Model LG MA-1020W MWO-M – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Diagram 7
Common parts from model LG MA-1020W MWO-M
![MANUAL,[OWNERS]](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
MANUAL,[OWNERS] LGE 3828W5A2177 Contact Us For Availability
*02
LGE 3828W5S1512 LGE 3828W5S1512 Contact Us For Availability
*05
LGE 3850W1D041B LGE 3850W1D041B Contact Us For Availability
*10
LGE 3890W3L005E LGE 3890W3L005E Contact Us For Availability
26638A
KEY MEMBRANE LGE 3506W1A135A Contact Us For Availability
33390G
TRAY,GLASS LGE 3390W1G003G Contact Us For Availability
35889A
ROTATING RING ASSEMBLY LGE 5889W2A014C Contact Us For Availability
54974S
GUIDE,SUCTION LGE 4974W1S048B Contact Us For Availability
55006F
CAP,FUSE LGE 5006WRA002D Contact Us For Availability
56170D
LGE 6170W1D027B LGE 6170W1D027B Contact Us For Availability
56324A
MAGNETRON LGE 2B71732B Contact Us For Availability
56411A
POWER CORD ASSEMBLY LGE 6411W1A031A Contact Us For Availability
56549F
MOTOR(CIRC),FAN LGE 6549W1F005B Contact Us For Availability
63302A
1.0CU.FT SINGLE LGE 3302W0A025A Contact Us For Availability
63303A
BASE PLATE ASSY LGE 3303W0A013B Contact Us For Availability
647781
LEG ALL LGE 4778W3A002A Contact Us For Availability
948503
LGE 4850W1A001A LGE 4850W1A001A Contact Us For Availability
BZ1
BUZZER,PIEZO CERAMIC LGE 6908W3YA01B Contact Us For Availability
× ![]()
