Model Whirlpool RF196LXKQ0 COOKTOP – Common Parts &amp; Diagrams

1

WPW10256908 Whirlpool Oven Range Rack In Stock WPL WPW10256908 $60.51

1

Trim, Door Top (Black) WPL 3196819 Contact Us For Availability

1

Trim, Door Top (Biscuit) WPL 8522434 Contact Us For Availability

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $41.94

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $2.51

2

Spring, Locator WPL 3149191 Contact Us For Availability

3

W10202219 Whirlpool Door Handle Assembly Backorder WPL W10202219 $103.68

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $167.94

3

WP3196170 Whirlpool Screw Backorder WPL WP3196170 $2.51

3

WPW10202217 Whirlpool Door Handle In Stock WPL WPW10202217 $101.23

3

Handle, Door (Biscuit) WPL 8522448 Contact Us For Availability

4

WP3148952 Whirlpool Oven Infinite Switch In Stock WPL WP3148952 $33.53

4

WP3148953 Whirlpool Oven Infinite Switch In Stock WPL WP3148953 $34.61

4

Liner, Door WPL 3186292 Contact Us For Availability

4

Drawer, Storage WPL 8272605 Contact Us For Availability

5

W10838990 Whirlpool Mounting Bracket In Stock WPL W10838990 $31.66

5

Seal, Window WPL 8522414 Contact Us For Availability

6

3196815 Whirlpool Oven Rivet Backorder WPL 3196815 $9.59

6

WP3196068 Whirlpool Light Lens In Stock WPL WP3196068 $2.85

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.43

6

WP8053948 Whirlpool Door Glass In Stock WPL WP8053948 $67.09

7

W11219377 Whirlpool Drawer Panel Backorder WPL W11219377 $70.99

7

W11230476 Whirlpool Drawer Panel Backorder WPL W11230476 $70.99

7

W11230488 Whirlpool Drawer Panel Backorder WPL W11230488 $70.99

7

WP8522565 Whirlpool Knob In Stock WPL WP8522565 $11.75

7

WP8522566 Whirlpool Knob Backorder WPL WP8522566 $11.14

7

WPW10316950 Whirlpool Window Frame Backorder WPL WPW10316950 $28.80

8

WPW10278991 Whirlpool Insulation Backorder WPL WPW10278991 $40.48

8

Spacer, Glide WPL 8522669 Contact Us For Availability

9

W11539580 Whirlpool Retainer Backorder WPL W11539580 $80.49

9

WP487939 Whirlpool Refrigerator Nut Backorder WPL WP487939 $2.51

9

Screw WPL 4449746 Contact Us For Availability

10

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

10

WP8053807 Whirlpool Oven Door Hinge In Stock WPL WP8053807 $49.45

10

WP8272473 Whirlpool Rear Cover Backorder WPL WP8272473 $112.03

3149360 Whirlpool Light Switch Backorder WPL 3149360 $36.12

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $26.75

WP8053834 Whirlpool Door Glass Backorder WPL WP8053834 $128.85

WPW10118455 Whirlpool Door Glass Assembly In Stock WPL WPW10118455 $195.36

Glass, Outer Door (Biscuit) WPL 8272498 Contact Us For Availability

Rail Assy, Drawer (Left) WPL 8274190 Contact Us For Availability

Rail Assy, Drawer (Right) WPL 8274191 Contact Us For Availability

12

WP3195993 Whirlpool Light Switch Backorder WPL WP3195993 $56.02

13

W10491985 Whirlpool Screw In Stock WPL W10491985 $2.51

13

Liner, Drawer WPL 8272311 Contact Us For Availability

242831 Whirlpool Oven Wire Backorder WPL 242831 $261.62

285006 Whirlpool Spray In Stock WPL 285006 $27.45

3184020 Whirlpool Oven Wire Backorder WPL 3184020 $28.80

3196696 Whirlpool Clip Backorder WPL 3196696 $6.61

3400964 Whirlpool Oven Clip Backorder WPL 3400964 $32.57

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

814229 Whirlpool Primary Roller In Stock WPL 814229 $27.60

814381 Whirlpool Pin Backorder WPL 814381 $3.70

8184858 Whirlpool Door Trim Backorder WPL 8184858 $61.47

8184859 Whirlpool Range Oven Door Trim Kit (2 In Stock WPL 8184859 $48.50

8184860 Whirlpool Oven Door Trim Backorder WPL 8184860 $55.24

8212471 Whirlpool Oven Paint In Stock WPL 8212471 $35.69

8273888A Whirlpool Range Oven Anchor Anti-Tip In Stock WPL 8273888A $11.14

W10355051 Whirlpool Cooktop Cleaner Affresh ( In Stock WPL W10355051 $5.93

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $26.50

WP3196154 Whirlpool Screw Assembly Backorder WPL WP3196154 $2.51

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $28.80

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire, White 14 Ga. 150~c WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire, Red 12 Ga. 150~c WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire, Yellow 14 Ga. 200~c WPL 242832 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Clip, Ground Wire WPL 313660 Contact Us For Availability

WPL 4392900 WPL 4392900 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 8272999 WPL 8272999 Contact Us For Availability

WPL 8273266 WPL 8273266 Contact Us For Availability

WPL 8273304 WPL 8273304 Contact Us For Availability

WPL 8273305 WPL 8273305 Contact Us For Availability

15

Frame, Front (Non-Serviceable) WPL ARI159923A Contact Us For Availability

15

Clip, Glass (4) WPL 3196025 Contact Us For Availability

16

WP3400882 Whirlpool Screw In Stock WPL WP3400882 $2.51

16

WP8054068 Whirlpool Retainer Backorder WPL WP8054068 $28.80

16

Bracket, Latch WPL 3195914 Contact Us For Availability

17

Clip, Panel (6) WPL 3196576 Contact Us For Availability

18

WP179051 Whirlpool Screw Backorder WPL WP179051 $2.51

18

WPW10306546 Whirlpool Base Rail Backorder WPL WPW10306546 $50.64

19

WP3196925 Whirlpool Clip Assembly Backorder WPL WP3196925 $5.16

19

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

20

Shield, Outer (2) WPL 3196091 Contact Us For Availability

21

Shield, Inner (2) WPL 3196092 Contact Us For Availability

22

WP3196794 Whirlpool Glass Bracket Backorder WPL WP3196794 $11.53

22

Retainer, Side (2) WPL 3195717 Contact Us For Availability

23

WPW10181986 Whirlpool Oven Sensor In Stock WPL WPW10181986 $50.55

24

Support, Front (2) WPL 3195736 Contact Us For Availability

25

Support, Corner RR WPL 3195987 Contact Us For Availability

28

W10404688 Whirlpool Bracket Support Backorder WPL W10404688 $7.69

29

W11728255 Whirlpool Service Bracket Backorder WPL W11728255 $28.68

30

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

30

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.45

31

Back, Main WPL 8274034 Contact Us For Availability

33

WPW10134285 Whirlpool Vent Tube Backorder WPL WPW10134285 $169.15

34

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $36.62

35

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

37

Ground Strap WPL 3169573 Contact Us For Availability

38

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

41

WP3196174 Whirlpool Screw Backorder WPL WP3196174 $2.51

42

Screw WPL 3196179 Contact Us For Availability

43

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $2.51

44

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

46

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

47

WP489491 Whirlpool Refrigerator Screw In Stock WPL WP489491 $2.51

48

W11244557 Whirlpool Screw Backorder WPL W11244557 $9.59

8053915 Whirlpool Oven Insulation Backorder WPL 8053915 $7.59

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

WP8272612 Whirlpool Insulation Backorder WPL WP8272612 $77.67

Insulation WPL ARI159924A Contact Us For Availability
