Model Whirlpool MH3184XPQ4 MICROWAVE OVEN 1.8 CU. FT. – Common Parts &amp; Diagrams

1

Reflector, Lamp WPL 8205096 Contact Us For Availability

1

Deflector, Air WPL 8205350 Contact Us For Availability

1

Motor, Stirrer WPL 8205044 Contact Us For Availability

2

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $2.91

2

Cover, Lamp WPL 8206453 Contact Us For Availability

2

Stirrer Shaft/Blade WPL 8205202 Contact Us For Availability

3

Duct, Air WPL 8205368 Contact Us For Availability

4

W10113040A Whirlpool Grease Filter Aluminum In Stock WPL W10113040A $14.68

4

Thermostat/Bracket WPL 8206454 Contact Us For Availability

5

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $55.48

5

Plate, Bottom WPL 8205366 Contact Us For Availability

5

Thermostat WPL 8183703 Contact Us For Availability

5

Cover, Inlet Includes Nails and Bushings WPL 8184476 Contact Us For Availability

6

W10708076 Whirlpool Microwave Power Cord In Stock WPL W10708076 $8.66

6

Hook, Rack (4) WPL 8204662 Contact Us For Availability

6

Pivot, Door WPL 8184922 Contact Us For Availability

6

Glass, Lamp WPL 8184141 Contact Us For Availability

7

Holder, Glass WPL 8184889 Contact Us For Availability

7

Case, Outer (White) WPL 8205347 Contact Us For Availability

7

Case, Outer (Black) WPL 8205348 Contact Us For Availability

7

Case, Outer (Biscuit) WPL 8205349 Contact Us For Availability

7

Nails/Bushings (4 of each) WPL 8184549 Contact Us For Availability

8

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $28.44

8

W10450172 Whirlpool Microwave Grille Vent Backorder WPL W10450172 $46.45

8

W10450187 Whirlpool Microwave Oven Vent Grill In Stock WPL W10450187 $47.71

8

Grille, Vent (Biscuit) WPL 8205216 Contact Us For Availability

8

Air Guide, Back WPL 8205354 Contact Us For Availability

8

Turntable WPL 8206226 Contact Us For Availability

9

W10615742 Whirlpool Microwave Clip In Stock WPL W10615742 $3.24

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $20.42

9

Motor, Fan Assy WPL 8206175 Contact Us For Availability

10

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $2.73

10

W10211974 Whirlpool Microwave Door Interlock In Stock WPL W10211974 $24.34

10

Shield WPL 8205355 Contact Us For Availability

W10435116 Whirlpool Microwave Turntable Rolle In Stock WPL W10435116 $12.02

Screw WPL 8169475 Contact Us For Availability

Spring, Interlock WPL 8169438 Contact Us For Availability

SHIELD WPL 8206460 Contact Us For Availability

8205146A Whirlpool Microwave Oven Range Vent In Stock WPL 8205146A $8.00

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $55.87

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

Plate, Cam WPL 8205211 Contact Us For Availability

13

Support, Interlock WPL 8185189 Contact Us For Availability

13

Cover, Terminal WPL W10110598 Contact Us For Availability

14

W10222507 Whirlpool Microwave Magnetron Backorder WPL W10222507 $150.53

14

Fan, DC 12 Volt WPL 8205362 Contact Us For Availability

15

Screw WPL 8169474 Contact Us For Availability

15

Housing, Fan WPL 8205364 Contact Us For Availability

15

Thermostat WPL 8184951 Contact Us For Availability

16

Air Guide (Right) WPL 8205352 Contact Us For Availability

16

Air Guide (Left) WPL 8205367 Contact Us For Availability

16

Rack WPL 8205549 Contact Us For Availability

17

Humidity, Sensor WPL 8206446 Contact Us For Availability

17

Diffuser, Housing WPL 8205357 Contact Us For Availability

18

Filter WPL 8206624 Contact Us For Availability

18

Cover, Fan Mtr WPL 8206452 Contact Us For Availability

18

Screw WPL 4393838 Contact Us For Availability

19

Rod-Locking Link WPL 8185190 Contact Us For Availability

20

Base Plate, Air Guide WPL 8205351 Contact Us For Availability

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $9.59

22

Plate, Side WPL 8206455 Contact Us For Availability

24

W10269458 Whirlpool Microwave Door Switch In Stock WPL W10269458 $15.87

24

Socket, Motor Wire WPL 8185097 Contact Us For Availability

25

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $26.90

25

Cover, Terminal WPL 8184202 Contact Us For Availability

26

Motor, Capacitor WPL 8184091 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $19.18

30

SCREW WPL 8184199 Contact Us For Availability

32

SCREW WPL 8184200 Contact Us For Availability

34

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $2.51

36

Holder, Lamp WPL 8169539 Contact Us For Availability

38

Transformer, H.V. WPL 8206456 Contact Us For Availability

39

Bracket, Capacitor WPL 8206457 Contact Us For Availability

40

Capacitor, H.V. WPL 8206458 Contact Us For Availability

41

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $10.01

42

Chassis WPL 8206567 Contact Us For Availability

8205948 Whirlpool Microwave Mount In Stock WPL 8205948 $7.89

W10539840 Whirlpool Microwave Wire Harness Backorder WPL W10539840 $9.20

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $3.00

Template, Upper WPL 8184731 Contact Us For Availability

H.V. Wire Assy WPL 8205693 Contact Us For Availability

Main Harness WPL 8205695 Contact Us For Availability

Wire-Grnd Cvty Lck WPL W10111829 Contact Us For Availability

Wire-Grnd Hum Snsr WPL W10111830 Contact Us For Availability

Wire-Grnd AC Fltr WPL W10111831 Contact Us For Availability

Wire-Grnd Intrlck WPL W10111832 Contact Us For Availability

Wire-Grnd, Fuse WPL W10111833 Contact Us For Availability

Hood Lamp/TT Mtr WPL W10113916 Contact Us For Availability
