Model GE NS23A48MA451A Room Air Conditioner Built In – Common Parts & Diagrams

130
WIRING DIAGRAM-(CTO)
WIRING DIAGRAM-(CTO) GEN 538265-01G Contact Us For Availability
View on Model
250
ASSY-COIL 2 ROW, 22 FPI, 42" x 93.3"-(CT
ASSY-COIL 2 ROW, 22 FPI, 42" x 93.3"-(CT GEN R624257-01 Contact Us For Availability
View on Model
262
COMP VAR SPD ROTARY GPT442
COMP VAR SPD ROTARY GPT442 GEN 19U49 Contact Us For Availability
View on Model
267
MOTOR-FAN 1/3HP 208/230V 60HZ 1PH PWM
MOTOR-FAN 1/3HP 208/230V 60HZ 1PH PWM GEN R103687-06 Contact Us For Availability
View on Model
269
CONTROL BOARD
CONTROL BOARD GEN 25B73 Contact Us For Availability
View on Model
270
HARN-COMP VARIABLE SPEED ROTARY-(CTO)
HARN-COMP VARIABLE SPEED ROTARY-(CTO) GEN R105382-02 Contact Us For Availability
View on Model
272
GROMMET-COMPRESSOR-(CTO)
GROMMET-COMPRESSOR-(CTO) GEN R100303-01 Contact Us For Availability
View on Model
273
BOLT-SLEEVE COMBINATION-(CTO)
BOLT-SLEEVE COMBINATION-(CTO) GEN R100301-01 Contact Us For Availability
View on Model
278
CONTACTOR-SPST 35FLA/40RES
CONTACTOR-SPST 35FLA/40RES GEN 10F74 Contact Us For Availability
View on Model
285
100499-24 CC HEATER 40W 240V
100499-24 CC HEATER 40W 240V GEN 12U71 Contact Us For Availability
View on Model
286
HARN # FIELD (614076-04 + 614073-05)-(CT
HARN # FIELD (614076-04 + 614073-05)-(CT GEN 19X71 Contact Us For Availability
View on Model
292
100503-13 THERMOSTAT-CC Heater
100503-13 THERMOSTAT-CC Heater GEN 12U74 Contact Us For Availability
View on Model
296
Switch-High Pressure (590PSI)
Switch-High Pressure (590PSI) GEN 55W64 Contact Us For Availability
View on Model
299
SUCTION ACCUMULATOR 3/4"CONN-(CTO)
SUCTION ACCUMULATOR 3/4"CONN-(CTO) GEN 19V42 Contact Us For Availability
View on Model
301
SUCTION FILTER 7/8" DRIER-(CTO)
SUCTION FILTER 7/8" DRIER-(CTO) GEN 19V44 Contact Us For Availability
View on Model
306
Valve Core
Valve Core GEN 95M48 Contact Us For Availability
View on Model
310
ORIFICE RING (26x6 DEEP)
ORIFICE RING (26x6 DEEP) GEN 15Z67 Contact Us For Availability
View on Model
951
MULLION RIGHT-(CTO)
MULLION RIGHT-(CTO) GEN 624538-02E Contact Us For Availability
View on Model
952
PNL ACCESS-(CTO)
PNL ACCESS-(CTO) GEN 624420-02E Contact Us For Availability
View on Model
953
BRKT SVC VLV(ARM GRAY)-(CTO)
BRKT SVC VLV(ARM GRAY)-(CTO) GEN 622069-01E Contact Us For Availability
View on Model
960
PNL CONTROL COVER-(CTO)
PNL CONTROL COVER-(CTO) GEN R613292-01E Contact Us For Availability
View on Model
970
POST - CORNER-(CTO)
POST - CORNER-(CTO) GEN 602300-01E Contact Us For Availability
View on Model
977
BRKT SUPPORT-(CTO)
BRKT SUPPORT-(CTO) GEN 624447-02 Contact Us For Availability
View on Model
978
COVER SOUND -ROTARY COMP-(CTO)
COVER SOUND -ROTARY COMP-(CTO) GEN 24C78 Contact Us For Availability
View on Model
988
GUARD-FAN WIRE BLK DIA-(CTO)
GUARD-FAN WIRE BLK DIA-(CTO) GEN R100305-09 Contact Us For Availability
View on Model
990
MULLION LEFT-(CTO)
MULLION LEFT-(CTO) GEN 624537-02E Contact Us For Availability
View on Model
991
PNL LUVR -CURVED RT/LF-(CTO)
PNL LUVR -CURVED RT/LF-(CTO) GEN 623481-17E Contact Us For Availability
View on Model
992
PNL LUVR -CURVED RT/LF-(CTO)
PNL LUVR -CURVED RT/LF-(CTO) GEN 623481-18E Contact Us For Availability
View on Model
997
ASSY PNL TOP (DRAWN)-(CTO)
ASSY PNL TOP (DRAWN)-(CTO) GEN 614257-04G Contact Us For Availability
View on Model
1001
TRANSDUCER SUCTION PRESSURE (EEV)
TRANSDUCER SUCTION PRESSURE (EEV) GEN R104123-05 Contact Us For Availability
View on Model
1005
105583-01 REACTOR FOR 6KW INVERTER GEN2
105583-01 REACTOR FOR 6KW INVERTER GEN2 GEN 17G87 Contact Us For Availability
View on Model
1006
106202-02 SENSOR TEMPERATURE 7/8
106202-02 SENSOR TEMPERATURE 7/8 GEN 19V56 Contact Us For Availability
View on Model
1007
VALVE-CHECK 1/2"
VALVE-CHECK 1/2" GEN 19V45 Contact Us For Availability
View on Model
9999
PM INSTALL INSTRUCTIONS
PM INSTALL INSTRUCTIONS GEN 31-5000754 Contact Us For Availability
View on Model
9999
PM OTHER
PM OTHER GEN 31-5000644 Contact Us For Availability
View on Model
