Model LG RAD-81C – Common Parts & Diagrams
Diagram 0
Common parts from model LG RAD-81C
135312
Grille Assembly,Front LGE 3530AR1615B Contact Us For Availability
135312
Grille Assembly,Front LGE 3531A20087B Contact Us For Availability
135313
GRILLE,INLET LGE 3530A10039A Contact Us For Availability
147581
LINK HOLDER PP JI-350 LW-A0512 LGE 4520AR3191A Contact Us For Availability
147582-2
VANE,VERTICAL LGE 5990AR3190D Contact Us For Availability
149980
Shroud LGE MHN41571401 Contact Us For Availability
237200
PANEL,CONTROL LGE 3720A20017A Contact Us For Availability
238310
ESCUTCHEON LGE 3831A10001F Contact Us For Availability
249950
Case Assembly,Control LGE ABQ57504310 Contact Us For Availability
267110
Remote Controller Assembly LGE 6711A20066C Contact Us For Availability
268711-1
PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20432B Contact Us For Availability
268711-2
PCB Assembly,Main LGE EBR39266613 Contact Us For Availability
346811
Motor Assembly,AC,Single LGE 4681A10016S Contact Us For Availability
352113
Tube Assembly,Suction LGE AJR36020003 Contact Us For Availability
352115
Tube Assembly,Evaporator(In) LGE AJR36600003 Contact Us For Availability
352390-1
Guide Assembly,Air LGE AEC36811301 Contact Us For Availability
352390-2
Guide Assembly,Air LGE AEC36596102 Contact Us For Availability
354210
Evaporator Assembly,First LGE ADL72909101 Contact Us For Availability
552113
Tube Assembly,Condenser(Out) LGE AJR37048101 Contact Us For Availability
554160
Compressor Set,China LGE TBZ32370701 Contact Us For Availability
567502
Overload Protect LGE 6750U5L004D Contact Us For Availability
731273
INSTALL PART ASSEMBLY,SINGLE LGE 3127A20074A Contact Us For Availability
749740
UPPER GUIDE LW-A0510/511CL LGE 5210AR3196C Contact Us For Availability
× ![]()
