Model LG LGDVB418 – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Common parts from model LG LGDVB418
001
PLATE LGE 3300R-0547A Contact Us For Availability
002
MAGNET LGE 5016H-1016B Contact Us For Availability
003
CLAMP LGE 4860R-0021A Contact Us For Availability
010
CABLE,FLAT LGE 6850R-JW24Y Contact Us For Availability
012
RUBBER LGE 5040R-0083B Contact Us For Availability
012A
RUBBER LGE 5040R-0083A Contact Us For Availability
012B
RUBBER LGE 5040R-0110B Contact Us For Availability
012C
RUBBER LGE 5040R-0110A Contact Us For Availability
013
BELT LGE 4400R-0006B Contact Us For Availability
014
GEAR LGE 4470R-0154A Contact Us For Availability
015
MOTOR ASSEMBLY LGE 4681R-A009A Contact Us For Availability
015A
Motor,Unclassified LGE 4680R-E007A Contact Us For Availability
015A
MOTOR(MECH) LGE 4680R-E008A Contact Us For Availability
015B
Pulley LGE 4560R-0008A Contact Us For Availability
016
PWB(PCB) ASSEMBLY,TO LGE 6871R-9288A Contact Us For Availability
017
GEAR LGE 4470R-0153A Contact Us For Availability
018
GUIDE LGE 4974R-0055A Contact Us For Availability
019
FRAME LGE 3210R-M006A Contact Us For Availability
020
BASE LGE 3040R-M061A Contact Us For Availability
024
GEAR LGE 4470R-0151A Contact Us For Availability
024A
GEAR LGE 4470R-0149A Contact Us For Availability
025
GEAR LGE 4470R-0150A Contact Us For Availability
026
TRAY LGE 3390R-0023A Contact Us For Availability
030
GEAR LGE 4470R-0152A Contact Us For Availability
035
PWB(PCB) ASSEMBLY,TO LGE 6871R-9283A Contact Us For Availability
035A
CABLE,FLAT LGE 6850R-GF10Z Contact Us For Availability
036
SHAFT LGE 4370H-1024C Contact Us For Availability
250
CASE LGE 3110R-D013B Contact Us For Availability
260
CHASSIS LGE 3140R-D002A Contact Us For Availability
261
RUBBER LGE 5040R-0069L Contact Us For Availability
283
DOOR LGE 3580R-T152C Contact Us For Availability
300
POWER CORD LGE 6410RAHX03A Contact Us For Availability
320
PANEL,VIDEO LGE 3720R-D113Y Contact Us For Availability
430
SCREW,DRAWING LGE 1SZZR-0064B Contact Us For Availability
431
SCREW,DRAWING LGE 1SZZR-0062A Contact Us For Availability
432
SCREW,DRAWING LGE 1SZZR-0072A Contact Us For Availability
435
SCREW, LGE 1SZZR-0011A Contact Us For Availability
439
SCREW,DRAWING LGE 1SZZR-0075A Contact Us For Availability
440
SCREW, LGE 1SZZH-1007B Contact Us For Availability
463
SCREW,DRAWING LGE 353-051G Contact Us For Availability
801
INSTRUCTION ASSEMBLY LGE 3835RD0037D Contact Us For Availability
802
LGE 3890R-C300F LGE 3890R-C300F Contact Us For Availability
803
LGE 3920R-E103A LGE 3920R-E103A Contact Us For Availability
804
Bag LGE 292-053Q Contact Us For Availability
808
BATTERY,ALKALINE LGE 6910A90004A Contact Us For Availability
808
BATTERY,MN LGE 841-0021 Contact Us For Availability
810
CABLE ASSEMBLY LGE 6851R-0034A Contact Us For Availability
811
PLUG ASSEMBLY LGE 6611R1D003A Contact Us For Availability
812
PLUG ASSEMBLY LGE 6611R2D003A Contact Us For Availability
900
REMOTE CONTROLLER AS LGE 6711R1N167A Contact Us For Availability
A00
DECK ASSEMBLY,VIDEO LGE 6721RHD032A Contact Us For Availability
A01
CLAMP ASSEMBLY LGE 4861R-0016B Contact Us For Availability
A02
BASE ASSEMBLY LGE 3041R-D007A Contact Us For Availability
A03
BASE ASSEMBLY LGE 3041R-D008C Contact Us For Availability
A42
PWB(PCB) ASSEMBLY,TO LGE 6871R-8298A Contact Us For Availability
A43
BOARD ASSEMBLY LGE 3501RF4999E Contact Us For Availability
A44
CHASSIS ASSEMBLY LGE 3141R-D031Y Contact Us For Availability
A45
PWB(PCB) ASSEMBLY,TO LGE 6871R-6378A Contact Us For Availability
A46
SUB PWB(PCB) ASSEMBL LGE 6885R-1035G Contact Us For Availability
A47
PWB(PCB) ASSEMBLY,TO LGE 6871R-7251B Contact Us For Availability
A48
PWB(PCB) ASSEMBLY,TO LGE 6871R-8388A Contact Us For Availability
A49
PWB(PCB) ASSEMBLY,TO LGE 6871R-8895A Contact Us For Availability
BC101
Filter,Bead LGE 636-004C Contact Us For Availability
BD101
DIODE S1WBA60 (1A 600V) LGE 0DD160000DA Contact Us For Availability
BD101
Diode,Rectifier LGE 0DRRE00060A Contact Us For Availability
C5A2
CHIP CAPA CERAMIC M/L T.C F/S LGE 0CH4470K412 Contact Us For Availability
C5E1
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8476C611 Contact Us For Availability
C6B1
Capacitor,Ceramic,Chip LGE 0CH1103K562 Contact Us For Availability
C6W4
Capacitor,Ceramic,Chip LGE 0CH4101K412 Contact Us For Availability
C6W5
Capacitor,Ceramic,Chip LGE 0CH4270K412 Contact Us For Availability
C101
Capacitor,Film,Box LGE 624-088S Contact Us For Availability
C103
LGE 0CE1071Q6A0 LGE 0CE1071Q6A0 Contact Us For Availability
C107
CAPACITOR,SEMI CERAM LGE 0CG1020U630 Contact Us For Availability
C109
Capacitor,AL,Radial LGE 0CE228BF630 Contact Us For Availability
C110
Capacitor,Ceramic,Axial LGE 0CN223AK948 Contact Us For Availability
C112
Capacitor,AL,Radial LGE 0CE3376D638 Contact Us For Availability
C113
LGE 0CC6810U565 LGE 0CC6810U565 Contact Us For Availability
C115
Capacitor,AL,Radial LGE 0CE3366K638 Contact Us For Availability
C116
Capacitor,AL,Radial LGE 0CE477BH630 Contact Us For Availability
C119
CAPACITOR,FIXED CERAMIC(High d LGE 624-087G Contact Us For Availability
C121
Capacitor,AL,Radial LGE 0CE2276F638 Contact Us For Availability
C122
Capacitor,AL,Radial LGE 624-085D Contact Us For Availability
C123
Capacitor,AL,Radial LGE 0CE108BF630 Contact Us For Availability
C126
CAPACITOR,POLYESTER LGE 0CQ1031Y519 Contact Us For Availability
C128
Capacitor,Film,DIP LGE 0CQ1042K409 Contact Us For Availability
C130
Capacitor,AL,Radial LGE 0CE1074F638 Contact Us For Availability
C201
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8107F611 Contact Us For Availability
C211
Capacitor,Ceramic,Chip LGE 0CH1821K562 Contact Us For Availability
C216
Capacitor,Ceramic,Chip LGE 0CH1102K562 Contact Us For Availability
C223
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8227C621 Contact Us For Availability
C304
Capacitor,AL,Chip LGE 0CE4775C638 Contact Us For Availability
C324
LGE 0CH1392K566 LGE 0CH1392K566 Contact Us For Availability
C331
LGE 0CH4102K406 LGE 0CH4102K406 Contact Us For Availability
C341
Capacitor,AL,Radial LGE 0CE4764F638 Contact Us For Availability
C501
Capacitor,Ceramic,Chip LGE 0CH1105D942 Contact Us For Availability
C512
Capacitor,Ceramic,Chip LGE 0CH4331K412 Contact Us For Availability
C514
Capacitor,Ceramic,Chip LGE 0CH1153K562 Contact Us For Availability
C518
Capacitor,Ceramic,Chip LGE 0CH1152K562 Contact Us For Availability
C520
CAPACITOR,CHIP[CERAM LGE 0CH1104K942 Contact Us For Availability
C536
Capacitor,Ceramic,Chip LGE 0CH4150K412 Contact Us For Availability
C537
Capacitor,Ceramic,Chip LGE 0CH4120K412 Contact Us For Availability
C549
Capacitor,Ceramic,Chip LGE 0CH1474H942 Contact Us For Availability
C551
Capacitor,Ceramic,Chip LGE 0CH4391K412 Contact Us For Availability
C556
Capacitor,Ceramic,Chip LGE 0CH1473K942 Contact Us For Availability
C563
Capacitor,Ceramic,Chip LGE 0CH4200K412 Contact Us For Availability
C565
Capacitor,Ceramic,Chip LGE 0CH1333K562 Contact Us For Availability
C576
Capacitor,Ceramic,Chip LGE 0CH1222K562 Contact Us For Availability
C593
Capacitor,Ceramic,Chip LGE 0CH4221K412 Contact Us For Availability
C621
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8226F611 Contact Us For Availability
C624
Capacitor,Ceramic,Chip LGE 0CH1392K562 Contact Us For Availability
C632
Capacitor,AL,Chip LGE 0CH8105K611 Contact Us For Availability
C655
Capacitor,AL,Chip LGE 0CH8477C611 Contact Us For Availability
C695
Capacitor,Ceramic,Chip LGE 0CH4271K412 Contact Us For Availability
C725
CAPACITOR,CHIP[AL. E LGE 0CH8106F611 Contact Us For Availability
C727
Capacitor,Ceramic,Chip LGE 0CH4330K412 Contact Us For Availability
C731
Capacitor,Ceramic,Chip LGE 0CH4100K412 Contact Us For Availability
C772
CHIP CAPA CERAMIC M/L T.C F/S LGE 0CH4220K412 Contact Us For Availability
C908
Capacitor,AL,Radial LGE 0CE4764C638 Contact Us For Availability
C1012
Capacitor,Ceramic,Chip LGE 0CH1331K412 Contact Us For Availability
C1018
Capacitor,Ceramic,Chip LGE 0CH1475D946 Contact Us For Availability
CN201
CONNECTOR (CIRC),FFC LGE 6630XE00123 Contact Us For Availability
CN202
Connector,FFC/FPC/PIC LGE 6630XE00106 Contact Us For Availability
CN203
Connector,FFC/FPC/PIC LGE 6630XE00105 Contact Us For Availability
CN602
Connector,FFC/FPC/PIC LGE 6630XE00118 Contact Us For Availability
CN604
Connector,Wafer LGE 6630R3S006M Contact Us For Availability
CN901
Connector,FFC/FPC/PIC LGE 6630R-FB05R Contact Us For Availability
CN903
LGE 6631R-E091A LGE 6631R-E091A Contact Us For Availability
D100
DIODE LGE 0DD221009AA Contact Us For Availability
D100
Diode,Rectifier LGE 0DR400709AA Contact Us For Availability
D102
Diode,Schottky LGE 0DR158220AA Contact Us For Availability
D102
Diode,Rectifier LGE 0DRGF00210A Contact Us For Availability
D103
Diode,Rectifier LGE 0DR202000AB Contact Us For Availability
D103
LGE 0DR310000AA LGE 0DR310000AA Contact Us For Availability
D103
LGE 0DRGF00200A LGE 0DRGF00200A Contact Us For Availability
D106
LGE 0DRRE00029A LGE 0DRRE00029A Contact Us For Availability
D110
DIODE,RECTIFIER LGE 0DR104009BA Contact Us For Availability
D110
Diode,Rectifier LGE 0DRGF00239A Contact Us For Availability
D600
DIODE,SWITCHING LGE 0DSRM00118A Contact Us For Availability
DIG901
LGE 6302RCV226C LGE 6302RCV226C Contact Us For Availability
DIG901
LGE 6302R-V226C LGE 6302R-V226C Contact Us For Availability
F101
FUSE,SLOW BLOW LGE 0FS1601B51D Contact Us For Availability
F306
FILTER(CIRC),EMI LGE 6200HJC901A Contact Us For Availability
F600
Filter,LCR LGE 6200JB8010V Contact Us For Availability
FH102
HOLDER FUSE LGE 586-008B Contact Us For Availability
IC101
IC,POWER MANAGEMENT LGE 0IPMGFA054A Contact Us For Availability
IC102
SENSOR LTV-817B PHOTO COUPLER LGE 657-063A Contact Us For Availability
IC103
IC,KEC LGE 0IKE781200S Contact Us For Availability
IC103
IC,POWER MANAGEMENT LGE 0IPMGSH010A Contact Us For Availability
IC103
IC,LDO Voltage Regulator LGE 0IPMGFA017A Contact Us For Availability
IC104
IC KEC, KIA431, GVR-C435/R-E4 LGE 0IKE431000A Contact Us For Availability
IC104
LGE 0IPMGUK001A LGE 0IPMGUK001A Contact Us For Availability
IC104
IC,Voltage Regulator LGE 0ISS431000A Contact Us For Availability
IC105
IC,POWER MANAGEMENT LGE 0IPMGKE008B Contact Us For Availability
IC105
IC,POWER MANAGEMENT LGE 0IPMGFA016A Contact Us For Availability
IC105
IC,Voltage Regulator LGE 0IPMGSH009A Contact Us For Availability
IC107
IC,POWER MANAGEMENT LGE 0IPMGKE022B Contact Us For Availability
IC107
IC,POWER MANAGEMENT LGE 0IPMGGM003A Contact Us For Availability
IC107
IC,POWER MANAGEMENT LGE 0IPMGFA046A Contact Us For Availability
IC201
LGE 0ILNRIJ001A LGE 0ILNRIJ001A Contact Us For Availability
IC201
IC,LINEAR LGE 0ILNRIJ001B Contact Us For Availability
IC301
LGE 0IPRPCI012A LGE 0IPRPCI012A Contact Us For Availability
IC304
IC,LINEAR LGE 0ILNRAU017A Contact Us For Availability
IC304
IC,LINEAR LGE 0ILNRUC001A Contact Us For Availability
IC304
IC,JRC LGE 0IJR458000B Contact Us For Availability
IC501
IC,LINEAR LGE 0ILNRNF009A Contact Us For Availability
IC502A
PROGRAM LGE 6957R-9991D Contact Us For Availability
IC503
IC,MEMORIES LGE 0IMMREB004A Contact Us For Availability
IC507
IC,CMOS LGE 0IFA742440F Contact Us For Availability
IC601
IC,PERIPHERALS LGE 0IPRPCI003B Contact Us For Availability
IC601
LGE 0IPRPCI003C LGE 0IPRPCI003C Contact Us For Availability
IC604
IC,PERIPHERALS LGE 0IPRPMT008A Contact Us For Availability
IC701
IC,PERIPHERALS LGE 0IPRPGN010B Contact Us For Availability
IC702
LGE 0IMMRHY025B LGE 0IMMRHY025B Contact Us For Availability
IC703
IC,PERIPHERALS LGE 0IPRPS5003A Contact Us For Availability
IC704
IC,POWER MANAGEMENT LGE 0IPMGA7001A Contact Us For Availability
IC705
IC,PERIPHERALS LGE 0IPRPMT004A Contact Us For Availability
IC706
IC,PERIPHERALS LGE 0IPRPPH012A Contact Us For Availability
IC901
IC,MICRO CONTROLLER LGE 0IMCRHY070B Contact Us For Availability
IC902
IC KIA7042P SP 4.2V RESET, KE LGE 0IKE704200B Contact Us For Availability
IC1001
LGE 0IPRPGY001A LGE 0IPRPGY001A Contact Us For Availability
IC1002
IC,MEMORIES LGE 0IMMRSW016A Contact Us For Availability
IC1005
FET LGE 0IPMGON018A Contact Us For Availability
IC1011
LGE 0ISTLTI072A LGE 0ISTLTI072A Contact Us For Availability
JK301
LGE 6612JH002XB LGE 6612JH002XB Contact Us For Availability
JK601
JACK,RCA LGE 6612J00044B Contact Us For Availability
JK602
JACK,FIBER OPTIC LGE 6612K00003D Contact Us For Availability
JK701
CONNECTOR(CIRC),DRAW LGE 6630R-SY08Z Contact Us For Availability
JK1001
LGE 6630CZ018ZC LGE 6630CZ018ZC Contact Us For Availability
JK1002
LGE 6630CZ018ZW LGE 6630CZ018ZW Contact Us For Availability
L101
FILTER(CIRC),EMC LGE 6200JB8013O Contact Us For Availability
L102
COIL,RF LGE 6140RCC003H Contact Us For Availability
L103
COIL,CHOKE LGE 633-088G Contact Us For Availability
L201
LGE 6140R-G022A LGE 6140R-G022A Contact Us For Availability
L205
INDUCTOR,CHIP LGE 0LCCE00004E Contact Us For Availability
L673
FILTER(CIRC),EMI LGE 6200HJC102A Contact Us For Availability
LED902
LED,DIP LGE 0DLAU0249AA Contact Us For Availability
LED902
LGE 0DL112000AK LGE 0DL112000AK Contact Us For Availability
P101
LGE 6631R-E034G LGE 6631R-E034G Contact Us For Availability
PCV01
Connector,Wafer LGE 6630R3S006F Contact Us For Availability
Q101
TRANSISTOR KTC3198-TP-BL(KTC1 LGE 0TR319809AC Contact Us For Availability
Q101
TRANSISTOR LGE 0TR534309BA Contact Us For Availability
Q102
LGE 0TR105009AD LGE 0TR105009AD Contact Us For Availability
Q102
LGE 0TRAU90025A LGE 0TRAU90025A Contact Us For Availability
Q107
TRANSISTOR LGE 0TR115100AA Contact Us For Availability
Q107
LGE 0TR115100AC LGE 0TR115100AC Contact Us For Availability
Q203
TRANSISTOR,BIPOLARS LGE 0TRRH80042A Contact Us For Availability
Q205
TR,Bipolar LGE 0TR150409AC Contact Us For Availability
Q205
TR,Bipolar LGE 0TRON80008A Contact Us For Availability
Q205
TR,Bipolar LGE 0TRAU80008A Contact Us For Availability
Q205
TR,Bipolar LGE 0TR103709BB Contact Us For Availability
Q301
TR,Bipolar LGE 0TRON80009A Contact Us For Availability
Q602
LGE 0TRON80007A LGE 0TRON80007A Contact Us For Availability
Q602
TR,Bipolar LGE 0TRAU80012A Contact Us For Availability
Q602
TRANSISTOR KRA103S-T1(PC)22-22 LGE 0TR103009AC Contact Us For Availability
Q605
TR CHIP KTC3875S-GR-T1(ALG) K LGE 0TR387509AC Contact Us For Availability
Q704
TRANSISTOR LGE 0TR830009BA Contact Us For Availability
Q902
TR,Bipolar LGE 0TR124009AP Contact Us For Availability
Q902
TRANSISTOR,BIPOLARS LGE 0TRAU80002A Contact Us For Availability
R6W1
Resistor,Chip LGE 0RH1100C622 Contact Us For Availability
R6W5
Resistor,Chip LGE 0RH0222C622 Contact Us For Availability
R100
RESISTOR,FIXED CARBON FILM LGE 0RD1504H632 Contact Us For Availability
R101
RESISTOR 2.7/2W CEMENT SMPS V LGE 614-007A Contact Us For Availability
R102
Resistor,Fusible LGE 0RF0200F708 Contact Us For Availability
R103
RESISTOR,FIX METAL FILM OXIDE LGE 0RS5602K619 Contact Us For Availability
R112
Resistor,Carbon Film LGE 0RD0822F608 Contact Us For Availability
R114
RESISTOR FIXED CARBON FILM 100 LGE 0RD1003F608 Contact Us For Availability
R116
Resistor,Carbon Film LGE 0RD0332F608 Contact Us For Availability
R120
RESISTOR FIXED CARBON FILM 47K LGE 0RD4702F608 Contact Us For Availability
R122
Resistor,Carbon Film LGE 0RD2200F608 Contact Us For Availability
R124
Resistor,Carbon Film LGE 0RD1800F608 Contact Us For Availability
R127
LGE 0RN3601E408 LGE 0RN3601E408 Contact Us For Availability
R128
LGE 0RN3301E408 LGE 0RN3301E408 Contact Us For Availability
R132
Resistor,Carbon Film LGE 0RD1002F608 Contact Us For Availability
R145
Resistor,Carbon Film LGE 0RD4700F608 Contact Us For Availability
R214
Resistor,Chip LGE 0RH0471C622 Contact Us For Availability
R218
Resistor,Chip LGE 0RJ7503C677 Contact Us For Availability
R227
Resistor,Chip LGE 0RH5601C622 Contact Us For Availability
R228
Resistor,Chip LGE 0RH2701C622 Contact Us For Availability
R231
Resistor,Chip LGE 0RH0101C622 Contact Us For Availability
R244
Resistor,Chip LGE 0RH2201C622 Contact Us For Availability
R309
Resistor,Chip LGE 0RH3300D622 Contact Us For Availability
R366
RESISTOR CHIP 100K 1/10W 5 D. LGE 0RH1003D622 Contact Us For Availability
R505
Resistor,Chip LGE 0RH2202C622 Contact Us For Availability
R508
Resistor,Chip LGE 0RH6801C622 Contact Us For Availability
R516
Resistor,Chip LGE 0RH0332C622 Contact Us For Availability
R518
Resistor,Chip LGE 0RH0681C622 Contact Us For Availability
R527
Resistor,Chip LGE 0RH1502C622 Contact Us For Availability
R559
Resistor,Chip LGE 0RH1201C622 Contact Us For Availability
R595
Resistor,Chip LGE 0RH0822C622 Contact Us For Availability
R607
Resistor,Chip LGE 0RH8201C622 Contact Us For Availability
R617
Resistor,Chip LGE 0RH7501C622 Contact Us For Availability
R620
Resistor,Chip LGE 0RH3300C622 Contact Us For Availability
R643
Resistor,Chip LGE 0RH1800C622 Contact Us For Availability
R662
Resistor,Chip LGE 0RH0752C622 Contact Us For Availability
R696
RESISTOR,CHIP LGE 0RH1001C622 Contact Us For Availability
R707
RESISTOR,CHIP LGE 0RH1000C622 Contact Us For Availability
R708
RESISTOR,CHIP LGE 0RH1002C622 Contact Us For Availability
R721
Resistor,Chip LGE 0RH0912C622 Contact Us For Availability
R730
INDUCTOR,CHIP LGE 0LCCE00005T Contact Us For Availability
R735
Resistor,Chip LGE 0RH0000C622 Contact Us For Availability
R743
Resistor,Chip LGE 0RH4701C622 Contact Us For Availability
R750
RH 47K-J 1/16W GVC-F475,F477 LGE 0RH4702C622 Contact Us For Availability
R902
Resistor,Carbon Film LGE 0RD8200F608 Contact Us For Availability
R903
Resistor,Carbon Film LGE 0RD1201F608 Contact Us For Availability
R904
Resistor,Carbon Film LGE 0RD1501F608 Contact Us For Availability
R905
Resistor,Carbon Film LGE 0RD2201F608 Contact Us For Availability
R906
Resistor,Carbon Film LGE 0RD6800F608 Contact Us For Availability
R910
Resistor,Chip LGE 0RH3301C622 Contact Us For Availability
R913
Resistor,Chip LGE 0RH2200C622 Contact Us For Availability
R914
Resistor,Chip LGE 0RH8200C622 Contact Us For Availability
R938
Resistor,Chip LGE 0RH1003C622 Contact Us For Availability
R1007
Resistor,Chip LGE 0RH5100C422 Contact Us For Availability
R1008
Resistor,Chip LGE 0RH1004C622 Contact Us For Availability
R1010
Resistor,Chip LGE 0RH5102C622 Contact Us For Availability
R1013
Resistor,Chip LGE 0RH2003C622 Contact Us For Availability
R1014
Resistor,Chip LGE 0RH3002C622 Contact Us For Availability
R1015
Resistor,Chip LGE 0RJ0332C477 Contact Us For Availability
R1028
Resistor,Chip LGE 0RH1002C422 Contact Us For Availability
RA704
Resistor,Array LGE 0RRZVTA001L Contact Us For Availability
RC901
REMOTE CONTROLLER RE LGE 6712R1038GA Contact Us For Availability
SW901
SWITCH,TACT LGE 6600R000036 Contact Us For Availability
SW909
SWITCH,TACT LGE 6600R000028 Contact Us For Availability
T101
TRANSFORMER,SMPS[COI LGE 6170RNGW05F Contact Us For Availability
V101
VARISTOR LGE 656-004C Contact Us For Availability
V708
Varistor LGE 6102R7E001A Contact Us For Availability
X701
RESONATOR,CRYSTAL LGE 6212AB2135C Contact Us For Availability
X901
RESONATOR,CERAMIC LGE 6212BA3004A Contact Us For Availability
ZD101
DIODE,ZENERS LGE 0DZ332609FB Contact Us For Availability
ZD102
Diode,Zener LGE 0DZ222609AA Contact Us For Availability
× ![]()
Login and Registration Form
