Model LG LUU369HV.EWGBEUS – Common Parts & Diagrams
DIAGRAM 1
Common parts from model LG LUU369HV.EWGBEUS
16500HP
Sensor,Pressure LGE EBD60663821 Contact Us For Availability
135500
Cover LGE MCK39626227 Contact Us For Availability
137223
Panel Assembly,Side LGE AGL34579165 Contact Us For Availability
237202
Panel,Front LGE MGC39426120 Contact Us For Availability
237205
Panel,Rear LGE MGC39613745 Contact Us For Availability
237213
Panel,Side LGE MGC39426024 Contact Us For Availability
249950
Case Assembly,Control Box LGE ABQ75744253 Contact Us For Availability
352111
Tube Assembly,Connector LGE 5211A20349Z Contact Us For Availability
430410
Base Assembly,Outdoor LGE AAN74512209 Contact Us For Availability
435512
Cover Assembly,Top(Outdoor) LGE ACQ35131832 Contact Us For Availability
437211
Panel Assembly,Front(Outdoor) LGE AGL34578727 Contact Us For Availability
437212
Panel Assembly,Rear(Outdoor) LGE AGL76512821 Contact Us For Availability
447910
Barrier Assembly,Outdoor LGE AAM35646423 Contact Us For Availability
546810B
Motor Assembly,DC,Outdoor LGE EAU62543704 Contact Us For Availability
548490
Accumulator Assembly LGE AAB35754002 Contact Us For Availability
549610
Bracket Assembly,Motor(Outdoor) LGE ABA34168813 Contact Us For Availability
552111
Tube Assembly,Capillary LGE AJR75062901 Contact Us For Availability
552115
Tube Assembly,Manifold(Outdoor) LGE AJR76562808 Contact Us For Availability
552116
Tube Assembly,Reverse LGE AJR75983010 Contact Us For Availability
552203B
Valve,Service LGE MJX62472202 Contact Us For Availability
554031
Condenser Assembly,Bending LGE ACG73706311 Contact Us For Availability
561410
Coil Assembly,Reverse LGE EAP64467707 Contact Us For Availability
661400
Coil Module,Expansion LGE EAP65270708 Contact Us For Availability
W4986A
Sound proof LGE MMC00120708 Contact Us For Availability
W4986B
Sound proof LGE MMC00120707 Contact Us For Availability
W6640
Connector,Terminal Block LGE 3A00493P Contact Us For Availability
× ![]()
