Model Accelerated Cooking Products MOC6201J-P2000312M Amana Menumaster MOC6201J – Common Parts &amp; Diagrams

1

UP MAG SHROUD ASSY ACP 20017201 Contact Us For Availability

1

REAR MC BRKT-E CT ACP 20011404 Contact Us For Availability

1

WIRE, JUMPER ACP 13017716 Contact Us For Availability

2

13074001 Amana RoHS TORX Pan Head Screw Backorder ACP 13074001 $5.59

2

POWER CORD ACP 20075401 Contact Us For Availability

2

BOARD, MAIN CONTROL ACP 59124190 Contact Us For Availability

2

HARNESS, HV ACP 20019401 Contact Us For Availability

3

10091101 Amana Fuse Holder Backorder ACP 10091101 $7.34

3

20031701 Amana Fuse 2.5A Backorder ACP 20031701 $5.14

3

59184614 Amana Antenna Shield Backorder ACP 59184614 $51.50

3

HARNESS, MAIN ACP 20216701 Contact Us For Availability

4

14149088 Amana Fan Motor Kit In Stock ACP 14149088 $264.92

4

14179117 Amana Ceramic Tray Supports Kit Backorder ACP 14179117 $106.51

4

59004102 Amana Outer Panel Left Hand Backorder ACP 59004102 $88.75

4

B5677203 Amana Terminal Block Backorder ACP B5677203 $5.14

4

STRAP-OVEN ACP 21009501 Contact Us For Availability

5

20013701 Amana Fan Guard Backorder ACP 20013701 $10.83

5

59004098 Amana Tray Support Backorder ACP 59004098 $23.88

5

M0805203 Amana Fuse 20A Backorder ACP M0805203 $5.14

6

OUTER PANEL- TOP ACP 59004104 Contact Us For Availability

6

BRKT-40 PIN HEADER ACP 20023501 Contact Us For Availability

7

12546101 Amana Washer Backorder ACP 12546101 $5.66

7

SCREW-TC/PAN ACP 13041802 Contact Us For Availability

7

SUPPORT-PCB ACP M0590609 Contact Us For Availability

8

14090026 Amana Left Hand Hinge Kit Backorder ACP 14090026 $392.01

8

14090031 Amana Switches and Fuse Kit Backorder ACP 14090031 $203.17

8

OUTER PANEL- RH ACP 59004103 Contact Us For Availability

9

20020601 Amana Hinge Spring Backorder ACP 20020601 $5.85

9

STRIP, ANTI INTRUSION ACP 20013601 Contact Us For Availability

9

SCREW TF/HEX RoHS ACP 12992306 Contact Us For Availability

14090027 Amana Kit, Hinge - Right Hand Backorder ACP 14090027 $392.01

14189146 Amana OC Antenna and Motor In Stock ACP 14189146 $90.40

SCREW-TC/FLAT ACP 13047404 Contact Us For Availability

SCREW-SM/PAN ACP 12990608 Contact Us For Availability

11

PANEL-MENU ACP 10432501 Contact Us For Availability

11

REAR MC BRKT-E CT ACP 20011402 Contact Us For Availability

12

21021202 Amana Control Escutcheon Backorder ACP 21021202 $33.99

13

59194708 Amana Gasket MAG Backorder ACP 59194708 $7.95

13

TOUCH PANEL ASSY ACP 59124192 Contact Us For Availability

14

14090028 Amana Kit, Harness - PC Board to Tou Backorder ACP 14090028 $93.08

14

59001893 Amana Line Filter Backorder ACP 59001893 $79.92

14

59004085 Amana Display Board Backorder ACP 59004085 $181.69

12991605 Amana Screw TC/HEX ROHS Backorder ACP 12991605 $5.14

20173001 Amana Rotary Igniter Backorder ACP 20173001 $15.81

CLIP, RETAINER ACP 20023301 Contact Us For Availability

NUT ACP 13045502 Contact Us For Availability

16

59004013 Amana Magnetron In Stock ACP 59004013 $101.60

16

LWR OC BACK WELD-E CT ACP 20015502 Contact Us For Availability

17

20241404 Amana Thermal Cutout Switch Backorder ACP 20241404 $8.36

17

59004092 Amana Motor and Gas Cavity Kit Backorder ACP 59004092 $113.67

17

R0000413 Amana Base Pan Gasket 90 Inch In Stock ACP R0000413 $43.09

18

GRILLE-EXH FAN ACP 20009701 Contact Us For Availability

18

THERMAL CUTOUT - LATCH TCO ACP B5684135 Contact Us For Availability

19

HOOD-CAVITY FAN ACP 21020302 Contact Us For Availability

19

SCREW-TC ACP 20095801 Contact Us For Availability

20

59004115 Amana Cavity Thermal Cutout Assembly Backorder ACP 59004115 $17.63

20

59174533 Amana Capacitor and Diode Kit, 0.65 In Stock ACP 59174533 $43.51

21

14179138 Amana Kit - Studs and Hardware Backorder ACP 14179138 $24.68

21

BRKT- CAPACITOR ACP 13069001 Contact Us For Availability

21

SCREW-TF/HEX RoHS ACP 12992304 Contact Us For Availability

22

NUT-#8 HEX ACP 20018901 Contact Us For Availability

22

TRANSFORMER, HV ACP 59124191 Contact Us For Availability

23

20057401 Amana Diode In Stock ACP 20057401 $7.48

24

59174520 Amana TRIAC (40A) & Snubber Kit In Stock ACP 59174520 $57.41

24

SCREW-SM/FLAT ACP 20021703 Contact Us For Availability

25

12990522 Amana Screw SM/HEX RoHS Backorder ACP 12990522 $5.14

25

GASKET-CAV FAN ACP 20095601 Contact Us For Availability

26

59004119 Amana Control Transformer Backorder ACP 59004119 $80.48

27

13045501 Amana Nut #6 KEPS Backorder ACP 13045501 $5.08
