  • Accelerated Cooking Products RFS12SW2C-P1330237M

Model Accelerated Cooking Products RFS12SW2C-P1330237M Amana Menumaster RFS12SW2C – Common Parts & Diagrams

1
TRANSFORMER, HV
TRANSFORMER, HV ACP 53002040 Contact Us For Availability
View on Model
1
ANTENNA SHIELD
ANTENNA SHIELD ACP 53002003 Contact Us For Availability
View on Model
1
SCREW
SCREW ACP 13004401 Contact Us For Availability
View on Model
2
ESCUTCHEON / TOUCH PANEL ASSY
ESCUTCHEON / TOUCH PANEL ASSY ACP 54116007 Contact Us For Availability
View on Model
2
COVER, LAMP- SS
COVER, LAMP- SS ACP 20051701 Contact Us For Availability
View on Model
3
WINDOW, INNER
WINDOW, INNER ACP 13066801 Contact Us For Availability
View on Model
3
GASKET, BASEPAN - 90 in (228 cm)
GASKET, BASEPAN - 90 in (228 cm) ACP R0000413 Contact Us For Availability
View on Model
3
LAMP
LAMP ACP 54137074 Contact Us For Availability
View on Model
3
SCREW, TAPPING TRUSS HEAD
SCREW, TAPPING TRUSS HEAD ACP R0131246 Contact Us For Availability
View on Model
3
SCREW, SPECIAL D
SCREW, SPECIAL D ACP R0654178 Contact Us For Availability
View on Model
4
BOARD, HV/LV (RFS12SW2B)
BOARD, HV/LV (RFS12SW2B) ACP 14114047 Contact Us For Availability
View on Model
4
WRAPPER- SS
WRAPPER- SS ACP 53001577 Contact Us For Availability
View on Model
5
SCREW, TRUSS HD
SCREW, TRUSS HD ACP R0654183 Contact Us For Availability
View on Model
5
SCREW, PAN HEAD
SCREW, PAN HEAD ACP 54116044 Contact Us For Availability
View on Model
6
SCREW, TRUSS HD S/TAP
SCREW, TRUSS HD S/TAP ACP R0654038 Contact Us For Availability
View on Model
7
PLATE, BACK
PLATE, BACK ACP 20059601 Contact Us For Availability
View on Model
8
SCREW, HANDLE SIDE
SCREW, HANDLE SIDE ACP 12002453 Contact Us For Availability
View on Model
8
FILTER, AIR- W/THUMB SCREW
FILTER, AIR- W/THUMB SCREW ACP 54116015 Contact Us For Availability
View on Model
8
THERMAL CUTOUT, CAVITY
THERMAL CUTOUT, CAVITY ACP 53001817 Contact Us For Availability
View on Model
8
SCREW, BINING HD S/TAP
SCREW, BINING HD S/TAP ACP R0654028 Contact Us For Availability
View on Model
9
SCREW, PAN HD
SCREW, PAN HD ACP R0654180 Contact Us For Availability
View on Model
10
MOTOR, ANTENNA
MOTOR, ANTENNA ACP 56002013 Contact Us For Availability
View on Model
11
KIT, ANTENNA- TOP
KIT, ANTENNA- TOP ACP 12002592 Contact Us For Availability
View on Model
12
RIVET ASSY
RIVET ASSY ACP 54116064 Contact Us For Availability
View on Model
13
SWITCH, INTERLOCK ASSY
SWITCH, INTERLOCK ASSY ACP 14164113 Contact Us For Availability
View on Model
13
KIT, ANTENNA- BOTTOM
KIT, ANTENNA- BOTTOM ACP 12002593 Contact Us For Availability
View on Model
14
TRAY, CERAMIC
TRAY, CERAMIC ACP 53002009 Contact Us For Availability
View on Model
15
INSULATOR
INSULATOR ACP 20209801 Contact Us For Availability
View on Model
16
BRACKET, CAPACITOR, BACK
BRACKET, CAPACITOR, BACK ACP 20060901 Contact Us For Availability
View on Model
17
DIODE
DIODE ACP 20057401 Contact Us For Availability
View on Model
18
COVER, POWER CORD
COVER, POWER CORD ACP 20058501 Contact Us For Availability
View on Model
19
POWER CORD
POWER CORD ACP 20057504 Contact Us For Availability
View on Model
20
MAGNETRON
MAGNETRON ACP 53002025 Contact Us For Availability
View on Model
21
FILTER ASSEMBLY
FILTER ASSEMBLY ACP 53001565 Contact Us For Availability
View on Model
22
BLOWER MOTOR ASSEMBLY
BLOWER MOTOR ASSEMBLY ACP 53002049 Contact Us For Availability
View on Model
23
HARNESS, MAIN
HARNESS, MAIN ACP 53002058 Contact Us For Availability
View on Model
25
DUCT, MAG.
DUCT, MAG. ACP 54116014 Contact Us For Availability
View on Model
26
FUSE-HV
FUSE-HV ACP 59244843 Contact Us For Availability
View on Model
27
FUSE BLOCK/FILTER ASSY
FUSE BLOCK/FILTER ASSY ACP 54116032 Contact Us For Availability
View on Model
28
FUSE- 15A TD
FUSE- 15A TD ACP 20057302 Contact Us For Availability
View on Model
29
BRACKET, CAPACITOR, FRONT
BRACKET, CAPACITOR, FRONT ACP 20061001 Contact Us For Availability
View on Model
30
CAPACITOR, .70
CAPACITOR, .70 ACP 53002038 Contact Us For Availability
View on Model
31
DUCT, EXHAUST- RIGHT
DUCT, EXHAUST- RIGHT ACP 54116016 Contact Us For Availability
View on Model
