Model Whirlpool MHE14XKB1 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

1

Literature Parts (Tech Sheet) WPL LIT8183894 Contact Us For Availability

1

Literature Parts (Guide, U & C) WPL LIT8183914 Contact Us For Availability

1

Literature Parts (Guide, Cooking) WPL LIT8183915 Contact Us For Availability

1

Literature Parts (Instructions, Installation) WPL LIT8183991 Contact Us For Availability

1

Exhaust Adapter WPL 4158541 Contact Us For Availability

1

Outer Case (Black) WPL 8184034 Contact Us For Availability

1

Outer Case (White) WPL 8184035 Contact Us For Availability

1

Door Assembly (Black) WPL 8184328 Contact Us For Availability

1

Door Assembly (White) WPL 8184332 Contact Us For Availability

2

Control Panel (Black) WPL 8184330 Contact Us For Availability

2

Control Panel (White) WPL 8184334 Contact Us For Availability

2

Exhaust Damper WPL 4158319 Contact Us For Availability

2

H.V. Transformer WPL 8184046 Contact Us For Availability

2

Air Duct WPL 8184045 Contact Us For Availability

2

Mounting Bracket WPL 4358928 Contact Us For Availability

2

Frame, Door WPL 8172111 Contact Us For Availability

3

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $2.85

3

WPW10146437 Whirlpool Peel and Stick Door Fil In Stock WPL WPW10146437 $26.92

3

Bracket, Control WPL 8184653 Contact Us For Availability

3

Bracket, H.V. WPL 4359497 Contact Us For Availability

3

Cavity Assy Not Serviceable WPL ARI118350A Contact Us For Availability

4

Lead Wire Assy WPL 8184042 Contact Us For Availability

4

Key Membrane (Black) WPL 8184387 Contact Us For Availability

4

Key Membrane (White) WPL 8184388 Contact Us For Availability

4

Toggle Wing WPL 4158326 Contact Us For Availability

4

Capacitor, H.V. WPL 8183536 Contact Us For Availability

4

Grille Vent (White) WPL 8184335 Contact Us For Availability

4

Grille Vent (Black) WPL 8184943 Contact Us For Availability

4

Latch WPL 8171850 Contact Us For Availability

5

Microcomputer WPL 8184654 Contact Us For Availability

5

Screw WPL 4158323 Contact Us For Availability

5

Spring, Latch WPL 8184016 Contact Us For Availability

6

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

6

Screw WPL 4158315 Contact Us For Availability

6

Motor, Turntable WPL 4359155 Contact Us For Availability

6

Panel, Door (Black) WPL 8184329 Contact Us For Availability

6

Panel, Door (White) WPL 8184333 Contact Us For Availability

7

Washer WPL 4158314 Contact Us For Availability

7

Plate WPL 8184043 Contact Us For Availability

7

Thermostat WPL 8184049 Contact Us For Availability

7

Glass, Door WPL 8184746 Contact Us For Availability

8

4358853 Whirlpool Grease Filter In Stock WPL 4358853 $7.48

8

Plate, Mounting Wing WPL 8184050 Contact Us For Availability

8

Handle, Door (Black) WPL 8184389 Contact Us For Availability

8

Handle, Door (White) WPL 8184390 Contact Us For Availability

9

8534021 Whirlpool Clamp Backorder WPL 8534021 $5.65

9

WP8205489 Whirlpool Microwave Voltage Wire Backorder WPL WP8205489 $26.88

9

Cover WPL 4359964 Contact Us For Availability

9

Plate, Mount WPL 8184655 Contact Us For Availability

9

Choke, Cover WPL 8171846 Contact Us For Availability

10

Lamp Holder WPL 4359518 Contact Us For Availability

10

Screw WPL 4358883 Contact Us For Availability

10

Bushing WPL 4358012 Contact Us For Availability

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $2.76

Screw (Black) WPL 4358381 Contact Us For Availability

Sheet-Top Cabinet Template WPL 8183896 Contact Us For Availability

Plate WPL 8184044 Contact Us For Availability

Screw (White) WPL 4359009 Contact Us For Availability

12

Sheet-Wall Template WPL 4359011 Contact Us For Availability

12

Shield, Protector WPL 8184039 Contact Us For Availability

12

Motor, Ventilation WPL 8184041 Contact Us For Availability

13

Screw (Black) WPL 4358762 Contact Us For Availability

13

Lead, Wire WPL 8184048 Contact Us For Availability

14

WP8183507 Whirlpool Microwave Fuse In Stock WPL WP8183507 $8.20

14

Canopy WPL 8184033 Contact Us For Availability

15

WP98008545 Whirlpool Screw Backorder WPL WP98008545 $2.64

15

Fuse Cap WPL 4358659 Contact Us For Availability

16

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

16

Pin, Locking WPL 4358933 Contact Us For Availability

16

Power Cord WPL 8184047 Contact Us For Availability

17

Rotating Ring WPL 4359509 Contact Us For Availability

18

Turntable Shaft WPL 8171863 Contact Us For Availability

19

WP8172138 Whirlpool Microwave Cook Tray In Stock WPL WP8172138 $40.22

20

W10864204 Whirlpool Microwave Filter Backorder WPL W10864204 $17.79

23

Screw WPL 4358188 Contact Us For Availability

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $9.61

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

Installation Hardware WPL 4358404 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI118351A Contact Us For Availability

SEALER WPL ARI118352A Contact Us For Availability
