Model Whirlpool RS20CKXXL00 – Common Parts &amp; Diagrams

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL 350941 WPL 350941 Contact Us For Availability

WPL LIT2148770 WPL LIT2148770 Contact Us For Availability

WPL LIT2149920 WPL LIT2149920 Contact Us For Availability

WPL LIT2150287 WPL LIT2150287 Contact Us For Availability

WPL LIT4361011 WPL LIT4361011 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI123798A Contact Us For Availability

1

Refrigerator Door (White) WPL 2147643 Contact Us For Availability

1

Refrigerator Door (Almond) WPL 2147645 Contact Us For Availability

1

Refrigerator Door (Golden Harvest (Also Order WPL 4362015 Contact Us For Availability

1

Fan Scroll WPL 1127163 Contact Us For Availability

1

Control Box WPL 1129413 Contact Us For Availability

1

Strap WPL 851095 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Hole Plug WPL 944795 Contact Us For Availability

2

Tap Plate WPL 988402 Contact Us For Availability

3

4318165 Whirlpool Refrigerator Door Closure C In Stock WPL 4318165 $9.42

3

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

3

Screw, 5/16-24 x 1-1/4 WPL 489333 Contact Us For Availability

3

Air Scoop WPL 1110798 Contact Us For Availability

3

Screw (2) WPL 489190 Contact Us For Availability

3

Condenser WPL 1127573 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.34

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Evaporator, Support WPL 1108436 Contact Us For Availability

5

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

5

WP938213 Whirlpool Refrigerator Power Switch Backorder WPL WP938213 $13.76

5

Bracket, Door Stop WPL 1115906 Contact Us For Availability

5

Air Duct Freezer WPL 1108434 Contact Us For Availability

5

Clamp (2) WPL 510716 Contact Us For Availability

6

Mullion Rail WPL 1118354 Contact Us For Availability

6

Hole Plug WPL 655411 Contact Us For Availability

6

Shim WPL 988421 Contact Us For Availability

6

Diffuser, Air Duct WPL 2149544 Contact Us For Availability

6

Defrost Timer, (10 Hr.) WPL 1127570 Contact Us For Availability

6

Clip (2) WPL 548744 Contact Us For Availability

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

7

Heater, Mullion WPL 1106997 Contact Us For Availability

7

support stud (8) WPL 946355 Contact Us For Availability

7

Fan Motor WPL 2149964 Contact Us For Availability

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP1104787 Whirlpool Refrigerator Shim Backorder WPL WP1104787 $3.70

8

Blade, Fan WPL 992920 Contact Us For Availability

8

Front Mullion Rail (White) WPL 1123966 Contact Us For Availability

8

Front Mullion Rail (Golden Harvest) WPL 1123968 Contact Us For Availability

8

Front Mullion Rail (Almond) WPL 1123969 Contact Us For Availability

8

Stud (3) WPL 946356 Contact Us For Availability

9

WP2149540 Whirlpool Shelf Support In Stock WPL WP2149540 $4.34

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $45.43

9

Stud (3) WPL 1106982 Contact Us For Availability

9

Hole Plug WPL 534927 Contact Us For Availability

9

Ring, Compression WPL 992953 Contact Us For Availability

9

Cover WPL 1108115 Contact Us For Availability

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Filler Bottom Mullion (White) WPL 1118361 Contact Us For Availability

Filler Bottom Mullion (Almond) WPL 1118362 Contact Us For Availability

Filler Bottom Mullion (Golden Harvest) WPL 1118363 Contact Us For Availability

Grommet, (6) WPL 1110779 Contact Us For Availability

Fan Grommet (2) WPL 1114354 Contact Us For Availability

819091 Whirlpool Refrigerator Shelf Stud Backorder WPL 819091 $13.89

Clip, Ground WPL 1110607 Contact Us For Availability

Shim, Handle WPL 2147097 Contact Us For Availability

Screw (2) WPL 489168 Contact Us For Availability

Cam Assembly WPL 1110566 Contact Us For Availability

Overload WPL 1127582 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $119.63

Hinge, Top (2) WPL 1123514 Contact Us For Availability

Shelf WPL 1106979 Contact Us For Availability

13

Shim, Hinge (2) WPL 1123515 Contact Us For Availability

13

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

Hole, Plug (White) WPL 849391 Contact Us For Availability

Hole, Plug (Golden Harvest) WPL 989957 Contact Us For Availability

Hole Plug (Almond) WPL 989958 Contact Us For Availability

Shelf (3) WPL 1106980 Contact Us For Availability

Handle Center WPL 2147526 Contact Us For Availability

Retainer, Damper WPL 938439 Contact Us For Availability

Pivot Arm WPL 1110559 Contact Us For Availability

Hole Plug (White) WPL 1115352 Contact Us For Availability

Hole Plug (Golden Harvest) WPL 1115353 Contact Us For Availability

Hole Plug (Almond) WPL 1115354 Contact Us For Availability

Trivet WPL 2148400 Contact Us For Availability

Reinforcement (3) WPL 849445 Contact Us For Availability

Housing Plug WPL 1118850 Contact Us For Availability

16

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

16

Hinge Bottom (R.H.) WPL 2151619 Contact Us For Availability

WPW10329686 Whirlpool Door Cam Black In Stock WPL WPW10329686 $3.39

Socket Assembly WPL 1108630 Contact Us For Availability

Cover, Evaporator WPL 1127168 Contact Us For Availability

Light Socket WPL 1110690 Contact Us For Availability

Compressor (Includes Items 51, 52, 53, 54, 55 WPL 482981 Contact Us For Availability

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

Lens, Light WPL 1108445 Contact Us For Availability

Reinforcement, Handle WPL 1127465 Contact Us For Availability

WP2158826 Whirlpool Refrigerator Dampener Backorder WPL WP2158826 $0.90

WP548049 Whirlpool Refrigerator Light Bulb Backorder WPL WP548049 $26.21

hinge Bottom (L.H.) WPL 2151620 Contact Us For Availability

Nameplate WPL 1124315 Contact Us For Availability

Gasket, Evaporator Cover (2) WPL 1110675 Contact Us For Availability

Spacer, Hinge WPL 1129868 Contact Us For Availability

Shim .030 WPL 836196 Contact Us For Availability

Cover, Wiring WPL 1129915 Contact Us For Availability

Gasket Retainer, Top & Bottom WPL 1118301 Contact Us For Availability

Gasket, Evaporator Cover Top (2) WPL 1110676 Contact Us For Availability

Control Box Harness WPL 2149748 Contact Us For Availability

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

Filler, Wrapper (White) WPL 1110708 Contact Us For Availability

Filler, Wrapper (Almond) WPL 1110709 Contact Us For Availability

Filler, Wrapper (Golden Harvest) WPL 1110710 Contact Us For Availability

Gasket Retainer, Side (2) WPL 1117766 Contact Us For Availability

Grille WPL 1129001 Contact Us For Availability

Fitting, Drain WPL 942768 Contact Us For Availability

Panel, Interior Door WPL 1129249 Contact Us For Availability

CLIP, WIRING WPL 1115375 Contact Us For Availability

Dampener WPL 510769 Contact Us For Availability

Screw WPL 489327 Contact Us For Availability

Trim, Door Shelf (5) WPL 1120852 Contact Us For Availability

Connecting Rod WPL 1123959 Contact Us For Availability

Exchanger, Heat WPL 1127577 Contact Us For Availability

24

end cap, trim (10) WPL 1110713 Contact Us For Availability

24

Fastener, Push-On WPL 489285 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $32.98

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

Door, Compartment WPL 1124431 Contact Us For Availability

Escutcheon, Control Box WPL 1123999 Contact Us For Availability

26

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $9.53

26

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

26

Trim, Compartment Door WPL 1124432 Contact Us For Availability

27

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

27

Knob, Air Control WPL 1110562 Contact Us For Availability

28

Hole Seal WPL 1120224 Contact Us For Availability

28

Trim, Handle WPL 2147581 Contact Us For Availability

28

Knob, Retainer WPL 837444 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Hole Seal 8 x 1/2 WPL 1129056 Contact Us For Availability

Transformer (115-230 Volt) WPL 515393 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Enamel, Black (1 Qt. Uncut) WPL 799340 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

30

1105612 Whirlpool Fan Guard Backorder WPL 1105612 $24.10

31

Tap Plate (2) WPL 2147310 Contact Us For Availability

31

Evaporator WPL 1106987 Contact Us For Availability

32

Cabinet Harness WPL 2149746 Contact Us For Availability

32

Clamp WPL 513584 Contact Us For Availability

33

WP250830 Whirlpool Refrigerator Screw Backorder WPL WP250830 $2.51

33

WP4387499 Whirlpool Refrigerator Bimetallic D In Stock WPL WP4387499 $41.78

34

Clamp WPL 937357 Contact Us For Availability

34

Heater, Defrost WPL 2154542 Contact Us For Availability

35

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

35

Wire Connector WPL 227991 Contact Us For Availability

36

Cover, Wiring WPL 1129193 Contact Us For Availability

37

Blade, Fan WPL 1108179 Contact Us For Availability

37

Wiring Shield, Short WPL 1108440 Contact Us For Availability

38

WP2002171 Whirlpool Refrigerator Sleeve Backorder WPL WP2002171 $10.19

38

Wiring Shield, Long WPL 1108441 Contact Us For Availability

39

Tube Clamp (2) WPL 1105607 Contact Us For Availability

40

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

40

Cord, Service WPL 937360 Contact Us For Availability

41

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

41

Drain Ferrule WPL 842258 Contact Us For Availability

42

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

42

Frame WPL 1127942 Contact Us For Availability

43

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

43

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $4.63

44

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

44

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

45

Cover, Plug WPL 1108443 Contact Us For Availability

45

Rail, Front WPL 2149717 Contact Us For Availability

46

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

46

Sealing Gasket WPL 1115321 Contact Us For Availability

47

Cover, Unit WPL 1105531 Contact Us For Availability

48

Bracket, Fan Motor WPL 548695 Contact Us For Availability

49

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $12.24

49

WPL 989896 WPL 989896 Contact Us For Availability

49

Air, Baffle WPL 1127938 Contact Us For Availability

50

Grommet WPL 509812 Contact Us For Availability

51

WP2262181 Whirlpool Refrigerator Start Relay In Stock WPL WP2262181 $50.51

51

WPL 1118236 WPL 1118236 Contact Us For Availability

52

Overload WPL 483037 Contact Us For Availability

53

WPL 548745 WPL 548745 Contact Us For Availability

53

Cover, Terminal WPL 1105015 Contact Us For Availability

54

Terminal Strap WPL 938384 Contact Us For Availability

55

Capacitor WPL 482996 Contact Us For Availability

56

Screw, 1/4-28 x 1/2 (2) WPL 488624 Contact Us For Availability

57

Nut WPL 489142 Contact Us For Availability

58

Overload Spring WPL 1114190 Contact Us For Availability

59

Washer WPL 489143 Contact Us For Availability

60

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

68

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $53.89

81

Screw, 8-32 x 1/2 WPL 489050 Contact Us For Availability

83

Clamp, Dryer WPL 1127590 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Clamp (4) WPL 1108431 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
