Model LG L1510P – Common Parts & Diagrams
Diagram 0
Common parts from model LG L1510P
0
LCD(LIQUID CRYSTAL D LGE 6304FLP068A Contact Us For Availability
0
PWB(PCB) ASSEMBLY,US LGE 6871TUT015A Contact Us For Availability
0
LGE 3880TKZ012C LGE 3880TKZ012C Contact Us For Availability
0
SCREW MACHINE,BINDIN LGE 1MBC0251723 Contact Us For Availability
0
CABINET ASSEMBLY LGE 3091TKL087G Contact Us For Availability
0
DISKETTE ASSEMBLY LGE 3171TZZ001G Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST385A Contact Us For Availability
0
LGE 4951TKK088A LGE 4951TKK088A Contact Us For Availability
0
PWB(PCB) ASSEMBLY,PO LGE 6871TPT271A Contact Us For Availability
0
SCREW, LGE 1SZZTPP001B Contact Us For Availability
0
MAIN TOTAL ASSEMBLY LGE 3313TL5082A Contact Us For Availability
0
SCREW, LGE 332-105G Contact Us For Availability
0
LGE 3890TSE323N LGE 3890TSE323N Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T11012R Contact Us For Availability
0
CABLE,D-SUB LGE 6850TD9004J Contact Us For Availability
0
SIGNAL CABLE LGE 6866TDU002D Contact Us For Availability
0
TILT SWIVEL ASSEMBLY LGE 3043TKK095A Contact Us For Availability
0
LGE 332-110A LGE 332-110A Contact Us For Availability
0
LGE 4951TKS134B LGE 4951TKS134B Contact Us For Availability
0
LGE 3920TKE170J LGE 3920TKE170J Contact Us For Availability
0
POWER CORD LGE 6410TUW002B Contact Us For Availability
0
SCREW, LGE 1SZZTER001A Contact Us For Availability
0
SCREW,DRAWING LGE 332-068U Contact Us For Availability
0
LGE 3920TKE186A LGE 3920TKE186A Contact Us For Availability
0
CABLE,DVI LGE 6866TDV004C Contact Us For Availability
0
SCREW, LGE 1SZZTPC002A Contact Us For Availability
0
SCREW,DRAWING LGE 332-112F Contact Us For Availability
0
BACK COVER ASSEMBLY LGE 3809TKL079A Contact Us For Availability
C1
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8107F611 Contact Us For Availability
C6
CAPACITOR,CHIP[CERAMIC LD-LESS LGE 0CH3105F946 Contact Us For Availability
C38
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C209
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C504
CAPACITOR,CHIP[AL. E LGE 0CH8106F611 Contact Us For Availability
C719
CAPACITOR,FIXED CERA LGE 0CC680CK41A Contact Us For Availability
C721
CAPACITOR,FIXED CERA LGE 0CK103CK51A Contact Us For Availability
C727
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C803
CAPACITOR,FIXED ELEC LGE 0CE107EF610 Contact Us For Availability
D1
DIODE,SWITCHING LGE 0DS181009AA Contact Us For Availability
D723
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
L14
Filter,Bead LGE 6210TCE001P Contact Us For Availability
L18
Filter,Bead LGE 6210TCE001B Contact Us For Availability
LED1
LED LGE 0DLBE0028AA Contact Us For Availability
Q502
IC,KEC LGE 0IKE704200H Contact Us For Availability
Q505
TRANSISTOR LGE 0TR390409AE Contact Us For Availability
Q704
TRANSISTOR LGE 0TR390609FA Contact Us For Availability
Q801
TRANSISTOR LGE 0TR127309AA Contact Us For Availability
R4
RESISTOR,METAL GLAZE LGE 0RJ1501D677 Contact Us For Availability
R19
RESISTOR,METAL GLAZE LGE 0RJ1502D677 Contact Us For Availability
R207
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R513
Resistor,Chip LGE 0RJ2000D677 Contact Us For Availability
R561
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R701
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R702
RESISTOR,METAL GLAZE LGE 0RJ2001D677 Contact Us For Availability
R729
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R755
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R772
RESISTOR,METAL GLAZE LGE 0RJ0102D677 Contact Us For Availability
R773
Resistor,Chip LGE 0RJ0122D677 Contact Us For Availability
R778
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R779
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
R825
LGE 0RX0470J609 LGE 0RX0470J609 Contact Us For Availability
SW7
SWITCH LGE 140-058E Contact Us For Availability
U1
IC,ROHM LGE 0IRH033200A Contact Us For Availability
U201
LGE 0IPRPM3009B LGE 0IPRPM3009B Contact Us For Availability
U501
LGE 0IZZTSZ329A LGE 0IZZTSZ329A Contact Us For Availability
U502
IC,MEMORIES LGE 0ISG240860B Contact Us For Availability
U703
IC,MEMORIES LGE 0IMMRSG036A Contact Us For Availability
U801
IC,POWER MANAGEMENT LGE 0IPMGKE011A Contact Us For Availability
X1
Crystal LGE 6202TST001C Contact Us For Availability
X501
RESONATOR,CRYSTAL LGE 6212AA2004A Contact Us For Availability
ZD712
DIODE,ZENERS LGE 0DZ560009GB Contact Us For Availability
× ![]()
