Model Whirlpool RT20AKXAL00 – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL LIT2154075 WPL LIT2154075 Contact Us For Availability

WPL LIT2163204 WPL LIT2163204 Contact Us For Availability

WPL LIT2163296 WPL LIT2163296 Contact Us For Availability

WPL LIT4361308 WPL LIT4361308 Contact Us For Availability

WPL LIT677969 WPL LIT677969 Contact Us For Availability

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

1

Panel, Freezer Door (Also Order Item 21) (Whi WPL 2159160 Contact Us For Availability

1

Panel, Freezer Door (Also Order Item 21) (Alm WPL 2159163 Contact Us For Availability

1

Panel, Refrigerator Door (Also Order Item 27) WPL 1122549 Contact Us For Availability

1

Panel, Refrigerator Door (Also Order Item 27) WPL 1122658 Contact Us For Availability

1

Cabinet (Not A Serviceable Part) WPL ARI127606A Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI127607A Contact Us For Availability

2

Wiring, Fan Motor WPL 1127626 Contact Us For Availability

2

Hole Plug (2) WPL 534927 Contact Us For Availability

2

Hole Plug (2) (Almond) WPL 989197 Contact Us For Availability

2

Roller, Front WPL 2152011 Contact Us For Availability

2

Fan, Blade WPL 851732 Contact Us For Availability

3

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

3

W10833053 Whirlpool Refrigerator Plate Backorder WPL W10833053 $6.31

3

Screw, 5/16-24 x 1-1/4 WPL 489393 Contact Us For Availability

3

Condenser Assembly WPL 2154010 Contact Us For Availability

4

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Bracket, Door Stop WPL 944035 Contact Us For Availability

4

Bracket, Door Stop WPL 1115910 Contact Us For Availability

5

W10854959 Whirlpool Refrigerator Shelf Stud Backorder WPL W10854959 $4.23

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

5

Clip, Wire WPL 548745 Contact Us For Availability

6

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

6

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

6

WP8281206 Whirlpool Refrigerator Screw In Stock WPL WP8281206 $2.51

6

Screw WPL 489327 Contact Us For Availability

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $3.70

7

Hole Plug (Almond) WPL 989196 Contact Us For Availability

7

Drain Pan/ Heat Shield WPL 2153974 Contact Us For Availability

8

2188450A Whirlpool Refrigerator Door Gasket Backorder WPL 2188450A $108.53

8

2188460A Whirlpool Refrigerator Door Gasket Backorder WPL 2188460A $89.09

8

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

8

Tube Clamp WPL 2159720 Contact Us For Availability

9

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

9

Control, Front Cover WPL 2163297 Contact Us For Availability

9

Stud (2) WPL 946356 Contact Us For Availability

9

Dampener WPL 2149670 Contact Us For Availability

819091 Whirlpool Refrigerator Shelf Stud Backorder WPL 819091 $13.89

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

End Cap, Top WPL 944157 Contact Us For Availability

Heater, Mullion WPL 2154065 Contact Us For Availability

11

Handle End, Center WPL 936930 Contact Us For Availability

11

Clip, Rail (4) WPL 1129018 Contact Us For Availability

Handle, Center WPL 2163218 Contact Us For Availability

Handle, Center WPL 1124376 Contact Us For Availability

Spacer (3) WPL 2149077 Contact Us For Availability

support stud (8) WPL 946355 Contact Us For Availability

4387535 Whirlpool Refrigerator Compressor Rel In Stock WPL 4387535 $68.76

Retainer, Gasket WPL 1122553 Contact Us For Availability

Shim, Handle WPL 935076 Contact Us For Availability

Center Rail (White) WPL 1122566 Contact Us For Availability

Center Rail (Almond) WPL 1122569 Contact Us For Availability

Cover, Air Duct WPL 2157411 Contact Us For Availability

14

WP2151652 Whirlpool Refrigerator Button Plug Backorder WPL WP2151652 $8.20

14

Spacer, Handle Door WPL 943188 Contact Us For Availability

14

Hole Plug (Almond) WPL 2151653 Contact Us For Availability

15

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

15

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

15

Interior Door Panel WPL 1122575 Contact Us For Availability

16

482731 Whirlpool Refrigerator Evaporator Fan In Stock WPL 482731 $47.13

16

WP488920 Whirlpool Refrigerator Screw Backorder WPL WP488920 $2.51

16

Housing Plug WPL 1118850 Contact Us For Availability

WP1100938 Whirlpool Refrigerator Fan Blade Backorder WPL WP1100938 $27.58

WP2189412 Whirlpool Refrigerator Door Hinge Backorder WPL WP2189412 $37.95

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $38.41

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

Running Capacitor WPL 2154565 Contact Us For Availability

WP487887 Whirlpool Refrigerator Screw Backorder WPL WP487887 $3.70

Nameplate WPL 2160005 Contact Us For Availability

Retainer, Insert WPL 1118080 Contact Us For Availability

Shim, Hinge Top WPL 1123517 Contact Us For Availability

Drain Fitting WPL 981629 Contact Us For Availability

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

Interior Door Panel WPL 2156208 Contact Us For Availability

Hinge Cover (Almond) WPL 2160404 Contact Us For Availability

Grommet (2) WPL 531933 Contact Us For Availability

Grommet, Screw WPL 509812 Contact Us For Availability

20

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $2.51

20

Trim, Door (2) WPL 1120833 Contact Us For Availability

20

Clip, Unit Cover WPL 548744 Contact Us For Availability

21

Trim, Door WPL 2163348 Contact Us For Availability

21

Hinge, Center WPL 2147335 Contact Us For Availability

21

Screw WPL 489168 Contact Us For Availability

EndCap, Trim (4) WPL 1106862 Contact Us For Availability

Compartment Door, Utility WPL 2163945 Contact Us For Availability

Shim, Hinge Center WPL 836155 Contact Us For Availability

Evaporator WPL 2153978 Contact Us For Availability

23

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.59

23

Compartment, Butter Door WPL 2163942 Contact Us For Availability

23

Scroll, Fan WPL 1127100 Contact Us For Availability

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP488296 Whirlpool Washer Refrigerator In Stock WPL WP488296 $3.70

Hole Plug, Handle (Almond) WPL 1122654 Contact Us For Availability

Evaporator Cover WPL 2157426 Contact Us For Availability

25

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $53.89

25

Insert, Handle WPL 1124378 Contact Us For Availability

26

WP2217784 Whirlpool Refrigerator Cover Backorder WPL WP2217784 $15.98

26

Endcap, Retainer WPL 1105804 Contact Us For Availability

26

Hinge Butt, Bottom WPL 1123378 Contact Us For Availability

27

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

27

Hinge Pin, Bottom WPL 654366 Contact Us For Availability

27

Hole Plug WPL 1103725 Contact Us For Availability

28

W10439652 Whirlpool Refrigerator Compressor Backorder WPL W10439652 $276.71

28

Screw 10-32 x 5/16 WPL 488714 Contact Us For Availability

28

Gasket, Retainer WPL 1122552 Contact Us For Availability

29

4318297 Whirlpool Refrigerator Shelf Bar Endc In Stock WPL 4318297 $10.39

29

Shim, Bottom WPL 1123379 Contact Us For Availability

29

Support, Heater WPL 2149120 Contact Us For Availability

30

WP489200 Whirlpool Refrigerator Washer Backorder WPL WP489200 $4.61

30

Unit Mounting Frame WPL 1127942 Contact Us For Availability

31

Gasket, Retainer WPL 1122551 Contact Us For Availability

31

Spacer WPL 1121117 Contact Us For Availability

32

WP1118001 Whirlpool Hinge Pin Backorder WPL WP1118001 $3.70

32

Fan, Motor Bracket WPL 2162062 Contact Us For Availability

33

Corner Filler, Grille WPL 1118078 Contact Us For Availability

33

Heater, Defrost WPL 2162019 Contact Us For Availability

34

Filler, Wrap Corner (White) WPL 1118058 Contact Us For Availability

34

Filler, Wrap Corner (Almond) WPL 1118059 Contact Us For Availability

35

WP4387503 Whirlpool Refrigerator Bimetal Defr In Stock WPL WP4387503 $16.40

35

Grille WPL 1129001 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Trim, Comp. Door WPL 2163344 Contact Us For Availability

Leveler, Enamel (13 Oz. Spray Can) WPL 350941 Contact Us For Availability

WPL 542639 WPL 542639 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Hole Plug (5) (White) WPL 1129062 Contact Us For Availability

Hole Plug (5) (Almond) WPL 1129063 Contact Us For Availability

37

Wiring Assembly, Intermediate WPL 2153994 Contact Us For Availability

38

WP250830 Whirlpool Refrigerator Screw Backorder WPL WP250830 $2.51

39

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

39

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

40

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

41

Air, Baffle WPL 1127938 Contact Us For Availability

42

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

43

WP2262181 Whirlpool Refrigerator Start Relay In Stock WPL WP2262181 $50.51

44

Cord, Service WPL 937360 Contact Us For Availability

44

Overload WPL 1108114 Contact Us For Availability

45

Cover WPL 1108115 Contact Us For Availability

46

Strap WPL 938384 Contact Us For Availability

47

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

48

Cover, Unit WPL 1105531 Contact Us For Availability

48

Unit Mounting Rail WPL 2149717 Contact Us For Availability

49

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

50

1105612 Whirlpool Fan Guard Backorder WPL 1105612 $24.10

51

Drain Extension WPL 2154119 Contact Us For Availability

53

Screw, WPL 488454 Contact Us For Availability

54

Support, Evaporator (R.S.) WPL 1118805 Contact Us For Availability

54

Support, Evaporator (L.S.) WPL 1118806 Contact Us For Availability

55

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

56

Nut WPL 489142 Contact Us For Availability

57

Washer WPL 489143 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Overload Spring WPL 1114190 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

60

WP489174 Whirlpool Refrigerator Screw Backorder WPL WP489174 $3.70

61

Tap-Plate, Bottom Hinge WPL 2147310 Contact Us For Availability

65

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

68

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94
