Model Whirlpool RF366PXXN1 – Common Parts &amp; Diagrams

WPL LIT3147395 WPL LIT3147395 Contact Us For Availability

WPL LIT3149507 WPL LIT3149507 Contact Us For Availability

WPL LIT3150299 WPL LIT3150299 Contact Us For Availability

WPL LIT3181612 WPL LIT3181612 Contact Us For Availability

WPL LIT884957 WPL LIT884957 Contact Us For Availability

1

Liner, Door WPL 3172218 Contact Us For Availability

1

Latch Assembly WPL 3171153 Contact Us For Availability

1

Main Chassis (Screw 10-24x1/2) WPL 247326 Contact Us For Availability

1

Main Chassis (Black) WPL 3181515 Contact Us For Availability

1

Main Chassis (White) WPL 330086 Contact Us For Availability

1

Main Chassis (Almond) WPL 330090 Contact Us For Availability

1

Harness, Wire (Surface Unit) WPL 3169104 Contact Us For Availability

2

Frame, Glass WPL 3148234 Contact Us For Availability

2

Safety Switch WPL 308185 Contact Us For Availability

2

Screw (2) WPL 98106 Contact Us For Availability

2

Harness, Wire (Oven) WPL 3169011 Contact Us For Availability

3

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

3

Seal, Foam WPL 3148441 Contact Us For Availability

3

Insulator, Switch WPL 309245 Contact Us For Availability

3

Harness, Wire (Supply) WPL 3149680 Contact Us For Availability

4

Glass, Reflective WPL 3148178 Contact Us For Availability

4

Screw, 6 x 3/8B (2) WPL 309258 Contact Us For Availability

4

Shield, Latch Terminal WPL 313035 Contact Us For Availability

4

Screw (1) WPL 3150537 Contact Us For Availability

4

Frame, Front WPL 3172194 Contact Us For Availability

4

Harness, Wiring (Oven Light) WPL 313152 Contact Us For Availability

5

WP660579 Whirlpool Range Wall Oven Broil Elem In Stock WPL WP660579 $66.17

5

Seal, Window WPL 3148183 Contact Us For Availability

5

Handle, Latch (Screw, 10-24 x 1/2 (2)) WPL 308422 Contact Us For Availability

5

Handle, Latch (Designer White) WPL 3150175 Contact Us For Availability

5

Handle, Latch (Black) WPL 3169081 Contact Us For Availability

5

Pin, Hinge WPL 307985 Contact Us For Availability

5

Harness, Wire (Lock Switch) WPL 3169012 Contact Us For Availability

6

488946 Whirlpool Air Conditioner Clamp Backorder WPL 488946 $10.25

6

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

6

WP486579 Whirlpool Air Conditioner Screw Backorder WPL WP486579 $3.11

6

Latch Knob (Black) WPL 3148684 Contact Us For Availability

6

Retainer, Insulation WPL 3148159 Contact Us For Availability

6

Latch Knob (Designer White) WPL 3150174 Contact Us For Availability

6

Seal, Door WPL 3148284 Contact Us For Availability

7

WP3169203 Whirlpool Door Glass Backorder WPL WP3169203 $61.02

7

Pin, Top (2) WPL 307966 Contact Us For Availability

7

Pushnut WPL 308306 Contact Us For Availability

8

Screw (4) WPL 3148443 Contact Us For Availability

8

Retainer, Glass (2) WPL 3148187 Contact Us For Availability

8

Hinge (R.H.) WPL 327890 Contact Us For Availability

8

Hinge (L.H.) WPL 327891 Contact Us For Availability

9

Bumper (4) WPL 3148182 Contact Us For Availability

9

Bracket, Light WPL 3149032 Contact Us For Availability

9

Screw (3) WPL 311056 Contact Us For Availability

9

Oven (30`` Pyro) WPL 3172547 Contact Us For Availability

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $36.67

Glass, Door (Black) WPL 3148185 Contact Us For Availability

Glass, Door (White) WPL 3149049 Contact Us For Availability

Shield, Probe WPL 3149262 Contact Us For Availability

11

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

11

Foil WPL 3148184 Contact Us For Availability

11

Bracket, Top (2) WPL 307965 Contact Us For Availability

WP355515 Whirlpool Screw Backorder WPL WP355515 $2.51

WP486754 Whirlpool Compactor Screw Backorder WPL WP486754 $2.51

Spring, Element (8) WPL 3149191 Contact Us For Availability

Handle, Door (Black) WPL 3148228 Contact Us For Availability

Handle, Door (Platinum) WPL 3149354 Contact Us For Availability

Insulation, Door WPL 3147951 Contact Us For Availability

Cooktop (White) WPL 3176523 Contact Us For Availability

cooktop (almond) WPL 3176524 Contact Us For Availability

Cooktop (Black) WPL 3176525 Contact Us For Availability

Cooktop (Designer White) WPL 3176526 Contact Us For Availability

14

Top, Door (Black) WPL 3148223 Contact Us For Availability

14

Top, Door (Panoramic Grey) WPL 3149355 Contact Us For Availability

14

Clip, Wire WPL 311311 Contact Us For Availability

15

Clip (2) WPL 3148282 Contact Us For Availability

15

Bracket, Oven (Mounting) WPL 311220 Contact Us For Availability

16

WP308685 Whirlpool Microwave Screw In Stock WPL WP308685 $2.51

16

Vent, Oven WPL 3148906 Contact Us For Availability

285006 Whirlpool Spray In Stock WPL 285006 $28.82

340184 Whirlpool Screw Backorder WPL 340184 $9.59

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72109 Whirlpool Dacor Avocado Touch-Up Paint Backorder WPL 72109 $10.07

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Wire, White 14 Ga. 150~c WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire, Red 12 Ga. 150~c WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire, Yellow 14 Ga. 200~c WPL 242832 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Coffee WPL 261886 Contact Us For Availability

Coffee (Uncu WPL 261887 Contact Us For Availability

WPL 261888 WPL 261888 Contact Us For Availability

WPL 261890 WPL 261890 Contact Us For Availability

WPL 261891 WPL 261891 Contact Us For Availability

WPL 285365 WPL 285365 Contact Us For Availability

WPL 285366 WPL 285366 Contact Us For Availability

WPL 285367 WPL 285367 Contact Us For Availability

WPL 285368 WPL 285368 Contact Us For Availability

WPL 312804 WPL 312804 Contact Us For Availability

WPL 3169093 WPL 3169093 Contact Us For Availability

WPL 3169094 WPL 3169094 Contact Us For Availability

WPL 72108 WPL 72108 Contact Us For Availability

WPL 72112 WPL 72112 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Switch, Broil WPL 314209 Contact Us For Availability

Frame, Glass WPL 3148235 Contact Us For Availability

Screw (3) WPL 3182345 Contact Us For Availability

Limiter, Temp. (230 MM - RR) WPL 3149123 Contact Us For Availability

Limiter, Temp. (180 MM - LR) WPL 3149125 Contact Us For Availability

Limiter, Temp. (200 MM - RF) WPL 3149126 Contact Us For Availability

Limiter, Temp. (250 mm (LF)) WPL 3149127 Contact Us For Availability

Screw, No.6 WPL 314215 Contact Us For Availability

Switch, Bake WPL 314210 Contact Us For Availability

Glide, Rear WPL 307980 Contact Us For Availability

Element, Surface (Includes No. 18) (180 MM - WPL 3148825 Contact Us For Availability

Element, Surface (Includes No. 18) (200 MM - WPL 3148826 Contact Us For Availability

Element, Surface (Includes No. 18) (230 MM - WPL 3148827 Contact Us For Availability

Channel, Arm (2) WPL 329710 Contact Us For Availability

WP307986 Whirlpool Hinge Pin Backorder WPL WP307986 $5.23

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

Panel Drawer (White) WPL 307935 Contact Us For Availability

Panel, Drawer (Almond) WPL 307939 Contact Us For Availability

Panel Drawer (Black) WPL 309923 Contact Us For Availability

End Cap R.H. WPL 313230 Contact Us For Availability

End Cap L.H. WPL 313231 Contact Us For Availability

WP488627 Whirlpool Refrigerator Screw In Stock WPL WP488627 $4.26

Handle, Drawer WPL 313337 Contact Us For Availability

Motor, Timer WPL 309822 Contact Us For Availability

Ring, Retainer (2) WPL 307594 Contact Us For Availability

22

WP308126 Whirlpool Door Spring In Stock WPL WP308126 $12.59

22

Drawer, Utility WPL 327887 Contact Us For Availability

22

Glass, Timer WPL 313513 Contact Us For Availability

WP308125 Whirlpool Microwave Range/Cooktop An Backorder WPL WP308125 $5.29

Screw (4) WPL 254225 Contact Us For Availability

End Trim L.H. WPL 313190 Contact Us For Availability

End Trim R.H. WPL 313191 Contact Us For Availability

Protector, Drawer (2) WPL 309329 Contact Us For Availability

Timer, Clock (Black with Chrome) WPL 3149505 Contact Us For Availability

Timer, Clock WPL 3150772 Contact Us For Availability

Support, L.H. Channel WPL 313196 Contact Us For Availability

Support, R.H. Channel WPL 313197 Contact Us For Availability

25

Switch, Door WPL 310345 Contact Us For Availability

25

Cap, Top Designer White Mdl WPL 3181363 Contact Us For Availability

25

WPL 3148809 WPL 3148809 Contact Us For Availability

26

WPL 312604 WPL 312604 Contact Us For Availability

26

WPL 3150628 WPL 3150628 Contact Us For Availability

26

WPL 3181487 WPL 3181487 Contact Us For Availability

27

98005642 Whirlpool Clip Backorder WPL 98005642 $30.25

27

WP3148952 Whirlpool Range Infinite Switch In Stock WPL WP3148952 $33.53

27

WP3148955 Whirlpool Infinite Switch Backorder WPL WP3148955 $72.47

28

WPL 3148419 WPL 3148419 Contact Us For Availability

29

WP313808 Whirlpool Screw Backorder WPL WP313808 $2.51

29

WPL 3148933 WPL 3148933 Contact Us For Availability

29

Snubber, Door (2) WPL 309111 Contact Us For Availability

30

WPL 314031 WPL 314031 Contact Us For Availability

30

WPL 3150647 WPL 3150647 Contact Us For Availability

30

Eliminator, Smoke WPL 3147241 Contact Us For Availability

31

WP3149983 Whirlpool Knob Backorder WPL WP3149983 $12.19

31

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

31

Box, Vent WPL 3147076 Contact Us For Availability

32

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.64

32

WPL 313570 WPL 313570 Contact Us For Availability

32

Support, Chassis (2) WPL 3147646 Contact Us For Availability

33

Screw (2) WPL 98520 Contact Us For Availability

33

WPL 313195 WPL 313195 Contact Us For Availability

33

Shield, Box WPL 3149006 Contact Us For Availability

34

WPL 313101 WPL 313101 Contact Us For Availability

34

Box, Vent WPL 3171381 Contact Us For Availability

35

WP3169181 Whirlpool Knob Backorder WPL WP3169181 $9.28

36

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

36

WPL 313608 WPL 313608 Contact Us For Availability

37

WPL 3149986 WPL 3149986 Contact Us For Availability

37

WPL 3181466 WPL 3181466 Contact Us For Availability

38

WPL 3149988 WPL 3149988 Contact Us For Availability

38

WPL 3181467 WPL 3181467 Contact Us For Availability

WPL 3149190 WPL 3149190 Contact Us For Availability

WPL 3149011 WPL 3149011 Contact Us For Availability

WPL 3149012 WPL 3149012 Contact Us For Availability

WPL 3181829 WPL 3181829 Contact Us For Availability

44

WPL 3149029 WPL 3149029 Contact Us For Availability

45

3149360 Whirlpool Light Switch Backorder WPL 3149360 $37.94

45

WP4314961 Whirlpool Lite Switch Backorder WPL WP4314961 $31.90
