Model Whirlpool MHE13XHB1 MICROWAVE – Common Parts & Diagrams

1
Base Plate (White)
Base Plate (White) WPL 4359525 Contact Us For Availability
View on Model
1
Base Plate (Black)
Base Plate (Black) WPL 4359526 Contact Us For Availability
View on Model
1
Magnetron
Magnetron WPL 4359687 Contact Us For Availability
View on Model
1
Door Assembly (White)
Door Assembly (White) WPL 4359957 Contact Us For Availability
View on Model
1
Door Assembly (Black)
Door Assembly (Black) WPL 4359982 Contact Us For Availability
View on Model
1
Literature Parts (Instructions, Installation)
Literature Parts (Instructions, Installation) WPL LIT4359455 Contact Us For Availability
View on Model
1
Literature Parts (Tech Sheet)
Literature Parts (Tech Sheet) WPL LIT4359670 Contact Us For Availability
View on Model
1
Literature Parts (Guide, U&C)
Literature Parts (Guide, U&C) WPL LIT4359930 Contact Us For Availability
View on Model
1
Literature Parts (Guide, Cooking)
Literature Parts (Guide, Cooking) WPL LIT4359931 Contact Us For Availability
View on Model
1
Outer Case (White Model)
Outer Case (White Model) WPL 4359487 Contact Us For Availability
View on Model
1
Outer Case (Black Model)
Outer Case (Black Model) WPL 4359488 Contact Us For Availability
View on Model
1
Motor, Fan
Motor, Fan WPL 4359511 Contact Us For Availability
View on Model
2
Screw (Black)
Screw (Black) WPL 4358829 Contact Us For Availability
View on Model
2
Bracket, Grey
Bracket, Grey WPL 4359527 Contact Us For Availability
View on Model
2
Bracket, Black
Bracket, Black WPL 4359532 Contact Us For Availability
View on Model
2
H.V. Transformer
H.V. Transformer WPL 4359494 Contact Us For Availability
View on Model
2
Screw
Screw WPL 4358188 Contact Us For Availability
View on Model
2
Frame, Door
Frame, Door WPL 4359979 Contact Us For Availability
View on Model
2
Control Panel (White Model)
Control Panel (White Model) WPL 4359479 Contact Us For Availability
View on Model
2
Control Panel (Black Model)
Control Panel (Black Model) WPL 4359480 Contact Us For Availability
View on Model
2
Mounting Bracket
Mounting Bracket WPL 4358928 Contact Us For Availability
View on Model
2
Air Duct
Air Duct WPL 4359513 Contact Us For Availability
View on Model
3
Glass, Cooktop Lamp
Glass, Cooktop Lamp WPL 4359528 Contact Us For Availability
View on Model
3
Bracket, H.V.
Bracket, H.V. WPL 4359497 Contact Us For Availability
View on Model
3
Bracket, Control
Bracket, Control WPL 4359481 Contact Us For Availability
View on Model
3
Cavity Assembly (Not Serviceable)
Cavity Assembly (Not Serviceable) WPL ARI118344A Contact Us For Availability
View on Model
4
Lead Wire Assy
Lead Wire Assy WPL 4359529 Contact Us For Availability
View on Model
4
Capacitor, H.V.
Capacitor, H.V. WPL 4359049 Contact Us For Availability
View on Model
4
Latch
Latch WPL 4359860 Contact Us For Availability
View on Model
4
Key Membrane (Black)
Key Membrane (Black) WPL 4359988 Contact Us For Availability
View on Model
4
Key Membrane (White)
Key Membrane (White) WPL 4359989 Contact Us For Availability
View on Model
4
Grille Vent (White Model)
Grille Vent (White Model) WPL 4359489 Contact Us For Availability
View on Model
4
Grille Vent (Black Model)
Grille Vent (Black Model) WPL 4359490 Contact Us For Availability
View on Model
5
Screw
Screw WPL 4358271 Contact Us For Availability
View on Model
5
Base Thermostat
Base Thermostat WPL 4158368 Contact Us For Availability
View on Model
5
Screw
Screw WPL 4358381 Contact Us For Availability
View on Model
5
Bracket
Bracket WPL 4359530 Contact Us For Availability
View on Model
5
Screw
Screw WPL 4358376 Contact Us For Availability
View on Model
5
Spring, Latch
Spring, Latch WPL 4358607 Contact Us For Availability
View on Model
5
Screw
Screw WPL 4358883 Contact Us For Availability
View on Model
5
PCB Sub Assy.
PCB Sub Assy. WPL 4359661 Contact Us For Availability
View on Model
5
Bracket, Front
Bracket, Front WPL 4358759 Contact Us For Availability
View on Model
5
Fuse
Fuse WPL 4359514 Contact Us For Availability
View on Model
6
Motor, Turntable
Motor, Turntable WPL 4359932 Contact Us For Availability
View on Model
6
Panel, Door (White)
Panel, Door (White) WPL 4359469 Contact Us For Availability
View on Model
6
Panel, Door (Black)
Panel, Door (Black) WPL 4359470 Contact Us For Availability
View on Model
6
Bracket, Grille
Bracket, Grille WPL 4358816 Contact Us For Availability
View on Model
7
Plate
Plate WPL 4359500 Contact Us For Availability
View on Model
7
Glass, Door (Black)
Glass, Door (Black) WPL 4359983 Contact Us For Availability
View on Model
7
Glass, Door (White)
Glass, Door (White) WPL 4359984 Contact Us For Availability
View on Model
7
Cover, Power Cord
Cover, Power Cord WPL 4359616 Contact Us For Availability
View on Model
8
Plate, Mounting Wing
Plate, Mounting Wing WPL 4358924 Contact Us For Availability
View on Model
8
H.V. Cable
H.V. Cable WPL 4359501 Contact Us For Availability
View on Model
8
Handle, Door (Screw)
Handle, Door (Screw) WPL 4358479 Contact Us For Availability
View on Model
8
Handle, Door (White Model)
Handle, Door (White Model) WPL 4359473 Contact Us For Availability
View on Model
8
Handle, Door (Black Model)
Handle, Door (Black Model) WPL 4359474 Contact Us For Availability
View on Model
8
Wire Holder
Wire Holder WPL 4158267 Contact Us For Availability
View on Model
9
Choke, Cover
Choke, Cover WPL 4359476 Contact Us For Availability
View on Model
9
Screw
Screw WPL 4358762 Contact Us For Availability
View on Model
9
Plate, Mount
Plate, Mount WPL 4359377 Contact Us For Availability
View on Model
9
Cover
Cover WPL 4359517 Contact Us For Availability
View on Model
10
Bushing
Bushing WPL 4358012 Contact Us For Availability
View on Model
10
Lamp Holder
Lamp Holder WPL 4359518 Contact Us For Availability
View on Model
10
Lead Wire
Lead Wire WPL 4359503 Contact Us For Availability
View on Model
11
Sheet-Top Cabinet Template
Sheet-Top Cabinet Template WPL 4359560 Contact Us For Availability
View on Model
11
Guide
Guide WPL 4359504 Contact Us For Availability
View on Model
12
Sheet-Wall Template
Sheet-Wall Template WPL 4359011 Contact Us For Availability
View on Model
12
Cover
Cover WPL 4359688 Contact Us For Availability
View on Model
12
Motor, Ventilation
Motor, Ventilation WPL 4359990 Contact Us For Availability
View on Model
13
Lead, Wire
Lead, Wire WPL 4359690 Contact Us For Availability
View on Model
15
Tape
Tape WPL 4359212 Contact Us For Availability
View on Model
15
Fuse Cap
Fuse Cap WPL 4358659 Contact Us For Availability
View on Model
16
Pin, Locking
Pin, Locking WPL 4358933 Contact Us For Availability
View on Model
16
Power Cord
Power Cord WPL 4359522 Contact Us For Availability
View on Model
17
Filter, Charcoal
Filter, Charcoal WPL 4359331 Contact Us For Availability
View on Model
17
Rotating Ring
Rotating Ring WPL 4359509 Contact Us For Availability
View on Model
17
Installation Hardware
Installation Hardware WPL 4158491 Contact Us For Availability
View on Model
18
Turntable Shaft
Turntable Shaft WPL 4359618 Contact Us For Availability
View on Model
20
Plate
Plate WPL 4359510 Contact Us For Availability
View on Model
