Model GE NS18H60HA5AA1 Room Air Conditioner Built In – Common Parts & Diagrams

1
FRONT PANEL
FRONT PANEL GEN WJ71X34849 Contact Us For Availability
View on Model
2
OUTLET GRILL
OUTLET GRILL GEN WJ71X35603 Contact Us For Availability
View on Model
3
FRONT SERVICE PANEL
FRONT SERVICE PANEL GEN WJ71X34847 Contact Us For Availability
View on Model
4
SMALL-FRONT SERVICE PANEL
SMALL-FRONT SERVICE PANEL GEN WJ71X34850 Contact Us For Availability
View on Model
5
RIGHT SERVICE PANEL
RIGHT SERVICE PANEL GEN WJ71X34845 Contact Us For Availability
View on Model
6
SMALL-RIGHT SERVICE PANEL
SMALL-RIGHT SERVICE PANEL GEN WJ71X34848 Contact Us For Availability
View on Model
7
VALVE SEAT GROUP
VALVE SEAT GROUP GEN WJ53X35596 Contact Us For Availability
View on Model
8
BOTTOM PLATE ASSEMBLY
BOTTOM PLATE ASSEMBLY GEN WJ71X35655 Contact Us For Availability
View on Model
9
HEATER
HEATER GEN WJ27X34675 Contact Us For Availability
View on Model
10
PARTION PLATE
PARTION PLATE GEN WJ71X35661 Contact Us For Availability
View on Model
13
COMPRESSOR DC
COMPRESSOR DC GEN WJ98X34843 Contact Us For Availability
View on Model
16
VAPOR SERVICE VALVE
VAPOR SERVICE VALVE GEN WJ58X32302 Contact Us For Availability
View on Model
19
EXPANSION VALVE
EXPANSION VALVE GEN WJ53X34842 Contact Us For Availability
View on Model
21
4-WAY VALVE
4-WAY VALVE GEN WJ53X34654 Contact Us For Availability
View on Model
22
SENSOR CLIP
SENSOR CLIP GEN WJ26X24079 Contact Us For Availability
View on Model
23
TOP COVER
TOP COVER GEN WJ76X34846 Contact Us For Availability
View on Model
24
BEAM
BEAM GEN WJ71X35537 Contact Us For Availability
View on Model
25
STAND COLUMN
STAND COLUMN GEN WJ65X34851 Contact Us For Availability
View on Model
26
FAN BLADE
FAN BLADE GEN WJ73X34836 Contact Us For Availability
View on Model
27
FAN MOTOR DC
FAN MOTOR DC GEN WJ94X34643 Contact Us For Availability
View on Model
28
MOTOR BRACKET
MOTOR BRACKET GEN WJ65X35600 Contact Us For Availability
View on Model
30
ELECTRIC CONTROL BOX-1
ELECTRIC CONTROL BOX-1 GEN WJ76X34854 Contact Us For Availability
View on Model
31
SERVICE POWER CONTROL BOARD
SERVICE POWER CONTROL BOARD GEN WJ26X29336 Contact Us For Availability
View on Model
33
TERMINAL BLOCK
TERMINAL BLOCK GEN WJ35X34645 Contact Us For Availability
View on Model
34
TERMINAL BLOCK
TERMINAL BLOCK GEN WJ35X34633 Contact Us For Availability
View on Model
35
TERMINAL STRIP SHEET METAL
TERMINAL STRIP SHEET METAL GEN WJ76X35619 Contact Us For Availability
View on Model
38
POWER MODULE
POWER MODULE GEN WJ26X34840 Contact Us For Availability
View on Model
39
MODULE BOARD
MODULE BOARD GEN WJ26X34839 Contact Us For Availability
View on Model
40
WIRE HARNESS
WIRE HARNESS GEN WJ35X34841 Contact Us For Availability
View on Model
41
WIRE HARNESS
WIRE HARNESS GEN WJ35X34838 Contact Us For Availability
View on Model
42
ELECTRIC CONTROL BOX 2
ELECTRIC CONTROL BOX 2 GEN WJ76X34855 Contact Us For Availability
View on Model
43
ELECTRICAL CONTROL BOX 3
ELECTRICAL CONTROL BOX 3 GEN WJ76X34856 Contact Us For Availability
View on Model
44
ELECTRICAL CONTROL BOX 4
ELECTRICAL CONTROL BOX 4 GEN WJ76X34857 Contact Us For Availability
View on Model
45
WIRING HARNESS (Y1 R DEFR)
WIRING HARNESS (Y1 R DEFR) GEN WJ35X36434 Contact Us For Availability
View on Model
9999
PRINTED AND ONLINE INSTALL INSTRUCTIONS
PRINTED AND ONLINE INSTALL INSTRUCTIONS GEN 31-5001053 Contact Us For Availability
View on Model
9999
ONLINE ONLYPRODUCT SPECIFICATION
ONLINE ONLYPRODUCT SPECIFICATION GEN 31-5001098 Contact Us For Availability
View on Model
