Model LG MA-781M MICROWAVE OVEN,SMALL – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Diagram 7
Common parts from model LG MA-781M MICROWAVE OVEN,SMALL
![MANUAL,[OWNERS]MWO](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
MANUAL,[OWNERS]MWO LGE 3828W5A1886 Contact Us For Availability
*04
MANUAL,[INSTALLATION] LGE 3828W5U0040 Contact Us For Availability
*05
LABEL,COOKING GUIDE LGE 3850W1D014A Contact Us For Availability
*06
TEMPLATE LGE 4922W5A001A Contact Us For Availability
50CZZH
CAPACITOR,[HIGH VOLTAGE] LGE 0CZZW1H001P Contact Us For Availability
54810C
BRACKET,CAPACITOR LGE 4810W1A253A Contact Us For Availability
54974S
GUIDE,[SUCTION] LGE 4974W1S056A Contact Us For Availability
55262A
AIR DUCT LGE 5262W2A044A Contact Us For Availability
56201A
FILTER ASSEMBLY(CIRC) LGE 6201W1A014C Contact Us For Availability
56324A
MAGNETRON LGE 3B71077E Contact Us For Availability
56411A
POWER CORD ASSEMBLY LGE 6411W1A036N Contact Us For Availability
56549F
MOTOR(CIRC),FAN LGE 6549W1F005P Contact Us For Availability
63302A
BASE PLATE LGE 3302W0A019B Contact Us For Availability
63303A
BASE PLATE ASSY LGE 3303W1A044B Contact Us For Availability
568771
HARNESS LGE 6877W1A227S Contact Us For Availability
BZ1
BUZZER,PIEZO CERAMIC LGE 6908W3YA01B Contact Us For Availability
CU1
CUSHION LGE 4850W4C001G Contact Us For Availability
× ![]()
