

38

Screw WPL 3196152 Contact Us For Availability

39

3196166 Whirlpool Screw Backorder WPL 3196166 $4.85

39

Screw (Almond) WPL 3196167 Contact Us For Availability

40

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

42

Screw WPL 3196179 Contact Us For Availability

44

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $2.51

45

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

46

W11244557 Whirlpool Screw Backorder WPL W11244557 $9.59

W10491985 Whirlpool Screw Backorder WPL W10491985 $2.51

W11684915 Whirlpool Insulation Backorder WPL W11684915 $47.58

W11688737 Whirlpool Insulation Backorder WPL W11688737 $47.58

Insulation WPL ARI163875A Contact Us For Availability
