Model Whirlpool MT2070XAB0 – Common Parts & Diagrams

1
Microcomputer
Microcomputer WPL 4375145 Contact Us For Availability
View on Model
1
Door, Complete
Door, Complete WPL 4375128 Contact Us For Availability
View on Model
1
Power Cord
Power Cord WPL 4375082 Contact Us For Availability
View on Model
2
Control Panel
Control Panel WPL 4375144 Contact Us For Availability
View on Model
2
Choke Cover
Choke Cover WPL 4375105 Contact Us For Availability
View on Model
3
Touch Pad
Touch Pad WPL 4375088 Contact Us For Availability
View on Model
3
Hinge, Lower
Hinge, Lower WPL 4375104 Contact Us For Availability
View on Model
3
Transformer
Transformer WPL 4375083 Contact Us For Availability
View on Model
4
Outer Frame
Outer Frame WPL 4375107 Contact Us For Availability
View on Model
4
Capacitor
Capacitor WPL 4375149 Contact Us For Availability
View on Model
5
Tray, Glass
Tray, Glass WPL 4375133 Contact Us For Availability
View on Model
5
Latch Board (Includes Item 6)
Latch Board (Includes Item 6) WPL 4375117 Contact Us For Availability
View on Model
5
Rectifier
Rectifier WPL 4375084 Contact Us For Availability
View on Model
6
Motor, Fan
Motor, Fan WPL 4375075 Contact Us For Availability
View on Model
6
Grille, Plastic
Grille, Plastic WPL 4375136 Contact Us For Availability
View on Model
6
Micro switch (3)
Micro switch (3) WPL 4375139 Contact Us For Availability
View on Model
6
Outer Cabinet
Outer Cabinet WPL 4375130 Contact Us For Availability
View on Model
7
Blade, Fan
Blade, Fan WPL 4375113 Contact Us For Availability
View on Model
7
Support, Turntable
Support, Turntable WPL 4375134 Contact Us For Availability
View on Model
7
Screw
Screw WPL 4375051 Contact Us For Availability
View on Model
7
Clamp
Clamp WPL 4375027 Contact Us For Availability
View on Model
8
Thermostat, Oven
Thermostat, Oven WPL 4375146 Contact Us For Availability
View on Model
8
Motor, Turntable
Motor, Turntable WPL 4375076 Contact Us For Availability
View on Model
8
Door, Inner
Door, Inner WPL 4375152 Contact Us For Availability
View on Model
8
Cover
Cover WPL 4375099 Contact Us For Availability
View on Model
9
Screw, Magnatron
Screw, Magnatron WPL 4375040 Contact Us For Availability
View on Model
9
Foot (4)
Foot (4) WPL 4375029 Contact Us For Availability
View on Model
10
Locking Pin
Locking Pin WPL 4375118 Contact Us For Availability
View on Model
10
Bracket, Capacitor
Bracket, Capacitor WPL 4375097 Contact Us For Availability
View on Model
11
Ring
Ring WPL 4375037 Contact Us For Availability
View on Model
11
Lever
Lever WPL 4375114 Contact Us For Availability
View on Model
11
Lock Washer
Lock Washer WPL 4375039 Contact Us For Availability
View on Model
12
Screw
Screw WPL 4375048 Contact Us For Availability
View on Model
12
Air Duct
Air Duct WPL 4375119 Contact Us For Availability
View on Model
13
Screw, Transformer
Screw, Transformer WPL 4375038 Contact Us For Availability
View on Model
14
Screen, Vent
Screen, Vent WPL 4375115 Contact Us For Availability
View on Model
14
Cover Strip
Cover Strip WPL 4375109 Contact Us For Availability
View on Model
15
Clip, Fan Blade
Clip, Fan Blade WPL 4375043 Contact Us For Availability
View on Model
15
Cover, Capacitor
Cover, Capacitor WPL 4375098 Contact Us For Availability
View on Model
16
Cover
Cover WPL 4375100 Contact Us For Availability
View on Model
18
Screw
Screw WPL 4375042 Contact Us For Availability
View on Model
20
Duct, Magnetron
Duct, Magnetron WPL 4375102 Contact Us For Availability
View on Model
21
Fuse Holder
Fuse Holder WPL 4375047 Contact Us For Availability
View on Model
22
Fuse (Black)
Fuse (Black) WPL 4375073 Contact Us For Availability
View on Model
23
Screw
Screw WPL 4375095 Contact Us For Availability
View on Model
