Frigidaire PRFG2383AF5 REFRIGERATOR, FRENCH DOOR, BOTTOM FREEZER, W/INTERNAL DISPENSER Parts List

1

218976443 Frigidaire Refrigerator Tube In Stock WCI 218976443 $8.60

View on Model

1

5304537408 Frigidaire Gasket In Stock WCI 5304537408 $51.94

View on Model

1A

DEFLECTOR, AIR, CONDENSER, W/FOAM TAPE WCI 241987302 Contact Us For Availability

View on Model

2

241778315 Frigidaire Door Gasket In Stock WCI 241778315 $62.39

View on Model

2

A21755301 Frigidaire Refrigerator Ice Maker A In Stock WCI A21755301 $135.96

View on Model

3

5304531313 Frigidaire Bracket Assembly Backorder WCI 5304531313 $49.41

View on Model

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $18.53

View on Model

4

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.50

View on Model

5

Backorder WCI 5304530727 $16.12

View on Model

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $23.09

View on Model

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $11.78

View on Model

9

5304508006 Frigidaire Refrigerator Bushing Backorder WCI 5304508006 $7.67

View on Model

11

241860104 Frigidaire Refrigerator Coil Cover Backorder WCI 241860104 $19.03

View on Model

12

241860105 Frigidaire Refrigerator Coil Cover Backorder WCI 241860105 $10.85

View on Model

12

809108704 Frigidaire Refrigerator Badge In Stock WCI 809108704 $17.40

View on Model

13

5304508039 Frigidaire Refrigerator Door Stop Backorder WCI 5304508039 $13.61

View on Model

13A

5304508038 Frigidaire Refrigerator Door Stop Backorder WCI 5304508038 $13.57

View on Model

14

5304520495 Frigidaire Refrigerator Switch In Stock WCI 5304520495 $12.20

View on Model

14

5304531011 Frigidaire Refrigerator Heater In Stock WCI 5304531011 $107.26

View on Model

15

242044505 Frigidaire Refrigerator Evaporator Backorder WCI 242044505 $24.50

View on Model

15B

5304536788 Frigidaire Lamp Backorder WCI 5304536788 $31.97

View on Model

15C

5304524658 Frigidaire Refrigerator Light Asse Backorder WCI 5304524658 $71.26

View on Model

16

BRACKET Backorder WCI 5304530897 $5.03

View on Model

17

241791201 Frigidaire Refrigerator Drain Troug Backorder WCI 241791201 $69.03

View on Model

18

GASKET Backorder WCI 241860131 $3.53

View on Model

18

5304536767 Frigidaire Handle Assembly Backorder WCI 5304536767 $77.35

View on Model

19

241510904 Frigidaire Refrigerator Dispenser H Backorder WCI 241510904 $38.53

View on Model

20

5303918645 Frigidaire Refrigerator Thermistor In Stock WCI 5303918645 $52.27

View on Model

21

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $6.79

View on Model

21

241732101 Frigidaire Refrigerator Screw Backorder WCI 241732101 $9.97

View on Model

21C

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.04

View on Model

22B

241760403 Frigidaire Refrigerator Bearing Backorder WCI 241760403 $12.22

View on Model

22C

241760401 Frigidaire Refrigerator Bearing Backorder WCI 241760401 $12.20

View on Model

24

240383412 Frigidaire Refrigerator Screw In Stock WCI 240383412 $7.30

View on Model

24

241812301 Frigidaire Refrigerator Compressor Backorder WCI 241812301 $7.71

View on Model

25

240383407 Frigidaire Refrigerator Screw Backorder WCI 240383407 $8.15

View on Model

25

242037702 Frigidaire Refrigerator Spring Clip Backorder WCI 242037702 $5.42

View on Model

26

241920608 Frigidaire Defrost Pan Backorder WCI 241920608 $80.76

View on Model

28

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $19.99

View on Model

29

5304523072 Frigidaire Refrigerator Switch In Stock WCI 5304523072 $27.49

View on Model

29

5304530688 Frigidaire Refrigerator Compressor In Stock WCI 5304530688 $240.74

View on Model

29A

5304523829 Frigidaire Refrigerator Grommet Backorder WCI 5304523829 $6.79

View on Model

30

241778702 Frigidaire Refrigerator Anti-Tip Br Backorder WCI 241778702 $12.18

View on Model

30

5304530939 Frigidaire Refrigerator Inverter In Stock WCI 5304530939 $87.70

View on Model

34

241929901 Frigidaire Grommet Condenser Mounti Backorder WCI 241929901 $5.88

View on Model

34A

241929902 Frigidaire Condenser Mounting Gromm Backorder WCI 241929902 $5.88

View on Model

37

5304519618 Frigidaire Refrigerator Cabinet Co In Stock WCI 5304519618 $7.25

View on Model

38

140153004290 Frigidaire User Interface Board, In Stock WCI 140153004290 $96.94

View on Model

41

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

View on Model

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $9.04

View on Model

44

5304456288 Frigidaire Refrigerator Clamp Backorder WCI 5304456288 $4.99

View on Model

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.72

View on Model

45

5303307980 Frigidaire Oven Screw Backorder WCI 5303307980 $9.06

View on Model

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

View on Model

50

5304501271 Frigidaire Shelf Clip In Stock WCI 5304501271 $9.95

View on Model

51

5304507976 Frigidaire Refrigerator Assembly-S In Stock WCI 5304507976 $167.55

View on Model

51A

5304507977 Frigidaire Refrigerator Slide Asse In Stock WCI 5304507977 $167.05

View on Model

54

SUPPORT, HOUSING, MAIN BOARD WCI 807854301 Contact Us For Availability

View on Model

55

SOLENOID, ASSEMBLY In Stock WCI 140137975102 $56.75

View on Model

58

240569202 Frigidaire Refrigerator Screw In Stock WCI 240569202 $1.35

View on Model

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $4.97

View on Model

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $28.97

View on Model

60

5304531260 Frigidaire Refrigerator Motor Backorder WCI 5304531260 $100.13

View on Model

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $13.11

View on Model

62

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.01

View on Model

64

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $12.24

View on Model

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.60

View on Model

81

134154100 Frigidaire Screw 10-32 x 0.375 Co Backorder WCI 134154100 $8.62

View on Model

81

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.26

View on Model

82

240335202 Frigidaire Refrigerator Roller Backorder WCI 240335202 $13.59

View on Model

82

241779401 Frigidaire Refrigerator Flipper Hin In Stock WCI 241779401 $13.13

View on Model

83

241812202 Frigidaire Refrigerator Magnet Backorder WCI 241812202 $45.70

View on Model

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.04

View on Model

84

241830904 Frigidaire Refrigerator Drain Tube In Stock WCI 241830904 $14.94

View on Model

85

242139301 Frigidaire Refrigerator Support Bea Backorder WCI 242139301 $46.62

View on Model

85

5304530251 Frigidaire Tube Assembly Backorder WCI 5304530251 $13.15

View on Model

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $39.88

View on Model

86

242015001 Frigidaire Refrigerator Screw Backorder WCI 242015001 $10.41

View on Model

87

5304507999 Frigidaire Refrigerator Pinion Backorder WCI 5304507999 $6.32

View on Model

88

241979601 Frigidaire Refrigerator Bumper Backorder WCI 241979601 $14.48

View on Model

89

215346903 Frigidaire Process Tube Backorder WCI 215346903 $6.05

View on Model

89

5304509676 Frigidaire Refrigerator Bracket In Stock WCI 5304509676 $45.72

View on Model

90

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.05

View on Model

90

241770705 Frigidaire Bar Backorder WCI 241770705 $30.23

View on Model

91

5304508041 Frigidaire Refrigerator Cover Backorder WCI 5304508041 $7.25

View on Model

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.60

View on Model

94

5303918775 Frigidaire Refrigerator Thermistor In Stock WCI 5303918775 $11.89

View on Model

122

241860117 Frigidaire Gasket Backorder WCI 241860117 $6.82

View on Model

123

5304508007 Frigidaire Refrigerator Bracket Backorder WCI 5304508007 $8.58

View on Model

124

242006903 Frigidaire Refrigerator Air Duct Backorder WCI 242006903 $37.65

View on Model

137

PurePour Frigidaire FPPWFU01 Refrigerator Wat In Stock WCI FPPWFU01 $52.85

View on Model

139A

MANIFOLD In Stock WCI 140156010054 $19.53

View on Model

211

5304508077 Frigidaire Refrigerator Bumper Backorder WCI 5304508077 $7.25

View on Model

212

5304508016 Frigidaire Refrigerator Roller In Stock WCI 5304508016 $3.44

View on Model

213

242010901 Frigidaire Refrigerator Assembly Ro Backorder WCI 242010901 $31.71

View on Model

NI

218515401 Frigidaire Refrigerator Clip Backorder WCI 218515401 $11.32

View on Model

NI

218709101 Frigidaire Refrigerator Handle Moun Backorder WCI 218709101 $4.09

View on Model

NI

241695904 Frigidaire Refrigerator Screw Backorder WCI 241695904 $8.60

View on Model

NI

242146401 Frigidaire Refrigerator Screw In Stock WCI 242146401 $9.12

View on Model

NI

5304527119 Frigidaire Screw Backorder WCI 5304527119 $5.88

View on Model

NI

5304538337 Frigidaire Harness Backorder WCI 5304538337 $19.34

View on Model

NIA

240346721 Frigidaire Tape Backorder WCI 240346721 $5.88

View on Model

NIA

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $8.14

View on Model

NIA

241500305 Frigidaire Refrigerator Screw In Stock WCI 241500305 $1.83

View on Model

NIA

241842301 Frigidaire Refrigerator Thermistor Backorder WCI 241842301 $21.73

View on Model

NIA

242036801 Frigidaire Refrigerator Plastic Cli In Stock WCI 242036801 $60.94

View on Model

NIA

242068601 Frigidaire Refrigerator Bumper Backorder WCI 242068601 $8.60

View on Model

NIA

242200102 Frigidaire Refrigerator Clip Backorder WCI 242200102 $6.79

View on Model

NIB

241953902 Frigidaire Refrigerator Screw In Stock WCI 241953902 $10.93

View on Model

NIB

242039701 Frigidaire Refrigerator Screw Backorder WCI 242039701 $8.60

View on Model

NIB

5304535843 Frigidaire Tube Assembly Backorder WCI 5304535843 $6.40

View on Model

Model Frigidaire PRFG2383AF5 REFRIGERATOR, FRENCH DOOR, BOTTOM FREEZER, W/INTERNAL DISPENSER – Common Parts & Diagrams

Common parts from model Frigidaire PRFG2383AF5 REFRIGERATOR, FRENCH DOOR, BOTTOM FREEZER, W/INTERNAL DISPENSER
