Model LG L1800PK – Common Parts & Diagrams
Diagram 0
Common parts from model LG L1800PK
0
POWER CORD LGE 174-206M Contact Us For Availability
0
SCREW,DRAWING LGE 332-112F Contact Us For Availability
0
SCREW,DRAWING LGE 332-113S Contact Us For Availability
0
LGE 3550TKK221B LGE 3550TKK221B Contact Us For Availability
0
COVER LGE 3550TKK223C Contact Us For Availability
0
LCD,Module-TFT LGE 6304FLP034A Contact Us For Availability
0
Harness,Single LGE 6631T25008Q Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST273A Contact Us For Availability
0
LGE 3171TZ1298C LGE 3171TZ1298C Contact Us For Availability
0
Screw,Customized LGE 332-068B Contact Us For Availability
0
SCREW LGE 332-105A Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 387-P61A Contact Us For Availability
0
Packing LGE 3920TKE227A Contact Us For Availability
0
Plate Assembly LGE 4951TKK071D Contact Us For Availability
0
Single Harness LGE 6631T20015U Contact Us For Availability
0
PWB(PCB) ASSEMBLY,PO LGE 6871TPT219B Contact Us For Availability
0
PWB(PCB) ASSEMBLY,US LGE 6871TUT015A Contact Us For Availability
0
SCREW, LGE 1SZZTPP001B Contact Us For Availability
0
LGE 332-112A LGE 332-112A Contact Us For Availability
0
SCREW ASSY LGE 339-006A Contact Us For Availability
0
LGE 3550TKK219C LGE 3550TKK219C Contact Us For Availability
0
Plate LGE 4814TKK187A Contact Us For Availability
0
Plate LGE 4950TKK346A Contact Us For Availability
0
Spring LGE 4970TKK008A Contact Us For Availability
0
Cable,Assembly LGE 6631T11012P Contact Us For Availability
0
Harness,Single LGE 6631T39001B Contact Us For Availability
0
SCREW,DRAWING LGE 1SZZTMF008A Contact Us For Availability
0
LGE 3091TKL091A LGE 3091TKL091A Contact Us For Availability
0
LGE 3550TKK225B LGE 3550TKK225B Contact Us For Availability
0
Bag LGE 3880TVZ007F Contact Us For Availability
0
SIGNAL CABLE LGE 6866TDU002A Contact Us For Availability
0
LGE 6871TMT467A LGE 6871TMT467A Contact Us For Availability
0
MAIN TOTAL ASSEMBLY LGE 3313TL8035A Contact Us For Availability
0
LGE 3890TSE309R LGE 3890TSE309R Contact Us For Availability
0
Plate LGE 4950TKK345A Contact Us For Availability
0
SCREW LGE 332-095A Contact Us For Availability
0
LGE 332-110A LGE 332-110A Contact Us For Availability
0
Plate LGE 4814TKK188B Contact Us For Availability
0
Plate Assembly LGE 4951TKS106B Contact Us For Availability
0
Harness,Single LGE 6631T20015R Contact Us For Availability
0
CABLE,DVI LGE 6866TDV004K Contact Us For Availability
0
LGE 1BWF0302616 LGE 1BWF0302616 Contact Us For Availability
0
SCREW, LGE 1SZZTPC002A Contact Us For Availability
0
DISKETTE ASSEMBLY LGE 3171TZZ001G Contact Us For Availability
0
LGE 3550TKK217C LGE 3550TKK217C Contact Us For Availability
0
LGE 3550TKK220B LGE 3550TKK220B Contact Us For Availability
0
LGE 3550TKK222C LGE 3550TKK222C Contact Us For Availability
0
LGE 3550TKK224C LGE 3550TKK224C Contact Us For Availability
0
SCREW, LGE 332-105G Contact Us For Availability
0
SCREW, LGE 1SZZTER001A Contact Us For Availability
0
SCREW,DRAWING LGE 1SZZTER001H Contact Us For Availability
0
SCREW, LGE 1SZZTPC001A Contact Us For Availability
0
LGE 3550TKK216C LGE 3550TKK216C Contact Us For Availability
0
LGE 3550TKK218C LGE 3550TKK218C Contact Us For Availability
0
LGE 3809TKL022G LGE 3809TKL022G Contact Us For Availability
0
Drawing,Assembly LGE 6631T25005E Contact Us For Availability
0
Inverter,DC/AC LGE 6633TZA008C Contact Us For Availability
0
LGE 6850TD9001H LGE 6850TD9001H Contact Us For Availability
BD901
DIODE D3SBA60 SHINDENKEN CM-77 LGE 0DD360000DA Contact Us For Availability
C1
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8107F611 Contact Us For Availability
C6
CAPACITOR,CHIP[CERAMIC LD-LESS LGE 0CH3105F946 Contact Us For Availability
C38
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C220
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C514
CAPACITOR,CHIP[AL. E LGE 0CH8106F611 Contact Us For Availability
C707
CAPACITOR,FIXED CERA LGE 0CC680CK41A Contact Us For Availability
C711
CAPACITOR,FIXED CERA LGE 0CK103CK51A Contact Us For Availability
C750
CAPACITOR,AL.ELECTRO LGE 0CE477EH618 Contact Us For Availability
C760
CAPACITOR,FIXED ELEC LGE 0CE107EF610 Contact Us For Availability
C809
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C901
Capacitor,Film,Box LGE 0CBZTBU002B Contact Us For Availability
C902
Capacitor,Ceramic,Radial LGE 0CKZTBU006B Contact Us For Availability
C904
Capacitor,Film,Box LGE 0CBZTBU002C Contact Us For Availability
C905
Capacitor,AL,Radial LGE 0CZZTAB002C Contact Us For Availability
C906
Capacitor,Ceramic,Radial LGE 0CK10302945 Contact Us For Availability
C907
Capacitor,AL,Radial LGE 0CE476EK638 Contact Us For Availability
C908
Capacitor,Film,DIP LGE 0CQ2721N419 Contact Us For Availability
C909
CAPACITOR CERAMIC(HIGH DIELE) LGE 0CK1020K515 Contact Us For Availability
C913
CAPACITOR,AL.ELECTROLYTIC LGE 0CE108EF618 Contact Us For Availability
C914
Capacitor,AL,Radial LGE 0CE228ED630 Contact Us For Availability
C916
Capacitor,Film,DIP LGE 181-288L Contact Us For Availability
C921
Capacitor,AL,Radial LGE 0CE228EF630 Contact Us For Availability
C923
Capacitor,Ceramic,Radial LGE 0CKZTTA002E Contact Us For Availability
C924
CAPACITOR,ELECTROLYTIC LGE 0CE336BH638 Contact Us For Availability
D1
DIODE,SWITCHING LGE 0DS181009AA Contact Us For Availability
D717
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
D901
Diode,Rectifier LGE 0DD400709CB Contact Us For Availability
D902
DIODE,RECTIFIER LGE 0DR400409AB Contact Us For Availability
D903
Diode,Schottky LGE 0DRIR00011B Contact Us For Availability
D906
Diode,Schottky LGE 0DRIR00021A Contact Us For Availability
D907
DIODE,SWITCHING LGE 0DS113309AA Contact Us For Availability
F901
FUSE,DRAWING LGE 0FZZTTH001D Contact Us For Availability
FH1
Fuse Holder LGE 430-858C Contact Us For Availability
IC901
IC,POWER MANAGEMENT LGE 0IPMGIH001A Contact Us For Availability
IC904
IC,Voltage Regulator LGE 0ISS431000A Contact Us For Availability
IC905
IC LGE 0ISS780500F Contact Us For Availability
J1
Connector,USB LGE 6630SK00804 Contact Us For Availability
J701
CONNECTOR (CIRC),D-S LGE 6630TGA005A Contact Us For Availability
J703
Connector,DSUB LGE 6630G100315 Contact Us For Availability
L17
Filter,Bead LGE 6210TCE001P Contact Us For Availability
L18
Filter,Bead LGE 6210TCE001B Contact Us For Availability
L901
Coil,Choke LGE 150-A85F Contact Us For Availability
LED1
LED,Chip LGE 0DLRH0058AA Contact Us For Availability
LF901
FILTER(CIRC),DRAWING LGE 6200TZZ001A Contact Us For Availability
PC1
IC,LITEON LGE 0ILI817000E Contact Us For Availability
Q503
IC,KEC LGE 0IKE704200H Contact Us For Availability
Q504
TRANSISTOR LGE 0TR390409AE Contact Us For Availability
Q704
TRANSISTOR LGE 0TR390609FA Contact Us For Availability
Q902
TRANSISTOR,FETS LGE 0TFFN10004B Contact Us For Availability
R2
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R3
RESISTOR CHIP 820 1/10W 5 D.R LGE 0RH8200D622 Contact Us For Availability
R5
RESISTOR,METAL GLAZE LGE 0RJ1501D677 Contact Us For Availability
R7
Resistor,Chip LGE 0RJ2201D677 Contact Us For Availability
R8
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
R32
RESISTOR,METAL GLAZE LGE 0RJ1502D677 Contact Us For Availability
R34
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R207
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R212
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R703
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R707
Resistor,Chip LGE 0RJ0272D677 Contact Us For Availability
R767
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R774
RESISTOR,METAL GLAZE LGE 0RJ0102D677 Contact Us For Availability
R813
RESISTOR,METAL GLAZE LGE 0RJ2202D677 Contact Us For Availability
R901
Resistor,Carbon Film LGE 0RD6803A609 Contact Us For Availability
R903
RESISTOR,FIXED CARBON FILM LGE 0RD3902A609 Contact Us For Availability
R906B
Resistor,Metal Oxide Film LGE 0RX5102J609 Contact Us For Availability
R908
Resistor,Carbon Film LGE 0RD0222Q609 Contact Us For Availability
R909
Resistor,Carbon Film LGE 0RD1001Q609 Contact Us For Availability
R910
Resistor,Carbon Film LGE 0RD0431A609 Contact Us For Availability
R913
Resistor,Metal Film LGE 0RN1102F409 Contact Us For Availability
R918
RESISTOR,FIXED CARBON FILM LGE 0RD1000Q609 Contact Us For Availability
R921
Resistor,Metal Film LGE 0RN2701F409 Contact Us For Availability
R923
Resistor,Wire Wound LGE 0RB0330K607 Contact Us For Availability
R924
Resistor,Carbon Film LGE 0RD1800Q609 Contact Us For Availability
R925
Resistor,Carbon Film LGE 0RD1002Q609 Contact Us For Availability
R926
Resistor,Metal Film LGE 0RN0471H609 Contact Us For Availability
R927
Resistor,Carbon Film LGE 0RD0102A609 Contact Us For Availability
R928
Resistor,Carbon Film LGE 0RD0821Q609 Contact Us For Availability
SW7
Switch,Tact LGE 6600R000002 Contact Us For Availability
T901
TRANSFORMER,SMPS[COI LGE 6170TMZ125B Contact Us For Availability
TH902
Thermistor,NTC LGE 6322TA080AA Contact Us For Availability
U1
IC,ROHM LGE 0IRH033200A Contact Us For Availability
U201
IC,PERIPHERALS LGE 0IPRPM3006A Contact Us For Availability
U501
LGE 0IZZTSZ257B LGE 0IZZTSZ257B Contact Us For Availability
U502
IC,MEMORIES LGE 0ISG240860B Contact Us For Availability
U803
IC,POWER MANAGEMENT LGE 0IPMGNS001D Contact Us For Availability
U804
IC,POWER MANAGEMENT LGE 0IPMGNS001E Contact Us For Availability
U805
TRANSISTOR,FETS LGE 0TFVI80036A Contact Us For Availability
X1
Crystal LGE 6202TST001C Contact Us For Availability
X501
RESONATOR,CRYSTAL LGE 6212AA2004A Contact Us For Availability
ZD708
DIODE,ZENERS LGE 0DZ560009GB Contact Us For Availability
ZD901
DIODE,ZENERS LGE 0DZ470009BC Contact Us For Availability
ZD902
Diode,Zener LGE 0DZ200009AD Contact Us For Availability
× ![]()
